(303PO) MODEL SM24101 SWIMMING MACHINE ENGLISH 7.5" X 10.3" PANTONE 295U 02/21/2017
Hydro Flow™ Swim Trainer
Model SM24101
110-120V AC / 60Hz
For illustrative purposes only. Pool not included.
Don't forget to try these other fine Intex products: pools, pool
accessories, inflatable pools and in-home toys, airbeds and boats
available at fine retailers or visit our website.
Due to a policy of continuous product improvement, Intex reserves the
right to change specifications and appearance, which may result in
updates to the instruction manual without notice.
DO NOT RETURN PRODUCT TO STORE
To purchase parts and accessories or to obtain non-technical assistance, Visit
For technical assistance and missing parts call us toll-free (for U.S. and Canadian Residents):
Monday through Friday, 8:30am to 5:00pm Pacific Time
IMPORTANT
SAFETY RULES
Read, understand, and follow
all instructions carefully before
installing and using this product.
IMPORTANT!
www.intexcorp.com
1-800-234-6839
303
English
PO
303-*PO-R0-1702

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hydro Flow SM24101 and is the answer not in the manual?

Questions and answers

Summary of Contents for Intex Hydro Flow SM24101

  • Page 1 Model SM24101 110-120V AC / 60Hz For illustrative purposes only. Pool not included. Don’t forget to try these other fine Intex products: pools, pool accessories, inflatable pools and in-home toys, airbeds and boats available at fine retailers or visit our website.
  • Page 2: Table Of Contents

    (303PO) MODEL SM24101 SWIMMING MACHINE ENGLISH 7.5” X 10.3” PANTONE 295U 02/21/2017 English TABLE OF CONTENTS Warnings..................3 Parts Reference................4-5 Product Specification..............6 Setup Instructions..............6-13 Operating Instructions............... 14-15 Maintenance................15 Internal Parts Replacements............. 16-17 Troubleshooting Guide.............. 18-19 Limited Warranty................. 20 Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 3: Warnings

    (303PO) MODEL SM24101 SWIMMING MACHINE ENGLISH 7.5” X 10.3” PANTONE 295U 02/21/2017 English IMPORTANT SAFETY RULES Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product. READ AND FOLLOW ALL INSTRUCTIONS WARNING • To reduce the risk of injury, do not permit children to use this product. Always supervise children and those with disabilities.
  • Page 4: Parts Reference

    PARTS REFERENCE Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. Intex Rectangular Frame Pool Mounting Bracket In Ground Pool Mounting Bracket Intex Round Frame Pool Mounting Bracket. NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.
  • Page 5: Parts Reference

    (303PO) MODEL SM24101 SWIMMING MACHINE ENGLISH 7.5” X 10.3” PANTONE 295U 02/21/2017 English PARTS REFERENCE (continued) Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. Intex Rectangular Intex Round Frame Frame Pool Pool POOL REF. NO. DESCRIPTION QTY.
  • Page 6: Product Specification

    PRODUCT SPECIFICATIONS SM24101 Model: Transformer input 110-120V AC / 60Hz 8A Voltage: Transformer output 24V DC 35A In ground pool or Intex above ground metal frame pools Suitable for: Pool water temperature range: 25ºC - 35ºC Speed Setting* 0.66 0.77 0.83...
  • Page 7 English SETUP INSTRUCTIONS (continued) Pool Mounting Bracket Assembly A: For Intex Rectangular Frame Pools 1. Mounting Bracket Assembly (see fi gures 1.1 to 1.2): NOTE: Center the swim-trainer unit on the short-end side of the pool. 2. Installing the mounting bracket assembly onto a rectangular frame pool wall (see fi...
  • Page 8 (303PO) MODEL SM24101 SWIMMING MACHINE ENGLISH 7.5” X 10.3” PANTONE 295U 02/21/2017 English SETUP INSTRUCTIONS (continued) • Lock the bracket poles and mounting bracket assembly onto the U-shaped side support with the bracket pole fi xer (7) and screws (8). (see fi gure 2.2). NOTE: Make sure all the screws are securely tightened and the mounting bracket top surface is level.
  • Page 9 (303PO) MODEL SM24101 SWIMMING MACHINE ENGLISH 7.5” X 10.3” PANTONE 295U 02/21/2017 English SETUP INSTRUCTIONS (continued) B: For Intex Round Frame Pools 1. Mounting Bracket Assembly (see figures 4.1 to 4.5): • Identify the frame pool pipe shape. For “...
  • Page 10 (303PO) MODEL SM24101 SWIMMING MACHINE ENGLISH 7.5” X 10.3” PANTONE 295U 02/21/2017 English SETUP INSTRUCTIONS (continued) 2. Installing the mounting bracket assembly onto a round frame pool wall (see figures 5.1 to 5.3): • Attach the mounting bracket assembly onto the frame pool vertical legs with the horizontal pipe lugs (10), screws (8), and depending on the shape of the vertical leg pipe include A/B/C gap fi...
  • Page 11 (303PO) MODEL SM24101 SWIMMING MACHINE ENGLISH 7.5” X 10.3” PANTONE 295U 02/21/2017 English SETUP INSTRUCTIONS (continued) • Adjust the nut on the swimming machine until the support plate is against the pool wall and the swim-trainer unit is perfectly Ajustable nut horizontal (see figure 5.5).
  • Page 12 (303PO) MODEL SM24101 SWIMMING MACHINE ENGLISH 7.5” X 10.3” PANTONE 295U 02/21/2017 English SETUP INSTRUCTIONS (continued) 2. Swim-Trainer Unit Assembly (see fi gures 6.4 to 6.5). • Be sure the swim-trainer unit “support bracket” is closed before installing the swim-trainer unit onto the mounting bracket assembly (see fi gure 6.4). •...
  • Page 13 (303PO) MODEL SM24101 SWIMMING MACHINE ENGLISH 7.5” X 10.3” PANTONE 295U 02/21/2017 English SETUP INSTRUCTIONS (continued) Connecting the swim-trainer unit to the transformer (see fi gures 9.1 to 9.2). ON/OFF Switch 1. Be sure the transformer (2) switch is Power receptacle OFF, connect the transformer cable to Fuse Box...
  • Page 14: Operating Instructions

    (303PO) MODEL SM24101 SWIMMING MACHINE ENGLISH 7.5” X 10.3” PANTONE 295U 02/21/2017 English OPERATION INSTRUCTIONS Display Panel Function Antenna Zone #1 Function Zone #1 Function Zone #2 Function A: On/Off Button B: Speed Increase Button C: Speed Decrease Button D: Speed Setting Display A: On/Off Button: Once the swim-trainer unit is connected to the transformer and the transformer turned ON, use this button to active the system.
  • Page 15: Maintenance

    F or when the appliance will not be used for a long period of time. IMPORTANT: Close the support bracket before disassembling and removing the swim-trainer unit from the mounting bracket assembly (Only for Intex Rectangular Frame Pools). 1. Turn off the transformer and unplug the power cable from the electrical outlet.
  • Page 16: Internal Parts Replacements

    (303PO) MODEL SM24101 SWIMMING MACHINE ENGLISH 7.5” X 10.3” PANTONE 295U 02/21/2017 English INTERNAL PARTS REPLACEMENTS Tools required: one Philip screwdriver, one flat screwdriver and one small adjustable wrench. A: Propeller and motor disassembly Page 16 SAVE THESE INSTRUCTIONS...
  • Page 17 (303PO) MODEL SM24101 SWIMMING MACHINE ENGLISH 7.5” X 10.3” PANTONE 295U 02/21/2017 English INTERNAL PARTS REPLACEMENTS (continued) B: Swim-trainer unit bracket and circuitry box disassembly Page 17 SAVE THESE INSTRUCTIONS...
  • Page 18: Troubleshooting Guide

    (303PO) MODEL SM24101 SWIMMING MACHINE ENGLISH 7.5” X 10.3” PANTONE 295U 02/21/2017 English TROUBLESHOOTING GUIDE LED PANEL PROBLEM SOLUTION CODE The maximum operating time It's normal. Turn off and unplug the unit. ● ● (90 minutes) has fi nished under the Then plug the RCD/GFCI back and same set mode.
  • Page 19 ● ● Emergency stop lanyard is put wrong plugged fi rmly into the cell housing ● place. receptacle. Contact Intex Service Center. ● Put the emergency stop lanyard ● on correct place. See “Setup Instructions”. Abnormal display / Display panel cord is loose.
  • Page 20: Limited Warranty

    Your Hydro Flow™ Swim Trainer has been manufactured using the highest quality materials and workmanship. All Intex products have been inspected and found free of defects prior to leaving the factory. This Limited Warranty applies only to the Hydro Flow™ Swim Trainer and accessories listed below.
