3rd sequence
PAGE 16 USER GUIDE DNC 600S
The following screen is displayed:
P 0 N 3
Th: 2.00
p/d 1/ 1
--MEM--
90.0°
Y1 229.90
Y2 229.90
L 20.00
X 18.00
Lmat 1000
Rx ___
Vy _ _
TDC ___
F1:___ F2:___ F3:___ F4:__ F5:__ Cr: 41
Modify the values which are different for this sequence, in this case
enter 50.0 in the L field (X is automatically calculated) or the value 48
in the X field.
The programming of the product is terminated.
If you wish to save:
Place the cursor on the P field.
( and
Introduce the number you wish to give to this product.
Press (if the system replies EXISTS, choose another number
for saving this product).
The product will be saved in the internal memory with the number
which you have given it.
It will, however, remain present in the work memory.
Pass to semi-automatic mode
Call the sequence 1.
Execute the first bend.
CY __
37.00 Kg/mm²
CR __/ri __.__
--POS--
350.92
351.05
51.85
TON 19
Ext start _
ΔT
_._s
SP ___
to position the cursor on the top of the page.)
.
--COR--
____.__
____.__
____.__
