ViewSmart 200 XP NEMA 7 EXPLOSION-PROOF WALL MOUNT
ENCLOSURE
The ViewSmart 200 XP shown in Figure 4.1 is an aluminum NEMA 7 wall mount
enclosure designed for mounting into potentially hazardous.
14.25
ViewSmart 200/2050/2150 Controller User's Manual
13.00
9.87
Figure 4.1
35
Revision Level B
6.25
Standard "O" Ring
adds NEMA 4 rating
3/4"NPT(Qty 4)
Mounting Feet
8.00
