Intex Hydro Flow SM24101 Owner's Manual page 13

SETUP INSTRUCTIONS (continued)
Connecting the swim-trainer unit to the
transformer (see fi gures 9.1 to 9.2).
1. Be sure the transformer (2) switch is
OFF, connect the transformer cable to
a grounded electrical outlet.
2. Transformer must be fi xed to a solid,
level ground or base. Connect the
swim-trainer unit power cable plug into
the transformer power receptacle. Be
sure the plug collar is securely tightened
(see fi gure 9.1 to 9.2).
3. Position the transformer 2m or more away
from the pool, so as to prevent children
from climbing on it and accessing the pool.
4. Test the GFCI or RCD before use:
a) Press the "RESET" button. The
indicator on the RCD should be "ON".
b) Press the "TEST" button. The indicator
on the RCD should be "OFF".
c) Press the "RESET" button again to
start using the product.
d) Do not use the product if the test
failed. Contact a qualifi ed electrician to
inspect the electrical outlet socket.
5. Turn the transformer switch ON.
NOTE: To reactivate the swim-trainer unit after the emergency stop lanyard is pulled,
replace the emergency stop lanyard back into the swim-trainer unit, unplugged and
re-plugged the power cable from the transformer.
SAVE THESE INSTRUCTIONS
(303PO) MODEL SM24101 SWIMMING MACHINE ENGLISH 7.5" X 10.3" PANTONE 295U 02/21/2017
Power
receptacle
303
English
PO
9.1
ON/OFF Switch
Fuse Box
9.2
Page 13
