Yealink SIP-T20P Quick Installation Manual

Configuring your Phone
Configuring via web user interface
Accessing the web user interface:
1. Press the OK key when the phone is idle to get the IP address of your phone.
2. Open the web browser of your computer, enter the IP address into the address bar (e.g.
"http://192.168.0.10" or "192.168.0.10") and click Enter.
3. Enter the user name (default: admin) and password (default: admin) in the pop-up dialogue
box and click OK.
Note: Please locate your computer in the same network segment of the IP phone (192.168.0.X) to access the
web user interface. Contact your system administrator for more information.
Network Settings: Click on Network->Internet Port(WAN)
You can configure the network settings in the following ways:
DHCP: By default, the phone attempts to contact a DHCP server in your network in order to obtain
its valid network settings, e.g. IP address, subnet mask, gateway, DNS server.
Static IP Address: If your phone can not contact a DHCP server for any reason, you need to
configure IP address, subnet mask, gateway, primary DNS and secondary DNS
for the phone manually.
PPPoE: If you are using an xDSL modem, you can connect your phone to the Internet via PPPoE
mode. Contact the ITSP for the account and password.
Note: The wrong network settings may result in inaccessibility of your phone and may have an impact on the
network performance. Contact your system administrator for more information.
Account Settings: Click on Account->Account X (X=1,2)
Parameters of the account:
It shows the register status of the current account.
Accounts Status:
You can select On/Off to enable/disable the account.
Account Active:
It is shown on the LCD to identify the account.
Label:
It is shown as Caller ID when placing a call.
Display Name:
It is provided by ITSP for registration (required).
User Name:
It is authenticated ID for authentication provided by ITSP (required).
Register Name:
It is provided by ITSP for registration (required).
Password:
SIP Server: It is provided by ITSP for registration (required).
Note: Check with your system administrator if any error appears during the registration process or if a specific
configuration is required for your registration.
Configuring via phone user interface
Network Settings:
Press the MENU key when the phone is idle, select Settings->Advanced->Network->WAN Port/
PC Port/VLAN/Web Type/802.1x Settings to configure the network settings.
Account Settings:
Press the MENU key when the phone is idle, select Settings->Advanced->Accounts to configure the
account settings.
Note: Contact your system administrator for the password for Advanced.
Refer to "Configuring via web user interface" for the parameter informantion.
For more information, refer to the User Guide available online at: http://www.yealink.com/index.php/Support/
c
Copyright 2011 YEALINK NETWORK TECHNOLOGY CO.,LTD.
Enterprise IP Phone
Quick Installation Guide
www.yealink.com
SIP-T20P
(V61.0)
