Page 1 Low Speed Handpiece for Apex Locator OTR Module Operation Instructions ROOT ZX II OTR Module must be connected to ROOT ZX II Canal Measurement Module, which is sold separately. This unit cannot be used as an independent unit. This manual is for the OTR Module.
Page 3 (7) Fires, earthquakes, floods, lightning, natural disasters, or acts of God. • The useful life of the ROOT ZX II OTR Module is 6 years (based on self-certification) from the date of shipment provided it is regularly and properly inspected and maintained.
Page 4: Table Of Contents
Table of Contents Page Prevent Accidents ............................... 1 1. Parts Identification ............................3 2. Assembling the Unit ............................5 Attaching OTR Module to Canal Measurement Module................5 Charging Battery ............................6 3. Before Using the Unit ............................. 7 Handpiece Cord ............................7 Assembling Micromotor ..........................
Page 5: Prevent Accidents
Caution: Federal law restricts this device to sale by or on the order of a dentist. (for U.S.A.) In Case of Accident If an accident occurs, the ROOT ZX II OTR Module must not be used until repairs have been completed by a qualified and trained technician authorized by the manufacturer.
Page 6 • Portable and mobile RF communications equipment can affect the ROOT ZX II. • The ROOT ZX II should not be used adjacent to or stacked with other equipment and that if adjacent or stacked use is necessary, the ROOT ZX II should be observed to verify normal operation in the configuration in which it will be used.
Page 7: Parts Identification
1. Parts Identification OTR Module is used as a low voltage motor and as a base unit for other electronic dental devices. OTR Module Canal Measurement Module (Sold separately) AC Adapter Liquid Crystal Display Handpiece Cord Cord Clips Micromotor Contra Angle Contrary Electrode Foot Switch (Canal Measurement Module accessory)
Page 8 Components OTR Module (1) Battery (1) AC Adapter (Pre-installed in OTR Module) Handpiece Cord (1) Contra Angle (1) Built-in Electrode (1) (Pre-installed in Contra Angle) Micromotor (1) Handpiece Rest (1) Guide Bar (1) Plastic Sleeve (20) LS Oil (1) Foot Switch (1) Cap with External File Electrode (Sold Separately) Operation 2018-06-21...
Page 9: Assembling The Unit
2. Assembling the Unit * OTR Module will not operate unless connected to Canal Measurement Module. Attaching OTR Module to Canal Measurement Module 1. Hold the cover and slide the stopper on the bottom towards the liquid crystal display. Canal Measurement Module Cover Stopper Cover...
Page 10: Charging Battery
• If the plug for the AC adapter does not fit the electrical power receptacle, it is the user’s responsibility to find a suitable plug adapter. • Use only the AC adapter made for ROOT ZX II. 1. Line up the arrow on the AC adapter’s connector with the OTR Module small triangle above its jack on the side of OTR Module and plug it in.
Page 11: Before Using The Unit
3. Before Using the Unit Handpiece Cord 1. Line up the arrow on the handpiece cord’s plug with the Handpiece Cord Plug little triangle above its jack and plug it all the way in until the arrow disappears inside the jack. •...
Page 12: Assembling Micromotor
Assembling Micromotor * Contra angle must be lubricated with the LS Oil before using for the first time. See “ 6. Maintenance ” on page 32. Micromotor 1. Line up the dots on the micromotor and contra angle and slide the contra angle straight onto the micromotor until it clicks Dots (●) Contra Angle...
Page 13: Assembling File
Assembling File * Use only nickel-titanium files for root canal preparation. • Never use stretched, deformed or damaged files. 1. Hold down the file release button on the contra angle and insert the file. Turn the file back and forth until it is lined up with interior latch groove and slips into place.
Page 14: Attaching Foot Switch
Attaching Foot Switch Insert the foot switch plug all the way into its jack on the side of Foot Switch Plug OTR Module. [This jack is marked with a small triangle (►) pointing right.] • Always hold the connector to connect or disconnect cords. * Operate the handpiece with the foot switch if a canal cannot be accurately measured.
Page 15: Checking The Function
• Check the ROOT ZX II’s operation before each patient. If the indicators in the display do not all appear normally, the File Holder Contact instrument may not be able to make an accurate measurement.
Page 16: Operating The Unit
4. Operating the Unit • If there is a lightning storm while the battery is being charged, do not touch the main unit, the AC adapter or the main power cord; you could get a shock. • Stop using the instrument and have it repaired if the display does not appear properly or if the instrument suddenly turns off (except in the case where it automatically turns itself off after 10 minutes of not being used).
Page 17: Normal Mode
<Normal Mode> If the file torque is less than the set value, the file will keep rotating in the forward direction. When the file torque is more than the set value, the file will automatically start rotating in reverse direction. Furthermore, the Normal mode can set various motor controls as described below.
Page 18: Root Canal Measurement (Two Methods)
Root Canal Measurement (Two Methods) Plug the probe cord into Canal Measurement Module and connect the file holder and contrary electrode. Probe Cord Plug a: Detach the micromotor from handpiece cord. Select M1, M2 or M3 with pressing the MODE switch and measure length of a root canal.
Page 19: Preparing The Root Canal
Preparing the Root Canal Plug the handpiece cord into OTR Module and then connect the handpiece and the contra angle. Handpiece Cord Plug Press the MODE switch to select M1, M2, or M3, and then perform root canal Preparing. • Make sure that the contrary electrode, file holder, handpiece file electrode etc.
Page 20: Liquid Crystal Display And Switches
Liquid Crystal Display and Switches <OTR Mode> Battery Power Indicator Shows how much power is left. Canal Length Indicator Bar • Charge the battery as soon as the Torque Line indicator gets down to the last two bars. • Never use the unit when the battery If the file torque is more than the set Sound Volume power display is flashing.
Page 21: Torque Settings
Torque Settings • If the torque setting is too high, the file could jam inside the canal. • The torque settings must be changed depending on the root canal condition. • When the auto torque reverse seems to be triggered too frequently, or it is triggered immediately after starting the normal rotation, increase the torque setting by one line.
Page 22: Normal Mode
<Normal Mode> Battery Power Indicator Shows how much power is left. Motor Stopping Time for • Charge the battery as soon as the indicator Apical Reverse gets down to the last two bars. • 0, 0.25 ( ), 0.5 ( ), and 1 ( Never use the unit when the battery power second.
Page 23: Torque Settings
Torque Settings • If the torque limit is too high, the file could get jammed in the canal. In this case, set the micromotor for reverse rotation to free the file. (See page 27, “Reverse Rotation”) • When the torque reverse function is turned off, the file could be engaged in the root canal and lock up. When this happens, set the micromotor for reverse rotation to free the file.
Page 24: Setting Memories For Other Functions
Setting Memories for Other Functions <OTR Mode> To change the settings other than Torque Line, Apical Line or Rotation Speed, take the following steps. 1. Turn the power off. 2. Press the SELECT switch and turn the power back on without releasing the SELECT switch. 3.
Page 25: Normal Mode
<Normal Mode> To change the settings other than Torque Line, Apical Line or Rotation Speed, take the following steps. 1. Turn the power off. 2. Press the SELECT switch and turn the power back on without releasing the SELECT switch. 3.
Page 26: Meter Display
Factory Settings for Memories Memory Item Mode OTR Mode OTR Mode Normal Mode Speed (rpm) Torque Meter Display The position of the file tip is shown by the root canal length indicator bar on the display. The apical line flashes on and off once file is inserted into the root canal.
Page 27: Operating The Micromotor
Operating the Micromotor 1. Hook the contrary electrode in the corner of the patient's mouth. Corner Corner of mouth mouth Contrary Contrary • Do not use an ultrasonic scaler with the contrary electrode electrode Electrode attached to the patient. This is dangerous because electrical noise from the scaler could interfere with canal measurements and motor operation.
Page 28 3. The file will automatically start to rotate when it is inserted into the root canal (Auto Start)*. If the root canal is extremely dry, the auto start function may not operate. • If the auto start function does not work because the root canal is too dry (infected canal etc.), moisten the canal with a liquid such as hydrogen peroxide, sodium hypochlorite or saline.
Page 29 Then hook the contrary electrode back in the corner of the patient’s mouth to start the file rotating. * Electrical noise will cause the motor to stop and automatically put ROOT ZX II into the root canal measurement mode, which is the safest mode. However, it will return to normal operation when the file is taken out of the root canal.
Page 30: Manual Mode Using The Foot Switch
• Nickel-Titanium files are more easily broken by the amount of torque applied to them than stainless steel files. Keep the following points in mind to minimize the possibility of file breakage. • Before using micromotor, use a small hand file, such as #10 or #15, to penetrate the root canal manually down to apex and then return to the apical constriction.
Page 31: Manual Mode Using The Operation Switches
Manual Mode Using the Operation Switches Forward Rotation With the file outside the canal and the motor stopped, hold down the Set switch and then press the MODE switch. (Do not reverse the switch order; this would go into the Memory function.) The file will rotate forwards at the specified speed.
Page 32: Replace Buit-In Electrode With Cap With External File Electrode
Replace Buit-in Electrode with Cap with External File Electrode If there is no electrical conductivity between the file and its shank, replace the cap with the one that has an external file electrode (sold Built-in separately). Electrode (1) Loosen the screw and take off the built-in electrode. Screw (2) Hold the push button and slide the guide bar straight in as shown in the illustration.
Page 33 (6) Hold the push button down and turn the file back and forth until is lines up with the notch and goes all the way in. Release the button to secure it. • Make sure the file goes all the way in. Give it a light tug to make sure it is held securely.
Page 34: After Using The Unit
• Use only the AC adapter made for ROOT ZX II. * The micromotor will still operate when the battery power indicator bar goes down to one line and starts flashing.
Page 35 • If [F.02] appears in the display, noise has been detected. Turn the unit off and then back on again. If [F.02] still appears, stop using the unit and contact your local dealer or J. MORITA OFFICE. 3. Amber Charge LED goes out when the battery is fully charged.
Page 36: Maintenance
6. Maintenance There are 4 ways to clean and disinfect components depending on the component. Be sure to follow the procedure below when performing daily maintenance. • Be careful to avoid cross contamination when performing maintenance. a. Autoclavable Components • Components maintained this way: Contra Angle Handpiece Rest •...
Page 37 3. Use a threeway syringe etc. to blow out any moisture remaining inside the contra angle. • Check to see if the contra angle, including its inside, is completely dry. If any water remains inside the component, expel it with an air gun or another such tool. Failure to do so could result in the remaining water coming out during use and cause malfunction, or poor lubrication and sterilization.
Page 38 * Using the MORITA MULTI SPRAY or LS SPRAY instead of the LS Oil will promote even better performance for the contra angle. For details, contact your local dealer or J. MORITA OFFICE.
Page 39 ■ Packing Put components in individual autoclave pouches. ■ Sterilization Autoclave the components after use for each patient. Sterilizer Type: Gravity Recommended Temperature and Time: In a sterilization pouch, 15 minutes at 132°C (269.6°F) or 30 minutes at 121°C (249.8°F) Drying Time after Sterilization: 15 minutes •...
Page 40 b. Non-Autoclavable Components: Wipe with Ethanol • Components maintained this way: Motor Handpiece Handpiece Cord Procedure: Disinfection ■ Disinfection Wipe the components with a piece of gauze dampened with Ethanol for Disinfection (Ethanol 70 vol% to 80 vol%). • Do not use anything except Ethanol for Disinfection (Ethanol 70 vol% to 80 vol%). Do not use too much ethanol as it could seep inside and damage the components.
Page 41 c. Non-Autoclavable Components: Wash and then Wipe with Ethanol • Components maintained this way: Guide Bar Procedure: Cleaning Disinfection ■ Cleaning Clean off the cutting debris in running water with a soft brush and then wipe off the water. • Do not clean the component with an ultrasonic cleaning device.
Page 42 d. Non-Autoclavable Components: Wipe with Neutral Detergent and Moistened Cloth • Components maintained this way: AC Adapter Foot Switch OTR Module Procedure: Cleaning To clean the surfaces of the components, use a soft cloth to apply a little neutral detergent, and then rinse them with a cloth moistened with water.
Page 43 Rotor Axle and Built-in Electrode Cleaning Procedure * If the bars flicker during use, or if all the bars in the meter do not light up when the file touches the contrary electrode, clean the rotor axle and the built-in electrode in the following way. 1.
Page 44 6. Slide the built-in electrode onto the guide bar and line up the screw holes. 7. Slowly turn the screw and make sure the built-in electrode goes into the head properly. 8. Tighten the screw up securely and then hold down the push button and pull out the guide bar.
Page 45: Replacement Parts, Transportation And Storage
7. Replacement Parts, Transportation and Storage * Replace the parts as necessary depending on degree of wear and length of use. * Order replacement parts from your local dealer or J. MORITA OFFICE. Replace the Built-In Electrode • If the bars flicker during use, or if all the bars in the meter do not light up when the file touches the contrary electrode, and cleaning the rotor axle and built-in electrode does not solve this problem, then the built-in electrode is worn out and must be replaced with a new one according to the following procedure.
Page 46: Replacing The Battery
Battery Cover ZX II OTR Module. * This battery can be ordered from your local dealer or from J. MORITA OFFICE. 1. Turn power off. 2. Slide the battery cover off the back of OTR Module in the direction indicated by the arrow in the illustration.
Page 47: Inspection
8. Inspection Regular Inspection * This instrument should be inspected every 6 months in accordance with the following maintenance and inspection items. Maintenance and Inspection Items 1. Check that the battery does not seem to be losing its charge too quickly. 2.
Page 48: Troubleshooting
If the instrument does not seem to be working properly, the user should first try to inspect and adjust it himself. * If the user is unable to inspect the instrument himself or if the instrument fails to work properly after being adjusted or after parts are replaced, contact your local dealer or J. MORITA OFFICE. Problem...
Page 49 Error Codes There may be something wrong with the instrument if any of the following error codes appear. If any of these appear repeatedly, contact your local dealer or J. MORITA OFFICE for repairs. Module Code*...
Page 50: Replacement Parts List
10. Replacement Parts List Description Description Built-in Electrode Micromotor Battery Handpiece Cord LS Oil Foot Switch Contra Angle Handpiece Rest Guide Bar Plastic Sleeve (500) AC Adapter (120V) Cap with External File Electrode Operation 2018-06-21...
Page 51: Technical Specifications
11. Technical Specifications * Specifications may be changed without notice due to improvements. Specifications Main Unit Model DP-ZX-VL Type TR-EX Intended Use The DP-ZX-VL device is a endodontic treatment motorized handpiece with root canal measurement capability. It can be used to enlarge the canals while monitoring the position of the file tip inside the canal.
Page 52: Symbols
Symbols * Some symbols may not be used. Manufacturer Date of manufacture Direct current Serial number Connector for the foot switch cord Connector for the handpiece cord CE(0197) marking Conforms with the European Directive, Authorized representative in the 93/42/EEC. European Community CE marking Conforms with the European Directive, 2011/65/EU.
Page 53: Operating, Transport And Storage Environments For The Main Unit And Ac Adapter
The ROOT ZX II may be repaired and serviced by: • The technicians of J. MORITA’s subsidiaries all over the world. • Technicians employed by authorized J. MORITA dealers and specially trained by J. MORITA. • Independent technicians specially trained and authorized by J. MORITA.
Page 54: Electromagnetic Declaration
EMC information provided in the ACCOMPANYING DOCUMENTS. • Portable and mobile RF communications equipment can affect the DP-ZX-VL. • Use of parts other than those accompanied or specified by J. MORITA MFG. CORP. may result in increased EMC emissions or decreased EMC immunity of the DP-ZX-VL.
Page 55 Guidance and Manufacturer’s Declaration – Electromagnetic Immunity The DP-ZX-VL is intended for use in the electromagnetic environment specified below. The customer or the user of the DP-ZX-VL should assure that it is used in such an environment. Electromagnetic Environment - Immunity Test IEC 60601 Test Level Compliance Level...
Page 56 Guidance and Manufacturer’s Declaration – Electromagnetic Immunity The DP-ZX-VL is intended for use in the electromagnetic environment specified below. The customer or the user of the DP-ZX-VL should assure that it is used in such an environment. IEC 60601 Test Compliance Immunity Test Electromagnetic Environment –...
Page 57: Essential Performance
Length Handpiece Cord Foot Switch 1.5 meters 1.4 meters • Use of the parts other than those accompanied or specified by J. MORITA MFG. CORP. may result in increased EMC emissions or decreased EMC immunity of the DP-ZX-VL. Operation 2018-06-21...
Page 58: Warranty
13. Warranty 1 Year Limited Warranty 1. The manufacturer gives a worldwide guarantee for one year beginning from the date of purchase. Within this period any defect that is due to faulty manufacturer or material will be remedied by repair or replacement at the judgment of the manufacturing or its distributor.
Page 60 Pub. No.: M8126-EN-USA-3 Printed in Japan...
