Summary of Contents for Clarke AC10000
- Page 1 PORTABLE AIR CONDITIONER MODEL NO: AC10000/13000 PART NO: 3230574/3230576 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC0518 Iss 3...
-
Page 2: Environmental Protection
GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase. -
Page 3: Safety Warnings
3. This appliance is designed for use in residential environments and must not be used for other purposes. 4. If the appliance requires repair, always contact your CLARKE dealer. Always insist on original spare parts. Repairs carried out by unauthorized persons may be dangerous and invalidate the guarantee. -
Page 4: Electrical Connections
ELECTRICAL CONNECTIONS WARNING! READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 230 V AC 50Hz. - Page 5 OVERVIEW DESCRIPTION DESCRIPTION Air Outlet Flap Lower Air Filter Frame Control Panel Power Cable with storage Handle Water Drain Port Upper Air Filter Frame (Air Intake) 9 Power Plug Storage Socket Air Outlet Port Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 6: Installation
Ensure the air conditioner and its components suffered no damage during transit and that all components are present. Should any loss or damage be apparent, please contact your CLARKE dealer immediately. The following components are supplied with the unit; 1. Flexible exhaust duct. - Page 7 NOTE: The length of duct has been designed to suit the specification of the air conditioner. Do not use an extension or change to a different size duct as it may lead to poor performance. 7. The flexible exhaust ducting can be bent to an angle if followed by a straight section, but tight curves and kinks must always be...
- Page 8 8. The window slider plate is designed to fit most standard vertical sash type and horizontal sliding windows. However, it may be necessary for you to adapt the installation procedure for various other types of window. 9. Extend the two parts of the window slider and fit into the window opening, below or beside the window panel.
-
Page 9: Control Panel
CONTROL PANEL The control panel has the following buttons: 1. POWER: Press this button to turn the unit on & off. When turned on, the machine will start running in the previously selected mode. • If the ambient temperature is above 35 C, the display will indicate “H”... -
Page 10: Remote Control
REMOTE CONTROL The remote control can be stored in the holder provided at the top of the air conditioning unit as shown. It requires 2 x AAA batteries to be installed as shown on page 8. The remote control incorporates the following pushbuttons: POWER Turns the unit on or off. -
Page 11: General Operation
OPERATION GENERAL OPERATION If the room is exposed to direct sunlight, draw any curtains during the sunniest part of the day. NOTE: Always drain any remaining water from the unit via the drain plug after operating in DRY mode. The unit will automatically stop working when water reaches the high level. -
Page 12: Draining Off The Water
DRAINING OFF THE WATER The air conditioner has a self-evaporating system. The condensing water will recycle to cool the condenser, which improves cooling efficiency but also saves energy and reduces noise. The condensation may eventually collect faster than the system can cycle and the water container will become full. When the water container is full, ‘FL’... -
Page 13: Maintenance
MAINTENANCE CLEANING WARNING: ALWAYS TURN OFF THE UNIT AND DISCONNECT FROM THE POWER SUPPLY BEFORE CLEANING. 1. Clean the outside surfaces of the unit with a duster or a soft, moist cloth. • Do not use solvents which could damage the plastic components. 2. -
Page 14: Fault Codes
FAULT CODES The following fault codes can be displayed on the control panel. Fault Code Diagnosis of Fault Action Required Coil temperature is Return to Clarke Service abnormal Department to check coil temperature sensor or relevant circuit Room temperature is... -
Page 15: Troubleshooting
TROUBLESHOOTING Problem Check Solution The unit fails to Check for power failure if Plug the unit into the operate unit is plugged in. socket. Check the switch is on and Replace fuse or switch that the fuse is not blown. Is the set running time Change the set time correct? -
Page 16: Parts Diagram
PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 17: Parts List
PARTS LIST PART NO DESCRIPTION PART NO DESCRIPTION Retaining Bracket Upper Foam Seal Discharge Fan Motor Compressor Exhaust Duct Fan Housing Bracket Condenser Assembly Discharge Fan Front Casing Connecting Pipe Filter Discharge Fan Motor Cover Metal Gasket Pump Flywheel Float Holder Discharge Fan Rear Casing Float Evaporator... -
Page 18: Technical Specifications
Special Spring Fittings Assembly Anti-vibration Rubber Cover Assembly Electromagnetic Pump Four-Way Valve Connect Pipe Suction Pipe 2 TECHNICAL SPECIFICATIONS AC10000 AC13000 Power Supply 230V/50Hz Weight 30 kg 33 kg Dimensions (L x W x H) 355 x 465 x 850 mm Water Holding Capacity 0.5 L... -
Page 19: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
