A E: T
PPENDIX
P
UNCH
P
ROGRAMMING
T
OOL
PAGE 34 USER GUIDE DNC 600S
P
OOL ROGRAMMING
The DNC 600S has several pages which allow consultation of the list of
existing tools, to display them and / or program new ones.
The DNC 600S memory can hold a maximum of 20 punches and 30 dies.
L
IST
From the main menu choose option LIST OF PUNCHES.
The system displays the list of punches existing in the memory, with
the number and characteristics of each punch:
If your DNC contains more than 4 punches, you can call the following page
or pages by pressing
Die List
From the main menu, choose option LIST OF DIES.
The consultation of the list of dies can be done in the same way as explained
for the punches.
P
UNCHES
P
ROGRAMMING
The programming of tools is done by introducing their values and
dimensions on the page as represented below.
Call the PROGRAMMING PUNCH / DIE page (via the main menu).
p
Hp
rp
TON/M
Vd
.
/ D
IES
O
VERVIEW
Punch angle.
Height of the punch between the lowest part of
the beam and the point of the punch.
Punch radius.
Maximum force supported by the punch per
linear meter.
V width of the die.
