SPECIFICATIONS

Functional Specifications
Adjustments/Settings
Overcurrent
Underload (dry-well)
Overvoltage
233P, 233P-1.5
111P
Undervoltage
233P, 233P-1.5
111P
Number of restarts allowed in 60
second period (rapid-cycling)
Trip Delay Times
Overcurrent
Dry-well
Dry-well Optional*
Restart Delay Times
Over/undervoltage
All other faults
Input Characteristics
Supply Voltage
233P, 233P-1.5
111P
Load Range
233P
233P-1.5
111P
Frequency
Output Characteristics
Output Contact Rating-SPST
233P
233P-1.5
111P
General Characteristics
Operating Temperature
Maximum Input Power
Wire Gauge
Terminal Torque
Standards Passed
Electrostatic Discharge (ESD)
Surge Immunity
Safety Marks
cUL Listed
Dimensions
Weight
Mounting Methods
*use part number 233P-UCTD8
Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: info@clrwtr.com
125% of calibration point
Adjustable (70-90% of calibrated run power)
265VAC
132.5VAC
190VAC
95VAC
4
5 seconds
4 seconds
8 seconds
2 seconds
Manual, 2-225 minutes
230VAC
115VAC
1/3 – 3 hp
1/3 – 1.5 hp
1/3 – 1 hp
50/60Hz
(NOTE: 50Hz will increase all delay timers by 20%)
3hp @ 240VAC (17 Amps max.)
1.5hp @ 240VAC (10 Amps max.)
1hp @ 120VAC (16 Amps max.)
-40° to 55°C (-40° to 131°F)
5 W
Solid or stranded 10 – 22 AWG
13 in.-lbs.
IEC 61000-4-2, Level 2, 4kV contact, 6kV air
IEC 61000-4-5, Level 4, 4kV line-to-line and line-to-
ground
UL508 & C22.2 No. 14
2.90" H x 5.26" W x 2.93" D
14 oz.
#8 screws
