SiK011003
Model of Outdoor Unit
Product Code
Compressor Model
Compressor Oil
Compressor Type
L.R.A.
Compressor RLA
Compressor Power Input
Overload Protector
Throttling Method
Operation temp
Ambient temp (cooling)
Ambient temp (heating)
Condenser Form
Pipe Diameter
Rows-fin Gap
Coil Length (LXDXW)
Fan Motor Speed
Output of Fan Motor
Fan Motor RLA
Outdoor Unit
Fan Motor Capacitor
Air Flow Volume of Outdoor Unit
Fan Type
Fan Diameter
Defrosting Method
Climate Type
Isolation
Moisture Protection
Permissible Excessive Operating Pressure for
the Discharge Side
Permissible Excessive Operating Pressure for
the Suction Side
Sound Pressure Level (H/M/L)
Sound Power Level (H/M/L)
Dimension (WXHXD)
Dimension of Carton Box (LXWXH)
Dimension of Package (LXWXH)
Net Weight
Gross Weight
Refrigerant
Refrigerant Charge
Gas Additional Charge
Outer Diameter Liquid Pipe
Connection Outer Diameter Gas Pipe
Pipe
Max Distance Height
Max Distance Length
Note: The connection pipe applies metric diameter.
The above data is subject to change without notice; please refer to the nameplate of the unit.
Specifications
RXV35AV1B
CB141W00400_L08682
QXA-A091zE190A
68EP
Rotary
A 16.5
A 4.9
W 950
1NT11L-6233
Electron expansion valve
o
C 16~30
o
C 18~43
o
C -7~24
Aluminum Fin-copper Tube
mm Φ7
mm 2-1.4
mm 710X38.1X508
rpm 900/660
W 30
A 0.15
μF /
3
m /h 1800
Axial-flow
mm Φ400
Automatic Defrosting
T1
I
IP24
MPa 4.3
MPa 2.5
dB (A) 53/-/-
dB (A) 63/-/-
mm 776X540X320
mm 848X360X580
mm 851X363X595
kg 29
kg 33
R410A
kg 0.95
g/m 20
mm Φ6
mm Φ9.52
m 10
m 20
ARXV35AV1B
CB141W00400_L07769
QXA-A091zE190A
68EP
Rotary
16.5
4.9
950
1NT11L-6233
Electron expansion valve
16~30
18~43
-7~24
Aluminum Fin-copper Tube
Φ7
2-1.4
710X38.1X508
900/660
30
0.15
/
1800
Axial-flow
Φ400
Automatic Defrosting
T1
I
IP24
4.3
2.5
53/-/-
63/-/-
776X540X320
848X360X580
851X363X595
29
33
R410A
0.95
20
Φ6
Φ9.52
10
20
5
