• Continue to swing the top half upward. This will release the tabs holding the
top half in place.
• Pull the control wires through the large opening in the base plate.
• Position the base plate on the wall and attach it with appropriate fasteners
(two screws with drywall anchors are supplied). The base plate should be
visibly level.
• Block any holes where wires are pulled through a wall opening. This will
prevent drafts from entering the back of the thermostat.
If this installation will be using ModBus controls or remote sensors, be certain to
include the proper wires to make those connections.
Do not use
these holes for
mounting.
Figure 2
