Nilfisk-Advance BA 751 Use And Maintenance

Use and Maintenance
- BA 651/751/851/751C
ATTENTION! Do not use the machine before you have read and understood the User Manual
External battery charger
1a. Switch off charger by pressing the
STOP button. Unplug charger cable
from red battery plug. Reconnect
the red battery plug to the machine.
5. Place the brushes or the pad-holders
under the deck. Use the appropriate
brushes to clean the floor.
10. Lower the squeegee with the lever.
15. Press the switch and wait for the
brushes to fall on the floor.Remove
the brushes and clean them.
If the machine has been used until the Red light illuminates on the battery level indicator on the machine, a full recharge of the batteries (10-12 hours) will be required.
Failure to carry out this this procedure may cause damage to the batteries. Charging the batteries after every use is recommended.
PLEASE ENSURE RED SOCKET IS LEFT DISCONNECTED AFTER RECHARGE IF THE MACHINE IS NOT TO BE USED ON A DAILY BASIS
Nilfisk A/S Tel.: +45 43 23 40 50
Kornmarksvej 1 Fax: +45 43 43 77 00
DK-2605 Brøndby mail.com@nilfisk.com
Denmark www.nilfisk.com
Machine with battery charger
1b. Disconnect the battery charger
cable from the electrical main.
6. Turn the ignition key to "I", then
lower the deck by pressing the Green
switch. To engage the brushes,
slightly press the drive paddle and
then release it.
11. Push the drive paddle for starting
floor cleaning. If solution applied
flows outside the brush housing
during use, reduce the flow of
solution. Switch off the machine
using the key.
16. Take the squeegee off and remove
debris. Check and clean the squeegee
blades.
2. Fill the tank with a clean water. The
clean water temperature must not
exceed 40 °C.
7. Press the solution flow control
switches as necessary, depending
on the type of cleaning to be per-
formed.
12. At the end of the work. Empty the
recovery tank with the hose. Then
empty the solution tank with the
trasparent hose
17. Clean the machine using a damp
cloth and where needed use a neutral
cleaning product.
3. Fill the EcoFlex tank with a
detergent suitable for the work to
be performed (highly concentrated
detergent).
8. Press the detergent flow control
switch. The number of display shows
the detergent concentration level in
the solution (see the table on the la-
bel). See the User Manual for setting
change.
13. Wash with clean water the recovery
tank and the vacuum grid. Remove
and clean the debris tray.
18. Charge the batteries: Connect the
battery charger cable from the
electrical main.
4. Install the squeegee and fasten it
with the handwheels, then connect
the vacuum hose to the squeegee.
9. Press the EcoFlex™ switch whenever
you temporarily need a greater
cleaning power.
14. Clean the filter: 1) Close the solu-
tion tap under the machine. 2)
Remove the transparent cover and
the gasket, then remove the filter
strainer.
19. Park the machine with the recovery
tank cover open.
