- Page 1 W A L K I N G F R A M E DYNAMICO DYNAMICO I N D O O R U S E I N D O O R U S E W A L K I N G F R A M E DYNAMICO DYNAMICO OUTDOOR USE...
- Page 3 In the end, should you still h ave something to ask for or to clear, don't hes itate to contact your Dealer, who w ill be glad to give y ou all the necessary assistance, o r directly call ORMESA. Our phone number is +39 0742 22927, our fax number is +39 0742 22637, our e- mail is: info@ormesa.com...
-
Page 4: Table Of Contents
INDEX WARNINGS ........................3 GUARANTEE ....................... 6 HOW TO STORE AND TRANSPORT THE MEDICAL DEVICE ........6 SOME EXAMPLES OF WHAT SHOULDN’T BE DONE WHILE USING DYNAMICO . 7 LABELS AND PLATES ....................7 TECHNICAL SPECIFICATIONS OF THE INDOOR DYNAMICO ......... 8 TECHNICAL SPECIFICATIONS OF THE OUTDOOR DYNAMICO ...... -
Page 5: Warnings
The handbook reflects the kind of techni que at the moment of putting th e aid on the market. ORMESA srl reserves the right to carry out any modification to the aid and to its handbook which can be suggested by the experience, by technical considerations or b y the change of sta ndards. - Page 6 accessories and all those parts which can be loosened are firmly locked Always make sure that there are no obstacles which could cause DYNAMICO to tip up, such as mats, steps and different objects on the floor Remove any knick-knacks or objects which could be knocked down while using DYNAMICO ...
- Page 7 Any CHANGES in the product and the REPLACEMENT WITHOUT ORIGINAL PARTS OR COMPONENTS ARE NOT AUTHORIZED. REFER ONLY TO ORMESA, otherwise warranty and marking will be voided In case of DOUBT about the SAFETY of the product or DAMAGE to parts or components, you are urged to...
-
Page 8: Guarantee
GUARANTEE ORMESA warrants the product for 2 years; in case of problems, contact the retailer where you purchased it. Always ask for original parts and accessories. ORMESA will not be liable for damage in the following cases: - use by an unsuitable person;... -
Page 9: Some Examples Of What Shouldn't Be Done While Using Dynamico
SOME EXAMPLES OF WHAT SHOULDN’T BE DONE WHILE USING DYNAMICO DYNAMICO MUSTN'T BE USED UNLESS A MEMBER OF THE FAMILY OR QUALIFIED PERSON IS PRESENT AT ALL TIME DO NOT CARRY OUT ANY OPERATION OR MANOEUVRE UNLESS YOU ARE SURE OF THE RESULT: IF IN DOUBT, CONTACT YOUR NEAREST TECHNICAL SERVICE OR CONTACT THE MANUFACTURER DIRECTLY NEVER USE DYNAMICO ON UNEVEN GROUND, STEEP SLOPES OR STAIRS NEVER ALLOW UNKNOWN PEOPLE TO USE DYNAMICO, NOT EVEN TO PLAY... -
Page 10: Technical Specifications Of The Indoor Dynamico
TECHNICAL SPECIFICATIONS OF THE INDOOR DYNAMICO - Non-toxic epoxy varnished chromium-plated frame in steel; - Padded pelvic support, adjustable in height as well as backwards and forwards; - Padded chest support, adjustable in height and removable; - Double thickness fabric harness, adjustable in height. it has straps and buckles to adjust the height and velcro strip to adjust the circumference;... -
Page 11: Technical Specifications Of The Outdoor Dynamico
TECHNICAL SPECIFICATIONS OF THE OUTDOOR DYNAMICO - Non-toxic epoxy varnished chromium-plated frame in steel; - Padded pelvic support, adjustable in height as well as backwards and forwards; - Padded chest support, adjustable in height and removable; - Double thickness fabric harness, adjustable in height. it has straps and buckles to adjust the height and velcro strip to adjust the circumference;... -
Page 12: Initial Preparation
INITIAL PREPARATION INFORMATION ABOUT THE PACKING OF THE INDOOR DYNAMICO WALKING VOLUME WEIGHT FRAME DYNAMICO 1 0,253 0,281 DYNAMICO 2 0,304 DYNAMICO 3 0,338 DYNAMICO 4 DYNAMICO 5 0,281 INFORMATION ABOUT THE PACKING OF THE OUTDOOR DYNAMICO WALKING VOLUME WEIGHT... -
Page 13: How To Assemble The Indoor Dynamico
HOW TO ASSEMBLE THE INDOOR DYNAMICO HOW TO ASSEMBLE THE OUTDOOR DYNAMICO Pag. 11 / 24... -
Page 14: What Dynamico Is
WHAT DYNAMICO IS DYNAMICO is a walking aid, that is a device designed to help his User move around on his own. It consists of: rigid frame castor wheels to help movement in different directions. pelvic support chest support the C-D supports may be used together or separately according to the User's physical conditions. -
Page 15: How Dynamico Works And How To Use It
c) to organize a wider structured vision of space, distance and the User's surroundings in the upright position; d) to enable "projects" and "actions" to be planned,for example having the possibility to Pict. 4 see an object, think of its use, work the movement out to reach the object and use it (Pict. - Page 16 There is no predetermined position! Each position must be decided according to the User and it must be modified according to his physical development, to the change in his motory situation and rehabilitation programme. Generally speaking , however, the distance of the supports from the ground must allow the User to just touch the floor (so that only part of the child's weight is on his feet), with a slight...
- Page 17 If the User is inclined to cross his feet and legs over (adductive or scissor pattern), the leg divider 814 must be used to avoid this pathological position (accessory Pict. 12). When these operations are completed, DYNAMICO can be used. First of all it is important to know the aid and how to use it.
-
Page 18: Assembling The Accessories
For those childr en who cannot easily walk, it is better to m ove the pelvic support at the back in order to exion of the trunk. In this way it will be easier to move the lower limbs. ASSEMBLING THE ACCESSORIES Assembling the ARM SUPPORTS They are available for INDOOR AND •... -
Page 19: Assembling The Wheel Direct. Locks 812
Assembling the WHEEL DIRECTIONAL LOCKS They are available for INDOOR DYNAMICO. • Disassemble the back wheels by unscrewing the threaded pins Y with our key. • Disassemble the wheel support by operating on the V screw. • Fix the R ring in the pin and direct it in such a way that the hole is well aligned forward. •... -
Page 20: Assembling The Leg Divider 814
Assembling the LEG DIVIDER It is available for INDOOR DYNAMICO • Assemble the a ccessory F as it is shown in • the Picture. Fix tw o screws on the upper part and two screws on the lower part. Screw tight by using our hexagonal key •... -
Page 21: Some Therapeutical Suggestions
SOME THERAPEUTICAL SUGGESTIONS As we have previously seen, DYNAMICO can be a valid instrument to practice certain walking patterns. In this section we'll illustrate a few examples of possible rehabilitation activities to be carried out in the gym or at home. WARNING! These exercises must be carried out under the strict control of either a parent or authorized, specialized personnel. - Page 22 A course of skittles and horizontal lines with a red fixed goal to be reached (Pict. 27 - This exercise aims to programme walking in order to reach a goal through visual and motory construction. Pict. 27 The child has to walk and take the object placed at the end of the course.
- Page 23 Pathway with a sudden STOP This path aims to form the ability to stop the step pattern, that is, to stop when the child wants to. The child must stop at a precise point in the pathway. The "STOP" point must be changed each time.
-
Page 24: Maintenance, Cleaning And Disinfection
MAINTENANCE, CLEANING AND DISINFECTION REGULAR (OR PREVENTIVE) MAINTENANCE ORDINARY MAINTENANCE OF THE AID AND ITS ACCESSORIES MUST BE PERFORMED MONTHLY. REGULAR MAINTENANCE IS REQUIRED TO KEEP THE PRODUCT WORKING PROPERLY AND SAFELY AND IT IS ES SENTIAL FOR KEEPING THE CE MARK. ONLY WHEN THESE INTERVENTIONS ARE COMPLETED IN THE TIME AND WAY HEREIN SPECIFIED, THE RESPONSIBILITY OF K EEPING THE MAIN REQUIREMENTS OF THE WALKING FRAME... -
Page 25: Customer Service And Spare Parts
EXTRAORDINARY MAINTENANCE ( or corrective ) EXTRAORDINARY MAINTENANCE MEANS ALL THOSE WORKS ON THE WALKING FRAME WHICH ARE DIFFERENT FROM THE ABOVE MENTIONED ONES. WE ASK THE USER, DE ALER AND ALL PUBLIC HEALTH SERVICES TO LE T THE MANUFACTURER OR OTHER OFFICIALLY AUTHORIZED COMPANIES INTERVENE WITH EXTRAORDINARY MAINTENANCE WORKS. -
Page 26: Conditions For Durability
Prior to recycling or reassignment an already used Ormesa product, it is required that: a doctor or therapist verifies that the aid is appropriate and adequate to meet the dimensional, functional and postural needs of the new user, and if all its components are suitable / appropriate for him. - Page 28 AND LISTED IN THE GERMAN HMV (Technical Aids Listing) REGISTERED - USA Authorized Dealer The technical Data and information given in this handbook are not binding. ORMESA reserves the right to carry out any necessary change without prior notice or replacements...
