5.0 Design

5.1 Design
Your substation might look different than the substation shown.
Design description
E
Hot water tank with coil
1A Ball valve, DVGW
7
Thermostatic valve, DHW
9 Strainer
8 DEN-GT
Termix BTD RO MIX
10 Circulator pump
14 Sensor pocket, energy meter
20 Filling/drain valve
22 Test connection
VI.HE.F2.02 / LUK40661
27 Actuator, HE
41 Fitting piece, energy meter
43 Ball valve closed
50 Diff. pressure controller with flow limiter
