Cateye CC-RS100W Quick Start Up Manual
Hide thumbs Also See for CC-RS100W:

Advertisement

Quick Links

This Quick Start manual will explain how to set up the computer and how to install the
computer and the sensor to the bicycle.
Start
* In this manual, orange text/icons on the computer screen represent flashing items.
* This manual and YouTube videos for this product are subject to change without notice.
* An
instruction manual (PDF)
detailing all functions is available on the website.
Copyright © 2018 CATEYE Co,.Ltd.

Advertisement

loading
Need help?

Need help?

Do you have a question about the CC-RS100W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Cateye CC-RS100W

  • Page 1 * In this manual, orange text/icons on the computer screen represent flashing items. * This manual and YouTube videos for this product are subject to change without notice. * An instruction manual (PDF) detailing all functions is available on the website. Copyright © 2018 CATEYE Co,.Ltd.
  • Page 2 Menu Follow the steps below to set up the computer and the sensor. 1. Set up the computer 2. How to install the bracket 3. How to install the speed sensor 4. Test operation Return to Top...
  • Page 3 Menu 1. Set up the computer Use these buttons for setup. 1. Clear all data (initialization) Initialize the computer. Press the AC button on the back of the computer. The whole display turns on and then switches to the speed unit setting screen. 2.
  • Page 4 Select either “km/h” or “mph.” Press the MODE button to switch between speed units. After selecting the unit, press the MENU button to confirm. Setting the speed unit Confirm 3. Enter the tire circumference Enter the tire circumference of your bicycle. Refer to “Determine tire circumference”...
  • Page 5 4. Set the clock display Select either “12h” or “24h.” Press the MODE button to switch between time formats. After selecting the format, press and hold the MODE button to confirm. Clock display Confirm (Press and hold) 5. Set the hour Enter the current hour.
  • Page 6 Press the MODE button to increase the flashing value (minute). After setting the minute, press the MENU button to confirm. Increase the value Minute Confirm Setup is completed The measurement screen appears. Now, setup of the computer is completed. 2. How to install the bracket 3.
  • Page 7: Tire Circumference Reference Table

    1. Set up the computer Determine tire circumference Determine tire circumference (L) by referring to the tire size chart or by measuring the actual tire circumference of your bicycle. Tire circumference reference table You can find the circumference on the tire size chart. * The tire size or ETRTO code is indicated on the side of the tire.
  • Page 9 Measure actual tire circumference You can measure the tire circumference of your bicycle. With tire air pressure adjusted appropriately, apply a load to the bicycle. Using the valve, etc., as a marker, rotate the tire once and measure the distance traveled along the ground.
  • Page 10: Mount The Bracket

    Menu 1. Set up the computer 2. How to install the bracket 1. Mount the bracket Handlebar diameter...
  • Page 11 ø25 to 26 mm ø31.8 mm Bracket Bracket Bracket rubber pad Recommended tightening torque 0.5 N•m (50 N•cm) Caution Adjust the mounting angle so that the back side of the computer faces the speed sensor. 2. Attach/detach the computer Attach...
  • Page 12 Detach Pull out Release button Press and hold The bracket installation is now completed. 3. How to install the speed sensor 4. Test operation Return to Menu...
  • Page 13 Menu 1. Set up the computer 2. How to install the bracket 3. How to install the speed sensor How to install the speed sensor (SPD-01) The speed sensor installation is now completed. 4. Test operation Return to Menu...
  • Page 14 Menu 1. Set up the computer 2. How to install the bracket 3. How to install the speed sensor 4. Test operation Rotate the front wheel of the bicycle Verify that the current speed is displayed on the computer and that the speed unit flashes. Current speed Speed unit If the current speed is not displayed, check the installation conditions below and perform...
  • Page 15 Sensor zone Magnet * For more details on mounting the speed sensor, refer to “3. How to install the speed sensor”. The magnet passes through the speed sensor zone. Magnet Sensor zone * For more details on mounting the speed sensor, refer to “3.
  • Page 16 * For more details on mounting the bracket, refer to “2. How to install the bracket”. Preparation of the computer is now completed. For the computer measurement functions or changing the settings, refer to the instruction manual on the website. Manual (PDF) Return to Top...
