  • Page 1 MCP1630 Automotive Input Triple Output Converter Demo Board User’s Guide © 2006 Microchip Technology Inc. DS51627A...
  • Page 2 Endurance, UNI/O, WiperLock and ZENA are trademarks of Microchip Technology Incorporated in the U.S.A. and other countries. SQTP is a service mark of Microchip Technology Incorporated in the U.S.A. All other trademarks mentioned herein are property of their respective companies.

  • Page 3: Table Of Contents

    Document Revision History ................... 3 Chapter 1. Product Overview ..................5 1.1 Introduction ..................... 5 1.2 What is the MCP1630 Automotive Input Triple Output Converter Demo Board? ................... 6 1.3 What the MCP1630 Automotive Input Triple Output Converter Demo Board kit includes ................6 Chapter 2.
  • Page 4 MCP1630 Automotive Input Triple Output Converter Demo Board User’s Guide NOTES: © 2006 Microchip Technology Inc. DS51627A-page iv...

  • Page 5: Preface

    • Customer Support • Document Revision History DOCUMENT LAYOUT This document describes how to use the MCP1630 Automotive Input Triple Output Converter Demo Board. The manual layout is as follows: • Chapter 1. “Product Overview” – Important information about the MCP1630 Automotive Input Triple Output Converter Demo Board.

  • Page 6: Conventions Used In This Guide

    { | } arguments; an OR selection RECOMMENDED READING This user's guide describes how to use MCP1630 Automotive Input Triple Output Con- verter Demo Board. The following Microchip documents are available on our web site (www.microchip.com) and recommended as supplemental reference resources.

  • Page 7: The Microchip Web Site

    Technical support is available through the web site at: http://support.microchip.com DOCUMENT REVISION HISTORY Revision A (September 2006) • Initial Release of this Document. © 2006 Microchip Technology Inc. DS51627A-page 3...
  • Page 8 MCP1630 Automotive Input Triple Output Converter Demo Board User’s Guide NOTES: © 2006 Microchip Technology Inc. DS51627A-page 4...

  • Page 9: Chapter 1. Product Overview

    Line, Load and Cross regulation for the three outputs. This chapter covers the following topics. • What is the MCP1630 Automotive Input Triple Output Converter Demo Board? • What the MCP1630 Automotive Input Triple Output Converter Demo Board Kit includes.

  • Page 10: What Is The Mcp1630 Automotive Input Triple Output Converter Demo Board

    SEPIC topology for Automotive applications. The board also serves as a platform to evaluate the MCP1630 device. The MCP1630 inputs were developed to be easily attached to the I/O of a MCU. The MCU supplies the oscillator pulses and reference voltage (V ) to the MCP1630 to provide the most flexible and adaptable power system.

  • Page 11: Chapter 2. Installation And Operation

    The MCP1630 Automotive Input Triple Output Converter Demo Board demonstrates Microchip's high speed pulse width modulator (PWM) used for Automotive application. When used in conjunction with a microcontroller, the MCP1630 will control the power system duty cycle to provide regulated output voltage. The PIC12F683 microcontroller is used to provide oscillator pulses at switching frequency of 250 kHz and set maximum duty cycle.

  • Page 12: Getting Started

    (<0.1 uA) until the SW1 push button is pressed by the user. 2. Once the SW1 push button is pressed, the MCP1630 Automotive Input Triple Output Converter Demo Board is powered on delivering the three output volt- ages of 3.3V at 1.2A (Maximum current), 1.2V at 600 mA (Maximum current) and...
  • Page 13 6.5V to 40V and checking the output voltage, the line regulation can be calculated. Evaluating the Application The best way to evaluate the MCP1630 Automotive Input Triple Output Converter Demo Board is to dig into the circuit. Measure voltages and currents with a DVM and probe the board with an oscilloscope.
  • Page 14 MCP1630 Automotive Input Triple Output Converter Demo Board User’s Guide Programming Header J1 is provided for in-circuit programming. This is an optional feature since the demo board comes preprogrammed with firmware to operate the system. The PIC12F683 can be reprogrammed with the Baseline Flash Microcontroller Programmer (BFMP) ©...

  • Page 15: Appendix A. Schematic And Layouts

    TRIPLE OUTPUT CONVERTER DEMO BOARD USER’S GUIDE Appendix A. Schematic and Layouts INTRODUCTION This appendix contains the following schematics and layouts for the MCP1630 Auto- motive Input Triple Output Converter Demo Board: • Board – Schematic • Board – Top Silk Layer •...

  • Page 16: Board - Schematic

    MCP1630 Automotive Input Triple Output Converter Demo Board User’s Guide BOARD – SCHEMATIC © 2006 Microchip Technology Inc. DS51627A-page 12...

  • Page 17: Board - Top Silk Layer

    Schematic and Layouts BOARD – TOP SILK LAYER © 2006 Microchip Technology Inc. DS51627A-page 13...

  • Page 18: Board - Top Metal Layer

    MCP1630 Automotive Input Triple Output Converter Demo Board User’s Guide BOARD – TOP METAL LAYER © 2006 Microchip Technology Inc. DS51627A-page 14...

  • Page 19: Board - Bottom Metal Layer

    Schematic and Layouts BOARD – BOTTOM METAL LAYER © 2006 Microchip Technology Inc. DS51627A-page 15...
  • Page 20 MCP1630 Automotive Input Triple Output Converter Demo Board User’s Guide NOTES: © 2006 Microchip Technology Inc. DS51627A-page 16...

  • Page 21: Appendix B. Bill Of Materials (Bom)

    Switch Tact 6MM 260GF SMT E-Switch TL3301NF260QG Note 1: The components listed in this Bill of Materials are representative of the PCB assembly. The released BOM used in manufacturing uses all RoHS-compliant components. © 2006 Microchip Technology Inc. DS51627A-page 17...
  • Page 22 MCP1630 Automotive Input Triple Output Converter Demo Board User’s Guide TABLE B-1: BILL OF MATERIALS (BOM) (CONTINUED) Reference Description Manufacturer Part Number ® TP1,TP2,TP3,T PC Test point compact SMT Keystone Electronics 5016 P4,TP5,TP6,TP 7,TP8 Inductor / Transformer 5.7uH SMD Coiltronics/Div of...

  • Page 23: Appendix C. Demo Board Firmware

    DEMO BOARD USER’S GUIDE Appendix C. Demo Board Firmware DEVICE FIRMWARE For the latest version of the MCP1630 Automotive Input Triple Output Converter Demo Board firmware, visit our web site at www.microchip.com. START Initialize Registers and Osc Clock to 8 MHz Configure GPIO<3>...

  • Page 24: Worldwide Sales And Service

    China - Wuhan Thailand - Bangkok Tel: 408-961-6444 Tel: 86-27-5980-5300 Tel: 66-2-694-1351 Fax: 408-961-6445 Fax: 86-27-5980-5118 Fax: 66-2-694-1350 Toronto China - Xian Mississauga, Ontario, Tel: 86-29-8833-7250 Canada Fax: 86-29-8833-7256 Tel: 905-673-0699 Fax: 905-673-6509 08/29/06 © 2006 Microchip Technology Inc. DS51627A-page 20...
