RIOTEC LS6307 USB Programming Quick Manual

P r o g r a m m i n g Q u i c k G u i d e
-LS6307 USB (HID)

Installation

Make sure that the scanner has the correct cable to plug
in the PC as below described:

Reset Configuration to Defaults

If you are unsure of the scanner configuration or have
scanned the incorrect codes, please scan the following
3 barcodes. This will reset the scanner to its factory
defaults settings.
** Code Programming ON
(Pro CMD : 0006010)

Load Factory Default

(Pro CMD : 0001160)
** Code Programming OFF
(Pro CMD : 0006000)

Keyboard Country

Scan the appropriate country code below to program
the keyboard for your country or language. As a
general rule, the following characters are not
supported by the scanner for countries other than the
United States: @ | $ # { } [ ] = / ' \ < > ~
Follow the steps mentioned below to program.
1. "Code Programming ON"
2. "Select Country Code"
3. Read digit codes (according to country code)
4. "Save "
5. "Code Programming OFF"
** Code Programming ON ** Code Programming OFF
(Pro CMD : 0006010)
Select Country Code
( Pro CMD : 1103000 )
Country/Language Number Country/Language
U.S. 0 Netherlands(Dutch)
Belgium 1 Norway
2
Brazil Poland
Canada(French) 3 Portugal
Czech 4 Romania
Denmark 5 Russia
Finland(Swedish) 6 Slovakia
7
France Spain
Germany/Austria 8 Sweden
Greece 9 Switzerland(German)
10
Hungary Turkey F
Israel(Hebrew) 11 Turkey Q
12
Italy U.K
Latin-American 13 Japan
It is must to be read "save" after read "digit code".
0
(Pro CMD : 0000000 )
1
(Pro CMD : 0000010 )
(Pro CMD : 0006000)
(Pro CMD : 0000040 )
Save
(Pro CMD：0000160)
Number
(Pro CMD : 0000050 )
14
15
16
17
(Pro CMD : 0000060 )
18

Barcode Configuration Method:

19
(Flow chart for setup procedure :)
21
22
23
24
25
26
27
28
Start Configuration
** Code Programming ON
2
(Pro CMD : 0006010)
(Pro CMD : 0000020 )
Trigger Mode
3
Pro CMD : 0302000
(Pro CMD : 0000030 )
4 7
(Pro CMD : 0000070 )
5 8
(Pro CMD : 0000080 )
6 9
(Pro CMD : 0000090 )
End Configuration
** Code Programming OFF
(Pro CMD : 0006000)
READING
Auto-Sensing
MODE
Pro CMD : 0302010
