Airlink101 AKVM-2UDA Quick Installation Manual page 2

Hotkey sequence = [ScrLk]
Command
2
Select PC Channel
(Joint-select PC port/hub port control/audio&mic,
if binding is enabled)
2
Select Hub Port Control
(Joint-select PC & Hub port control, if binding is
enabled)
3
Select Audio&Mic Channel
(Joint-select PC port & audio/mic , if binding is
enabled)
Bind PC & Hub Port Control Switching
[Default]
Unbind PC & Hub Port Control Switching
3
Bind PC & Audio/Mic Switching
[Default]
Unbind PC & Audio/Mic Switching
2
Next lower PC channel
(Joint-select PC /hub port control/audio&mic,
if binding is enabled)
2
Next higher PC channel
(Joint-select PC /hub port control/audio&mic,
if binding is enabled)
Previous PC channel
Beep Sound On/Off
Define Hotkey Preceding Sequence
Autoscan
Autoscan with Programmable Delay Time
Stop Autoscan
Notes:
1. The USB keyboard hotkeys allows you a faster and broader control for your KVM switching operation in addition to the front-panel buttons. If you have configured a hotkey preceding sequence other than
two consecutive scroll locks, you should change your hotkey sequence accordingly.
2. When the binding of PC & USB hub port control switching is enabled by the hotkey sequence: ScrLk + ScrLk + Z, any PC and hub port control switching are bound together. To remove this binding, use the
hotkey sequence: ScrLk + ScrLk + X.
3. When the binding of PC & Audio&Mic switching is enabled by the hotkey sequence: ScrLk + ScrLk + Q, any PC and audio&mic switching are bound together. To remove this binding, use the hotkey sequence:
ScrLk + ScrLk + W.
Q u i c k
+ [ScrLk] + Command key(s)
* *
Hotkeys
1
ScrLk + ScrLk + (x)
(x is a top-row number key)
x = 1~2 for PC channel no
ScrLk + ScrLk + (Fx)
Fx = F1~F2 (Fx is a function key)
x = 1~2 for PC channel no
ScrLk + ScrLk + (Fy)
Fy = F5~F6 (Fy is a function key)
y = 1~2 for audio/mic channel no
2
ScrLk + ScrLk + Z
2
ScrLk + ScrLk + X
ScrLk + ScrLk + Q
3
ScrLk + ScrLk + W
ScrLk + ScrLk + ↑ (arrow up)
ScrLk + ScrLk + ↓ (arrow down)
ScrLk + ScrLk + (Backspace)
ScrLk + ScrLk + B
ScrLk + ScrLk + H + (y)
y = SCROLL LOCK, CAPS, ESC,
F12 or NUM LOCK
ScrLk + ScrLk + S
ScrLk + ScrLk + S + (z)
z = 0~9
1 10" ; 2 20" ; 3 30" ; 4
6 60" ; 7 70" ; 8 80" ; 9
Press any key on keyboard
R e f e r e n c e S h e e t
*User-definable Preceding sequence = SCROLL LOCK, CAPS, ESC, F12 or NUM LOCK
Front-panel Buttons
Press the corresponding button to select the
active PC channel
(Press the corresponding button to select the
specific PC+USB hub port control --works
only if PC port/hub port control binding
enabled)
--
--
--
--
--
--
--
--
--
Press and hold down last button (Button 2 /
Butotn4) till two beeps, release the button,
then press (y) key
--
--
40" ; 5 50"
90" ; 0 100"
Press any button
Description
Select the active PC channel
(Joint-select PC port/hub port control/audio&mic , if
binding is enabled)
Select the PC channel that control all USB hub ports
(Joint-select PC & Hub port control, if PC/hub port control
binding is enabled)
Select the active Audio&Mic channel
(Joint-select PC & audio&mic channel, if binding is enabled)
Enable the binding of PC port and hub port control switching.
(Once this feature is enabled, any pc and/or hub port control
switching is bound together) (factory default)
Disable the binding of PC port and hub port control switching
Enable the binding of PC port and audio&mic switching.
(Once this feature is enabled, any pc and/or audio&mic
switching is bound together) (factory default)
Disable the binding of PC port and audio&mic switching
Select the next lower connected PC channel
(Joint-select PC/hub port control/audio&mic, if binding is
enabled)
Select the next higher connected PC channel
(Joint-select PC/hub port control/audio&mic , if binding is
enabled)
Toggle between the previous channel and current channel
Toggle on/off the beep sound while autoscanning
Select the hotkey preceding sequence among 5 alternative
keys
Autoscan through every connected channel for quick screen
browsing of each channel (scan delay = 5 sec.).
Autoscan with a user-defined delay time within a range of
10 ~ 100 seconds
Terminate Autoscan activity
