HDE-8C DIN SERIES
STEP 1 - Connect the Inputs
HD Device
HD Device
#1
#2
HD MPEG-2 Encoding
DOLBY
Digital Audio Encoding
®
Possible
Sources
INPUT #1 - INPUT #8
PC with web browser
www.blondertongue.com
QUICK GUIDE
8xDIN (Component)
(8 HD Programs Total)
(8 HD Programs)
Stk#
3701
See next page
for DIN cable
information
IP=172.16.70.1
HD Device
#8
8xIP*
4xQAM
• Connect the unit as pictured here
• Power up the encoder.
P/N:651245800A
EAS
* Stk# 6371 QIP Only
Connect 40dB
of attenuation
Stock #6371 QIP | #6371 Q
v20180523
Advertisement
Table of Contents
Related Manuals for Blonder tongue HDE-8C DIN SERIES
Summary of Contents for Blonder tongue HDE-8C DIN SERIES
- Page 1 HDE-8C DIN SERIES QUICK GUIDE STEP 1 - Connect the Inputs 8xDIN (Component) HD Device HD Device HD Device (8 HD Programs Total) HD MPEG-2 Encoding (8 HD Programs) * Stk# 6371 QIP Only DOLBY Digital Audio Encoding ® 8xIP* 4xQAM •...
- Page 2 Stock # 3701 - H258C DIN to RCA Cable: STEP 3 - Login • Log in to the HDE-8C DIN Series encoder, using a standard web browser. • This can be done through the Control 10/100 port, next to the Receiver Control port. Either go directly from a computer or through an Ethernet switch •...
- Page 3 STEP 4 - TS Configuration Go to the Main > Output > TS Config Tab Verify the Multiplexed MPTS Output default settings are suitable for your application - TS bitrate = QAM Modulator - Modulation Mode = QAM 256 - Out of band = disabled Verify the Output Mapping Section.
- Page 4 STEP 6 - Configure QAM Output Setup the QAM output channels by going to the Main > Output > QAM tab Select the channel for the 1st QAM. The next 3 will be automatically assigned. Ensure all outputs are on and CW mode is not enabled. Click “SAVE”...
