Specifications

Monitor Specifications
LCD Module
Viewable Image Size:
Native Resolution (Pixel Count):
Input Signal
DisplayPort: DisplayPort Connector:
DVI: DVI-D 24pin:
VGA: Mini D-Sub 15-pin:
HDMI: HDMI Connector:
Display Colors
Synchronization Range
Viewing Angle
Image Formation Time
Active Display Area Landscape: Horiz.:
Portrait: Horiz.:
USB Hub
Load Current:
AUDIO
Audio Input: STEREO Mini Jack:
DisplayPort Connector:
HDMI Connector:
Headphone Output: STEREO Mini Jack:
Speakers Practical Audio Output:
ControlSync
(available up to 5 sub monitors)
Power Supply
Current Rating
Dimensions
Stand adjustable range Height Adjustment:
Tilt / Pivot / Swivel:
Weight
Environmental Considerations
Operating Temperature:
Storage Temperature:
NOTE: Technical specifications are subject to change without notice.
MultiSync EA271F
Diagonal: 68.60 cm/27 inches
68.60 cm/27 inches
1920 x 1080
Digital RGB
Digital RGB
Analog RGB
Sync
Digital YUV
Digital RGB
16,777,216
Horizontal: 31.5 kHz to 83.0 kHz
Vertical: 50 Hz to 75 Hz
Left/Right: ±89° (CR > 10)
Up/Down: ±89° (CR > 10)
6 ms (Gray to gray Typ.)
597.89 mm/23.5 inches
Vert.: 336.31 mm/13.2 inches
336.31 mm/13.2 inches
Vert.: 597.89 mm/23.5 inches
I/F: USB Specification Revision USB 3.1 Gen 1
Port: Upstream 1
Downstream 3
Maximum 0.9 A per port for USB 3.1 Gen 1
Analog Audio
Digital Audio
Digital Audio
1.0 W + 1.0 W
IN: Stereo Micro jack 2.5 φ
OUT: Stereo Micro jack 2.5 φ
AC 100-240 V ~ 50/60 Hz
0.85 - 0.45 A
Landscape: 610.2 mm (W) x 377.3 - 527.3 mm (H) x 250.0 mm (D)
24.0 inches (W) x 14.9 - 20.8 inches (H) x 9.8 inches (D)
Portrait: 359.8 mm (W) x 628.4 - 652.6 mm (H) x 250.0 mm (D)
14.2 inches (W) x 24.7 - 25.7 inches (H) x 9.8 inches (D)
150 mm/5.9 inches (Landscape orientation)
24.2 mm/1.0 inches (Portrait orientation)
Up 35° Down 5° / ± 90° / 340°
7.6 kg (16.8 lbs)/Without stand: 5.0 kg (11.0 lbs)
5°C to 35°C/41°F to 95°F
Humidity: 20% to 80%
Altitude: 0 to 16,404 Feet/0 to 5,000 m
-10°C to 60°C/14°F to 140°F
Humidity: 10% to 85%
Altitude: 0 to 40,000 Feet/0 to 12,192 m
Notes
Active matrix; thin film transistor (TFT) liquid crystal
display (LCD); 0.311 mm dot pitch; 250 cd/m
luminance; 1000:1 contrast ratio (typical), (5000:1
Contrast ratio, Dynamic).
DisplayPort V1.1a (HDCP1.3)
DVI (HDCP1.4)
0.7 Vp-p/75 ohm
Separate sync.TTL level Positive/Negative
Composite sync.TTL level Positive/Negative
Sync on Green
(Video 0.7 Vp-p and Sync Negative 0.3 Vp-p)
HDMI (HDCP1.4)
Automatically
Automatically
Upstream port applicable to USB monitor control.
Stereo L/R 500mV rms 20 Kohm
PCM 2ch 32, 44.1, 48 kHz (16/20/24bit)
PCM 2ch 32, 44.1, 48 kHz (16/20/24bit)
Headphone Impedance 32 Ohm
English-21
