Cycle Without Bend; Punching - CYBELEC DNC 600S User Manual

C
YCLE WITHOUT
P
UNCHING
PAGE 70 USER GUIDE DNC 600S
B
END
The cycle without bend is used to move the axes and auxiliary functions
without moving the beam.
To program a cycle without be
Delete the field.
Program Y1 and Y2 at a value greater than that of the pinch point
(PP).
The cycle proceeds as follows:
Descent command
TDC output cut
End of bend impulse
Sequence forward
Start of axes and auxiliary functions depending on the mode
TDC ou tput activated
Control synchro impulse
Wait descent command
This cycle has been defined for re-arming the
bend.
To use punching tools on the pressbrake, it is essential to know
of the punch.
Then the DNC is to program in such a way that the bottom dea
corresp onds to this exit point.
If necessary, a fictitious tools pair can be programmed in order to
reference height such that the clamping point is just above the
the punching tools.
To find these values:
Make a descent with the machine in adjustment mode
DNC in mode.
When the punch reaches its exit point, stop the descent and note the
position of the beam.
Delete the field.
Introduce this value in Y1 Y2.
Regulate the tool reference value as a function of the tools used.
nd:
electrical cabinet for a new
the exit value
d center
adjust the
pressing up of
and the
