Zte MF83M Quick Manual

Hide thumbs

Advertisement

Table of Contents

ZTE MF83M
Quick Guide
1

Advertisement

Table of Contents
loading

Related Manuals for Zte MF83M

Summary of Contents for Zte MF83M

  • Page 1 ZTE MF83M Quick Guide...

  • Page 2: Legal Information

    No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means, elec- tronic or mechanical, including photocopying and micro- film, without the prior written permission of ZTE Corpora- tion. The manual is published by ZTE Corporation. We reserve the right to make modifications on print errors or update specifications without prior notice.

  • Page 3: Getting To Know Your Device

    Getting to Know Your Device Appearance The following figure is only for your reference. The actual product may be different. 1. LED Indicators 2. Power Button 3. WPS Button 4. Micro USB Port 5. (U)SIM Card Slot 6. microSD Card Slot NOTE: 1.
  • Page 4 Indicators Indicator Status Description Error status. Not registered to the mobile network, no Red solid (U)SIM card inserted or no Network network service available. Registered to the mobile Green solid network. Connected to the mobile Green network and data is being blinking transferred.

  • Page 5: Connection Scenario

    Red solid/ The battery is low. Please blinking charge the battery. Green The battery is being blinking charged. Battery The battery level is middle Green solid or high. Your device is in standby mode and not being LED light off charged, or the battery is not inserted.
  • Page 6 • Internet Wi-Fi Mode: Your device will connect to other WLAN device (hotspot device, wireless router, etc.) via Wi-Fi to access the Internet. The WLAN de- vice has already connected to the Internet. NOTE: The subnets of your device and other WLAN device must be different.

  • Page 7: Installing Your Device

    Installing Your Device 1. Slide the back cover and remove it 2. Insert the (U)SIM card. IMPORTANT: Your device does not support Micro/Nano or any other nonstandard SIM cards. To avoid device damage, please do not use them.
  • Page 8 3. Insert the microSD card if necessary. 4. Insert the battery. 5. Close the back cover.

  • Page 9: Connecting To Your Device

    Connecting to Your Device Via Wi-Fi 1. Power on your device directly. It will take 1~2 minutes to initialize. 2. Use your normal Wi-Fi application on the client to search for the available wireless networks. NOTE: Please set the client to obtain an IP address automatically referring to the chapter “Configuring your PC”, and then the client will get an IP address like “192.168.0.101”.
  • Page 10 3. Select the SSID of your device, and then click Con- nect. NOTE: Please check the label on your device to get the default SSID. 4. Input the password, and then click Connect.

  • Page 11: Via Usb Cable

    NOTE: You may need to input the password for Wi-Fi connection. Please check the label on your device to get the default. 5. Wait a moment, and then the client will connect to your device successfully. Via USB Cable 1. Connect to the device. 2.

  • Page 12: Accessing The Internet

    NOTE: If the system does not launch installation auto- matically, you can run the installation program in path of My Computer > ZTEMODEM. 4. Wait a moment, and then the client will connect to your device successfully. Accessing the Internet 3G Mode After the client connected to your device successfully, you can access the Internet in the Automatic or Manual...
  • Page 13 NOTE: If you want to modify the detailed parameters of your device, please log in the webGUI configuration page by visiting http://192.168.0.1 or http://m.home. The default password is admin. Internet Wi-Fi Mode 1. Log in the webGUI configuration page. 2. Select Settings > Internet Wi-Fi. 3.
  • Page 14 There are two methods for your reference. Input the Wi-Fi device information in the Wi-Fi Setting area, and then click Apply. Click for more help. 5. After the client connected to the Wi-Fi device suc- cessfully, you can access the Internet.

  • Page 15: Configuring Your Pc

    Configuring Your PC Follow the following steps and figures for Windows XP to configure the Internet Protocol for your Wi-Fi connection. 1. Right-click My Network Places, and then select Properties.
  • Page 16 2. Right-click Wireless Network Connection, and then select Properties.
  • Page 17 3. Select Internet Protocol(TCP/IP), and then click Properties.
  • Page 18 4. Select Obtain an IP address automatically and Ob- tain DNS server address automatically, and then click OK to finish the configuration.

  • Page 19: Warning And Notice

    Warning and Notice To the Owner • Some electronic devices are susceptible to electro- magnetic interference sent by your device if inad- equately shielded, such as the electronic system of vehicles. Please consult the manufacturer of your device before using if necessary. •...

  • Page 20: Using Your Device

    • The use of electronic transmitting devices is forbidden in aircrafts, at petrol stations and in hospitals. Please observe and obey all warning signs and switch off your device in these conditions. • Do not touch the inner antenna area if not necessary. Otherwise it will affect your device’s performance.

  • Page 21: Using Battery

    • Do not use your device immediately after a sudden temperature change. In such case, it will produce dew inside and outside your device, so don’t use it until it becomes dry. • Handle your device carefully. Do not drop, bend or strike it.

  • Page 22: Limited Warranty

    End User’s failure to follow ZTE’s installation, operation or maintenance instructions or proce- dures. iii. End User’s mishandling, misuse, negligence, or improper installation, disassembly, storage, ser- vicing or operation of the Product. iv. Modifications or repairs not made by ZTE or a ZTE-certified individual.
  • Page 23 Any other cause beyond the range of normal us- age intended for the Product. End User shall have no right to reject or return the Prod- uct, or receive a refund for the Product from ZTE under the above-mentioned situations. •...

  • Page 24: Limitation Of Liability

    Limitation of Liability ZTE shall not be liable for any loss of profits or indirect, special, incidental or consequential damages resulting from or arising out of or in connection with using of this product, whether or not ZTE had been advised, knew or...

  • Page 25: Troubleshooting

    device when tested was 0.819 W/kg. As mobile devices offer a range of functions, they can be used in other posi- tions, such as on the body. As SAR is measured utilizing the device’s highest trans- mitting power, the actual SAR of this device while operat- ing is typically below that indicated above.
  • Page 26 • Make sure the Wi-Fi function is ac- tive. • Refresh network list and select the Can not es- correct SSID. tablish the • Check the IP address to make sure Wi-Fi connec- your client can obtain an IP address tion between automatically in the Internet protocol your device...
  • Page 27 When I use • Make sure the other WLAN device AP Station has already connected to the Inter- mode, the net. client cannot • Make sure that the subnet of your access the device and the other WLAN device is Internet.
  • Page 28 For more assistance, please: Send E-mail to mobile@zte.com.cn • • Visit http: //www.ztedevice.com. • Call Service Hotline: +86–755–26779999 ZTE CORPORATION NO. 55, Hi-tech Road South, ShenZhen, P.R.China Postcode: 518057...
