OPERATING MANUAL
A U D I O
M I X E R
4 PROGRAM
RMX-1426

Advertisement

Table of Contents
loading

Related Manuals for Inter-m RMX-1426

Summary of Contents for Inter-m RMX-1426

  • Page 1 OPERATING MANUAL A U D I O M I X E R 4 PROGRAM RMX-1426...

  • Page 2: Unpacking And Installation

    UNPACKING AND INSTALLATION Although it is neither complicated to install nor difficult to operate your set, a few minutes of your time is required to read this manual for a properly wired installation and becoming familiar with its many features and how to use them.
  • Page 3 FEATURES • 6 MONO, 4 STEREO CHANNEL INPUT AND 4 OUTPUT Any sound source of microphones, cassette deck, compact disc and electronic instruments can be applied to mono input channel, especially 4 channels are designed for stereo function. 4 channel output are provided for convenient use.

  • Page 4: Front Panel Controls

    FRONT PANEL CONTROLS PEAK PEAK PEAK PEAK PEAK PEAK PEAK PEAK PEAK PEAK TRIM TRIM TRIM TRIM TRIM TRIM TRIM TRIM TRIM TRIM LINE LINE LINE LINE LINE LINE LINE LINE LINE LINE HIGH HIGH HIGH HIGH HIGH HIGH HIGH HIGH HIGH HIGH...

  • Page 5: Balance Control

    7. BALANCE CONTROL The BALANCE knob adjust balance or the L/R position of the stereo module signal. For example if this knob is turned all the way to the left, the signal will be sent only the stereo L and PGM 1, 3 whose assign switchs are pressed.
  • Page 6 RMX-1426 AUDIO MIXER 4 PROGRAM M O N POWER PHANTOM STEREO MONITOR EFX RETURN AUX SEND EFX SEND H.P/MON HEADPHONS PGM 1 PGM 2 PGM 3 PGM 4 STEREO OUTPUT CONTROL PART 1. EFX RETURN CONTROL The volume control the input levels from the effect device etc, connected to EFX RETURN.
  • Page 7 9. ON SWITCH This switch turn the PGM 1~4, ST on/off. The output signal is on when the switch is pressed in. When off, the output signal will be muted. 10. MASTER FADER CONTROL This fader adjusts the signal level to the PGM 1~4, ST. 11.

  • Page 8: Rear Panel Controls

    REAR PANEL CONTROLS INPUT/BAL PROGRAM OUTPUT +4dB / BAL 13/14 11/12 9 / 1 0 FUSE T315mAL/250V I NS ER T 0 d B LINE INPUT AC INPUT B A L 230V 50Hz, 36W A U X L/MONO S T E R E O M O N I T O R SEND SEND...

  • Page 9: Stereo Out

    0dB/10KΩ. These are unbalanced TRS jacks, with tip=out, ring=in and sleeve=ground. 8. PGM OUT 1~4 These are unbalanced phone jack which output the signal of the PGM bus. The nominal output level impedance is +4dB/600Ω 9. STEREO OUT These are unbalanced phone jack which output the signal of the STEREO bus.

  • Page 10: Specifications

    SPECIFICATIONS ELECTRICAL • Rated Output Stereo, PGM 1~4 Output ....................+4dB/600Ω, BAL AUX, EFX Send......................+4dB/600Ω, UNBAL Monitor Out........................+4dB/600Ω, UNBAL Headphone Out ........................100mW/40Ω • Input sensitivity/Impedance Mic(CH1~CH6) .........................-60dB/600Ω, BAL Mic(CH7~CH14) .......................-50dB/600Ω, BAL Line(CH1~CH6) .......................-20dB/10KΩ, BAL Line(CH7~CH14) ......................-20dB/10KΩ, UNBAL EFX Return ........................+4dB/10KΩ, UNBAL SUB In(PGM1~4, AUX, EFX) ..................+4dB/10KΩ, UNBAL •...
  • Page 11 MADE IN KOREA...
