Makita JS1300 Instructions Manual
Straight shear
Hide thumbs
Also See for JS1300:
- Instruction manual (21 pages) ,
- Instruction manual (8 pages) ,
- Instruction manual (16 pages)
Advertisement
Table of Contents
SPECIFICATIONS
Model
Max. cutting capacities
Steel up to 400 N/mm
Steel up to 600 N/mm
Steel up to 800 N/mm
Aluminium up to 200 N/mm
Strokes per minute ............................................................................................................................. 0 – 2,500
Overall length ....................................................................................................................................... 302 mm
Net weight ................................................................................................................................................ 1.7 kg
• Due to our continuing program of research and development, the specifications herein are subject to change
without notice.
• Note: Specifications may differ from country to country.
Power supply
The tool should be connected only to a power supply of the same voltage as indicated on the nameplate, and
can only be operated on single-phase AC supply. They are double-insulated in accordance with European
Standard and can, therefore, also be used from sockets without earth wire.
2
........................................................................................................................ 1.3 mm
2
........................................................................................................................ 1.0 mm
2
........................................................................................................................ 0.5 mm
2
............................................................................................................... 2.5 mm
Straight Shear
JS1300
JS1300
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Makita JS1300
Summary of Contents for Makita JS1300
- Page 1 Straight Shear JS1300 SPECIFICATIONS Model JS1300 Max. cutting capacities Steel up to 400 N/mm ........................1.3 mm Steel up to 600 N/mm ........................1.0 mm Steel up to 800 N/mm ........................0.5 mm Aluminium up to 200 N/mm ....................... 2.5 mm Strokes per minute ..........................
- Page 3 Symbols The following show the symbols used for the tool. Be sure that you understand their meaning before use. [ Read instruction manual. [ DOUBLE INSULATION...
-
Page 4: Safety Instructions
ENGLISH Explanation of general view 1 Switch trigger 6 Loosen 11 Sleeve 2 Lock button 7 Hex wrench 12 Tighten 3 Hook 8 Side blade L 13 Side blade surface 4 Cutting head 9 Center blade 14 Side blades 5 Screws 10 Side blade R 15 Workpiece SAFETY INSTRUCTIONS... -
Page 5: Additional Safety Rules
To maintain product safety and reliability, repairs, • Never remove the blades with bare hands. Wear maintenance or adjustment should be carried out by a gloves. Otherwise it can cause injury. Makita Authorized Service Center. - Page 8 Made in Japan 884341-0...
