Zte MF631 Quick Manual

Introduction
The Ncell Connect USB modem is a multi-mode USB modem, working in HSUPA/HSDPA/WCDMA/
EDGE/GPRS/GSM networks. With USB interface connecting to a laptop or a desktop PC, it integrates
the functionality of a modem and a mobile phone (SMS), and combines mobile communication with
Internet perfectly. It supports data and SMS services through the mobile phone network, enabling you
MF631 Quick Guide to communicate anytime and anywhere.
Specification
The following table shows the specification of your device.
Interface Type
Systems supported
Operating systems supported
Functions
Network Standards
Transmission speed (Max)
Temperature
Dimension
Weight
USB 2.0 high speed
microSD capability
Supports most types of laptop and desktop PC.
Notes:
Windows XP, Vista, Windows 7 MAC 10.4 or above
microSD is a trademark of SD Card Association.
SMS service, Data service, Applications management, support
microSD card, etc.
Getting to know your device
HSUPA/HSDPA/WCDMA/EDGE/GPRS/GSM
The following figure shows the appearance of the MF631. It is only for your reference. The actual
HSUPA: 5.76Mbps UL
product may be different.
HSDPA: 7.2Mbps DL
Storage: -40°C ~ +80°C
Operation:-10°C ~ +55°C
76mm×24.5mm×10mm
About 25g
Support up to 32GB microSD card
Hardware Installation
1. Put finger on the bottom finger grip, and then lift the cover of the
modem to release and remove.
Notes: Do not open the cover rudely so as to avoid the damage of the
cover.
2. Insert the SIM/USIM card into the SIM/USIM card slot.
Insert the SIM/USIM card with the metal contact area facing downwards
into the slot, shown as the following picture.
3. Insert the microSD card into the microSD card slot.
1. Indicator
Insert your microSD card into the microSD card slot, shown as the
2. Front Cover
following picture.
3. USB Connector
Notes: This modem only supports microSD card.
4. microSD card slot
5. SIM/USIM card slot
4. Put the cover of the modem flatly upon the body of modem. Direct the
cover towards the locking catches on the sides of the modem and push
the cover of the modem to lock the cover into its place.
