SETUP INSTRUCTIONS (continued)
2. Installing the mounting bracket assembly onto a round frame pool wall
(see figures 5.1 to 5.3):
1
X
• Attach the mounting bracket assembly onto the frame pool vertical legs with the
horizontal pipe lugs (10), screws (8), and depending on the shape of the vertical leg
pipe include A/B/C gap fi ller (11) (see fi gure 5.2).
For " " shape vertical leg pipe, do not include the A/B/C gap fi ller (11).
For 38mm diameter vertical leg pipe include "A" gap fi ller.
For 44mm diameter vertical leg pipe include "B" gap fi ller.
For 48mm diameter vertical leg pipe include "C" gap fi ller.
NOTE: Make sure all the screws are securely tightened and the mounting bracket top
surface is level.
8
3. Swim-Trainer Unit Assembly (see fi gures 5.4 to 5.5).
• Be sure the swim-trainer unit "support bracket" is closed before installing the
swim-trainer unit onto the mounting bracket assembly (see fi gure 5.4).
X
SAVE THESE INSTRUCTIONS
(303PO) MODEL SM24101 SWIMMING MACHINE ENGLISH 7.5" X 10.3" PANTONE 295U 02/21/2017
5.2
11
10
X
English
2
X
4
MIN
303
PO
5.1
5.3
X
5.4
22
