LO - Shows the transmit output power is set to 1
watt on the output channel.
HI - Shows the transmit output power is set to 25
watts on the output channel.
MEM - Indicates if a channel has been placed into
channel scanning memory.
TRI- Appears when the microphone is on a working
channel and is watching channel 16 and channel 9.
Also, additionally if watching the weather channel.
WX - Appears when the microphone is in the
weather mode.
- Appears when the weather alert channel
watch is active and blinks when the alert is acti-
vated.
U I C - Shows the channel mode (USA, INT, or
CAN).
DSC - Appears when the microphone is in the DSC
mode, including receiving DSC calls. It also shows
that the microphone is connected to the main radio
(by RF). It blinks when the microphone is close to
out of range, or when completely out of range.
GPS is connected to the microphone. The
signal wave portions of this icon will blink sequen-
tially to indicate that the GPS data being received is
valid.
This icon shows that the microphone is
connected to the main radio (by RF). It blinks when
the WHAMx4 is close to out of range, or when
completely out of range.
Setting Up the Microphone 13
