Page 1 A000A01A-GAT This Owner's Manual should be considered a part of the car and remain with it when it is sold for the use of the next owner. OWNER'S I.D. ORIGINAL: NAME: ADDRESS: STREET: TOWN: COUNTY: P.CODE: DATE OF SALE: SUBSEQUENT: NAME: ADDRESS: STREET:...
Page 2 A020A01A-AAT RESPONSIBILITY FOR MAINTENANCE The maintenance requirements for your new Hyundai are found in Section 5. As the owner, it is your responsibility to see that all maintenance operations specified by the manufacturer are carried out at the appropriate intervals. When the vehicle is used in severe driving conditions, more frequent maintenance is required for some operations.
Page 3 Specifications HGK037 All information in this Owner's Manual is current at the time of publication. However, Hyundai reserves the right to make changes at any time so that our policy of continual product improvement may be carried out. This manual applies to all Hyundai models and includes descriptions and explanations of optional as well as standard equipment. As a result, you may find material in this manual that does not apply to your specific vehicle.
Page 4 Your Owner's Manual will introduce you to the features and operation of your new Hyundai. It is suggested that you read it carefully because the information it contains can contribute greatly to the satisfaction you receive from your new car.
Page 5: Table Of Contents
TABLE OF CONTENTS SECTION PAGE FEATURES OF YOUR HYUNDAI ................1-1 DRIVING YOUR HYUNDAI ..................2-1 WHAT TO DO IN AN EMERGENCY ................3-1 CORROSION PREVENTION & APPEARANCE CARE ..........4-1 VEHICLE MAINTENANCE REQUIREMENTS ............5-1 DO-IT-YOURSELF MAINTENANCE ................6-1 EMISSION CONTROL SYSTEMS ................
Page 6 For this reason, we recommend that you carefully follow the radio manufacturer's instructions or consult your Hyundai dealer for precautionary measures or special instructions if you choose to install one of these devices.
Page 7 A090A01A-AAT SAFETY AND VEHICLE DAMAGE WARNING This manual includes information titled as WARNING, CAUTION and NOTE. These titles indicate the following: WARNING: This indicates that a condition may result in harm, serious injury or death to you or other persons if the warning is not heeded.
Page 8 1. What are Hyundai Genuine Parts? an imitation, counterfeit or used sal- Hyundai Genuine Parts are the same vage part is not covered by Hyundai parts used by Hyundai Motor Company Motor Company. to manufacture vehicles. They are de- signed and tested for the optimum safe- 3.
Page 9: Features Of Your Hyundai
87 (Research Octane Number 91) or higher No formal "break-in" procedure is required with not be used in your Hyundai. This type of fuel can must be used in Hyundai vehicle. If leaded gaso- your new Hyundai. However, you can contribute...
Page 10 SSA1030B KEYS A code number is stamped on the key number plate that came with the keys to your Hyundai. This key number plate should be kept in a safe place, not in the vehicle. The key number should also be recorded in a place where it can be found in an emergency.
Page 11 New keys are available from any 10 times. the car in case of an accident. Hyundai dealer by quoting the relevant key num- 2. Wait for 3~10 seconds. o Before opening the door, always look for ber.
Page 12 FEATURES OF YOUR HYUNDAI B040B01A-AAT B040C01S-AAT B040D01S-AAT Locking and Unlocking Front Doors Locking From the Outside Locking From the Inside With a Key UNLOCK UNLOCK LOCK LOCK HGK208 HGK099 HGK101 To lock the doors from the inside, simply close The doors can be locked without a key.
Page 13 FEATURES OF YOUR HYUNDAI CAUTION: B040G01GK-GAT B070A01A-AAT Central Door Lock THEFT-ALARM SYSTEM (If Installed) Do not arm the system until all passengers This system is designed to provide protection have left the car. If the system is armed while from unauthorized entry into the car. This system a passenger(s) remains in the car, the alarm is operated in three stages: the first is the "Armed"...
Page 14 FEATURES OF YOUR HYUNDAI B070D03GK-AAT B070E02GK-GAT Disarmed Stage Replacing the battery When the transmitter's battery begins to get weak, it may take several pushes on the button to lock or unlock the doors, and the LED will not light. Replace the battery as soon as possible.
Page 15 FEATURES OF YOUR HYUNDAI B050A01GK-AAT WINDOW GLASS Power Window B050A02GK HGK097 CAUTION: WARNING: Never try to operate the main switch and sub- o Be careful that head, hands and body are HGK096 switch in opposing directions at the same not trapped by a closing window.
Page 16 FEATURES OF YOUR HYUNDAI WARNING: collision may be reduced significantly when B080A01A-AAT ADJUSTABLE FRONT SEATS To ensure the seat is locked securely, at- the seat backs are reclined. There is greater WARNING: tempt to move the seat forward or rearward...
Page 17 FEATURES OF YOUR HYUNDAI The use of a cushion that holds the body B080F01F-AAT The seat warmer is provided to warm the front Seat Cushion Height Adjustment away from the seatback is not recom- seats during cold weather. With the ignition key mended.
Page 18 FEATURES OF YOUR HYUNDAI B130A01GK-AAT By pulling up the walk in device lever (1) at the In order to prevent the shoulder belt from being REAR SEAT ENTRY (Walk in device) right-upper side of the passenger side seatback, damaged while folding the rear seat, the shoulder The driver and front passenger's seatbacks the seatback will tilt forward.
Page 19 FEATURES OF YOUR HYUNDAI WARNING: the rear shelf as they may move forward during B150C02A-AAT Larger Children The purpose of the fold-down rear seatbacks braking or in an accident and strike vehicle is to allow you to carry longer objects than passengers.
Page 20 B160A01S-GAT B150G01A-AAT CARE OF SEAT BELTS ed to your Hyundai Dealer. Do Not Lie Down Seat belt systems should never be disassembled To reduce the chance of injuries in the event of an or modified.
Page 21 FEATURES OF YOUR HYUNDAI WARNING: B170A04A-AAT extend and let you move around. If there is a HEIGHT ADJUSTABLE FRONT SEAT o The height adjuster must be in the locked sudden stop or impact, however, the belt will lock SHOULDER BELT (If installed) position when the vehicle is moving.
Page 22 FEATURES OF YOUR HYUNDAI WARNING: B210A01A-AAT B230A03A-GAT To Release the Seat Belt CHILD RESTRAINT SYSTEM o A child restraint system must be placed in the rear seat. Never install a child or infant (If Installed) seat on the front passenger's seat.
Page 23 On outboard rear seats o If the seat belt will not properly fit the child restraint system manufacturer. child, Hyundai recommends the use of an o If the seat belt does not operate as de- approved booster seat in the rear seat in...
Page 24 FEATURES OF YOUR HYUNDAI B230B02GK-GAT B230E02GK-GAT 1. Route the child restraint seat strap over the Using a Child Restraint System with Securing a Child Restraint System with seatback. For vehicles with adjustable headrests, route "Tether Anchorage" System "Tether Anchorage" System...
Page 25 2. Connect the tether strap hook to the child anchorage-points in a way you can hear it click- the Hyundai ISOFIX GR1 / Hyundai Duo / Römer restraint hook holder and tighten to secure ing (check by pulling!) and has to be fixed with the ISOFIX GR1 and the Römer Duo ISOFIX / Britax...
Page 26 Passenger Outboard Center rear seat to the ISOFIX anchors. In a crash, Your Hyundai vehicle is equipped with driver's 0 : Up to 10 kg the child restraint seat ISOFIX attachments and front passenger's pre-tensioner seat belts. (0 ~ 9 months)
Page 27 Do not attempt to inspect or replace the dent in which the pre-tensioner seat belts pre-tensioner seat belts yourself. This B180B01GK were activated. must be done by an authorized Hyundai The seat belt pre-tensioner system consists dealer. mainly of the following components. CAUTION:...
Page 28 The SRS is designed to deploy the airbags Your Hyundai is equipped with a Supplemental ment threshold speed. only when an impact is sufficiently severe Restraint (Airbag) System. The indications of the o The driver should sit back as far as pos- and when the impact angle is less than 30°...
Page 29 FEATURES OF YOUR HYUNDAI o Do not tamper with or disconnect SRS B240B01GK-GAT The airbag modules are located both in the SRS Components and Functions wiring, or other components of the SRS center of the steering wheel and in the front system.
Page 30 FEATURES OF YOUR HYUNDAI CAUTION: o The SRS can function only when the igni- When installing a container of liquid air fresh- tion key is in the "ON" position. If the SRS ener inside a vehicle, do not place it near the...
Page 31 B990B02Y fastened. The driver's hands should be Any work on the SRS system, such as removing, Your Hyundai is equipped with a side impact placed on the steering wheel at the 9:00 installing, repairing, or any work on the steering airbag in each front seat.
Page 32 Extreme Hazard! Do not use a reward scrapped, certain safety preca utions must be observed. Your Hyundai dealer knows facing restraint on a seat protected by an these precautions and can give you the...
Page 33 FEATURES OF YOUR HYUNDAI B250A01GK-GAT INSTRUMENTS AND CONTROLS 12 3 5 67 89 10 1. Head Light Leveling Device (If installed) 2. Traction Control System (If installed) 3. Panel Brightness Control Knob (Rheostat Switch) (If installed) 4. Multi-Function Light 5. Windshield Wiper/Washer Switch 6.
Page 34 FEATURES OF YOUR HYUNDAI B260A01GK-GAT INSTRUMENT CLUSTER AND INDICATOR LIGHTS 2 3 4 HGK026C 11 12 13 151617 18 1920 21 22 23 1. Speedometer 8. Tachometer 17. Malfunction Indicator Light (If installed) 2. Turn Signal Indicator Light 9. Traction Control Indicator Light (If installed) 18.
Page 35 ABS. beam or flash position. If this occurs, have your vehicle checked by your Hyundai dealer as soon as possible. The normal braking system will still be operational, but with- out the assistance of the anti-lock brake system. 1- 27...
Page 36 If you suspect brake trouble, have your brakes greater pedal pressure are required to stop the checked by a Hyundai dealer as soon as car. Also, the car will not stop in as short a possible. Driving your car with a problem in...
Page 37 ENGINE COOLANT TEMPERATURE when the brake pedal is pushed down firmly. GAUGE Excessive rotor damage will result if the worn pads are not replaced. See your Hyundai dealer B260E01HP-GAT immediately. Seat Belt Warning Light (If Installed) The seat belt warning light blinks for about 6 seconds when the ignition key is turned from the "OFF"...
Page 38 If you suspect cooling system HGK131A HGK028A trouble, have your cooling system checked by a Hyundai dealer as soon as possible. The tachometer registers the speed of your en- Function of digital odometer/trip odom- gine in revolutions per minute (rpm).
Page 39 FEATURES OF YOUR HYUNDAI B400B01GK-GAT 1. Odometer TRIP COMPUTER The odometer records the total driving distance DISTANCE TO EMPTY in kilometers or miles, and is useful for keeping a A Type record for maintenance intervals. AVERAGE SPEED NOTE: Any alteration of the odometer may void your warranty coverage.
Page 40 FEATURES OF YOUR HYUNDAI NOTE: B330C01GK-GAT 3. DRIVE TIME MULTI GAUGE (If installed) o If the distance to empty is indicated "- -", have the trip computer system checked by Multi gauge is consists of torque gauge, instan- A Type your authorized Hyundai dealer.
Page 41 Check for a burned- out fuse or bulb or see your Hyundai dealer. HGK231 HGK039...
Page 42 "AUTO", the (If Installed) tail lights and headlights will be turned automati- Your Hyundai is equipped with daytime running cally on or off according to external illumination. lights. The daytime running lights are used to improve visibility for oncoming traffic.
Page 43 FEATURES OF YOUR HYUNDAI B350B01O-AAT To use the intermittent wiper feature, place the Mist Wiper Operation Windshield Washer Operation wiper switch in the "INT" position. With the switch in this position, the interval between wipes can be varied from 2 to 10 seconds by turning the interval adjuster barrel.
Page 44 FEATURES OF YOUR HYUNDAI B370A01A-AAT B380A01A-AAT B400A01A-AAT HAZARD WARNING SYSTEM REAR WINDOW DEFROSTER DIGITAL CLOCK (If Installed) SWITCH A Type A Type B Type B Type HGK140 HGK143 B380A01GK The hazard warning system should be used There are three control buttons for the digital whenever you find it necessary to stop the car in clock.
Page 45 The ashtray If it is necessary to replace the cigarette lighter, lamp will only illuminate when the exterior body use only a genuine Hyundai replacement or its lights are switched on. approved equivalent.
Page 46 HGK029 Your HYUNDAI is equipped with a sliding sun- shade which you can manually adjust to let in light with the sunroof closed, or to block sunlight.
Page 47 FEATURES OF YOUR HYUNDAI WARNING: CAUTION: B460D03GK-AAT Manual Operation of Sunroof Never adjust the sunshade while driving. o Do not open the sunroof in severely cold temperature or when it is covered with ice If the sunroof does not electrically operate: or snow.
Page 48 FEATURES OF YOUR HYUNDAI 3. Push and turn the wrench clockwise to close B480A01GK-GAT B491A01F-GAT MAP LIGHT SPECTACLE CASE (If Installed) or counterclockwise to open the sunroof. B460E02GK-GAT Resetting the Sunroof System If the battery has been recharged, disconnected or if the sunroof is operated with the hexagonal head wrench manually, you may need to reset the sunroof.
Page 49 FEATURES OF YOUR HYUNDAI CAUTION: B500A01A-AAT B510B01Y-AAT GLOVE BOX OUTSIDE REAR VIEW MIRROR o Do not operate the switch continuously for an unnecessary length of time. Electric Type o Scraping ice from the mirror face could cause permanent damage. To remove any ice, use a sponge, soft cloth or approved deicer.
Page 50 Adjust the rearview mirror to the desired position. B520A01GK Your Hyundai is equipped with a day/night inside rearview mirror. The "night" position is selected by flipping the tab at the bottom of the mirror B510C01GK toward you.
Page 51 FEATURES OF YOUR HYUNDAI B530A01A-AAT B360A01F-AAT B360B01GK-GAT PARKING BRAKE FRONT FOG LIGHT SWITCH REAR FOG LIGHT SWITCH (If Installed) (If installed) HGK178 HGK142 HGK183 Always engage the parking brake before leaving the car. This also turns on the parking brake To turn on the front fog lights, push the switch.
Page 52 FEATURES OF YOUR HYUNDAI B550A01S-GAT B620A01S-AAT 1. Pull the release knob to unlatch the hood. HIGH-MOUNTED REAR STOP LIGHT FRONT DOOR EDGE WARNING LIGHT A Type B Type C Type B550A01GK HGK098 B620A01GK 2. Press the secondary latch lever up and lift the In addition to the lower-mounted rear stoplights hood.
Page 53 FEATURES OF YOUR HYUNDAI B560A01A-AAT B540A01F-AAT REMOTE FUEL-FILLER LID RELEASE TAIL GATE Remote Tail Gate Release HGK124 WARNING: HGK105 Gasoline vapors are dangerous. Before refu- The fuel-filler lid may be opened from inside the eling, always stop the engine and never allow...
Page 54 HGK145 B540C01GK Do not close an open tailgate (rear hatch) Your Hyundai is equipped with sun visors to give To open the tail gate, insert the key and turn it while a person(s) is sitting upright on the rear the driver and front passenger either frontal or clockwise to unlock.
Page 55 FEATURES OF YOUR HYUNDAI B600A01HP-AAT B610A01S-GAT Some objects can be kept in the net of the STEERING WHEEL TILT LEVER HORN luggage compartment. Use the luggage net on the floor or at the back of (If installed) the luggage compartment to prevent objects To adjust the steering wheel: from sliding.
Page 56 FEATURES OF YOUR HYUNDAI WARNING: B660B01E-GAT B660D01E-GAT To Set the Cruise Speed To Resume the Preset Speed To avoid accidental cruise control engage- ment, keep the cruise control main switch off when not using the cruise control. B660C01E-GAT To Cancel the Cruise Speed...
Page 57 FEATURES OF YOUR HYUNDAI o During cruise-control driving with a manual B660F01E-AAT To Reset at a Slower Speed transaxle vehicle, do not shift into neutral without depressing the clutch pedal, or the engine will be overrevved. If this happens, depress the clutch pedal or release the main switch.
Page 58 FEATURES OF YOUR HYUNDAI B710A01GK-GAT B710A01S-AAT HEATING AND COOLING CONTROL VENTILATION To operate the ventilation system: o Set the air intake control to "Fresh" mode o To direct all intake air to the dashboard vents, set the airflow control to "Face".
Page 59 FEATURES OF YOUR HYUNDAI B670A01GK-GAT B670B01A-AAT B670E02A-AAT Fan Speed Control (Blower Control) ROTARY TYPE Temperature Control Cool Warm HGK006 HGK002 HGK007 1. Air Conditioning switch This is used to turn the blower fan on or off and This control is used to adjust the degree of to select the fan speed.
Page 60 FEATURES OF YOUR HYUNDAI B670C01FC-AAT With the "Recirculation" mode selected, air from B670D01GK-AAT Air Intake Control Air Flow Control within the passenger compartment will be drawn through the heating system and heated or cooled according to the function selected. NOTE: o It should be noted that prolonged opera- tion of the heating in "Recirculation"...
Page 61 FEATURES OF YOUR HYUNDAI If the "Floor-Defrost" mode is selected, the A/C will turn on automatically and "Fresh" mode will be activated. HGK021 HGK023 Floor-Level Face-Level Air is discharged through the floor vents, wind- Selecting the "Face" mode will cause air to be...
Page 62 FEATURES OF YOUR HYUNDAI B690A01S-AAT B720A02FC-GAT o Set the temperature control to warm. HEATING CONTROLS DEFROSTING/DEFOGGING o Set the fan speed control to position "3" or "4". For normal heating operation, set the air intake NOTE: control to the "Fresh" position and the air flow control to "Floor".
Page 63 FEATURES OF YOUR HYUNDAI B740A01S-AAT B740B01S-AAT B740C01S-AAT AIR CONDITIONING SYSTEM Air Conditioning Operation Dehumidified Heating For dehumidified heating: (If installed) Cooling Air Conditioning Switch o Turn on the fan control switch. o Turn on the air conditioning switch. The air conditioning indicator light should come on at the same time.
Page 64 FEATURES OF YOUR HYUNDAI B740D01A-AAT Operation Tips o If the interior of the car is hot when you first get in, open the windows for a few minutes to expel the hot air. o When you are using the air conditioning sys- tem, keep all windows closed to keep hot air out.
Page 65 FEATURES OF YOUR HYUNDAI B970A01Y-AAT AUTOMATIC HEATING AND COOLING CONTROL SYSTEM (If lnstalled) Your Hyundai is equipped with an automatic heating and cooling control system controlled by simply setting the desired temperature. B970B01GK-GAT Heating and Cooling Controls TYPE A (Without Air Quality System)
Page 66 FEATURES OF YOUR HYUNDAI NOTE: B970C02E-GAT Automatic Operation If the battery has been discharged or discon- nected, the temperature mode will reset to centigrade degrees. This is a normal condition and you can change the temperature mode from centigrade to farenheit as follows;...
Page 67 FEATURES OF YOUR HYUNDAI B995A01Y-GAT B980B01Y-AAT B670C01GK-AAT AMBIENT SWITCH Fan Speed Control Switch Air Intake Control Switch (Without A.Q.S) HGK015 HGK009 The fan speed can be set to the desired speed by Pressing the OUTSIDE button displays the ambient HGK008-1...
Page 68 FEATURES OF YOUR HYUNDAI With the "Recirculation" mode selected, air from B980C01GK-GAT Exhaust gas cutoff mode : Air Intake Control Switch (With A.Q.S) within the passenger compartment will be drawn Air enters the vehicle from the outside. through the heating system and heated or cooled...
Page 69 FEATURES OF YOUR HYUNDAI B980D01Y-AAT makes it possible to have cooler air from the Heating and Cooling System Off dashboard vents and warmer air from the floor Press the "OFF" button to stop the operation of outlets at the same time.
Page 70 FEATURES OF YOUR HYUNDAI B760A03GK-GAT Floor-Defrost Level AIR CONDITIONER FILTER (IN FRONT When selecting the "Floor-Defrost" mode, the OF BLOWER UNIT) (If Installed) indicator light will come on and the air will be discharged through the windshield defrost nozzle, Outside air...
Page 71 FEATURES OF YOUR HYUNDAI B750A02A-AAT AM reception FM radio station STEREO SOUND SYSTEM Ionosphere Unobstructed How Car Audio Works area FM reception Ionosphere Mountains Buildings Iron bridges SSAR011A SSAR012A Obstructed area AM broadcasts can be received at greater dis- FM broadcasts are transmitted at high frequen- tances than FM broadcasts.
Page 72 FEATURES OF YOUR HYUNDAI B750B02Y-AAT Using a cellular phone or a two-way radio When a cellular phone is used inside the vehicle, noise may be produced from the audio equip- ment. This does not mean that something is wrong with the audio equipment. In such a case, use the cellular phone at a place as far as possible from the audio equipment.
Page 73 FEATURES OF YOUR HYUNDAI H240A01O-GAT STEREO RADIO OPERATION (H250) (If Installed) 5. BAND Selector 3. TREBLE/FADER Control Knob (TREB/FAD) 6. PRESET Buttons 2. BASS/BALANCE Control Knob (BASS/BAL) 7. SCAN Button 4. TUNE/SEEK Select Button 1. POWER ON/OFF, VOLUME Control Knob...
Page 74 FEATURES OF YOUR HYUNDAI H240B02A-GAT FAD (Fader Control) Knob 6. PRESET STATION SELECT Button 1. POWER ON-OFF Control Knob Pull the treble control knob further out. Six (6) stations for AM, FM and FM2 respective- The radio unit may be operated when the igni-...
Page 75 FEATURES OF YOUR HYUNDAI 7. SCAN Button When the scan button is pressed, the frequency will increase and the receivable stations will be tuned in one after another, receiving each sta- tion for 5 seconds. To stop scanning, press the scan button again.
Page 76 FEATURES OF YOUR HYUNDAI H240C01O-GAT CASSETTE TAPE PLAYER OPERATION (H250) (If Installed) 3. TAPE PROGRAM Button 6. TAPE SLOT 2. AUTO MUSIC SELECT Button 4. EJECT Button 1. FF/REW Button 5. DOLBY SELECT Button H250A01GK 1- 68...
Page 77 FEATURES OF YOUR HYUNDAI NOTE: H240A02O-AAT 1. FF/REW Button When tape operation is abnormal or ER8 fault o The FF (fast forward tape winding) starts when code is displayed, press the eject button button is pressed during PLAY or more than 5 seconds to reset the deck func- REW.
Page 78 FEATURES OF YOUR HYUNDAI B250A01GK-GAT CD AUTO CHANGER (H250) (If Installed) 1. CD CHANGER Select Button 3. TRACK UP/DOWN 6. SCAN Button 4. FF/REW Button 5. REPEAT Button 2. DISC Select Button H250A01GK 1- 70...
Page 79 This process will be continued until you push be used even if the radio is being used. The the button again. Hyundai CD changer can hold up to eight discs. The disc number will be lit, and the track number, 6. SCAN Button and elapsed time will be displayed.
Page 80 FEATURES OF YOUR HYUNDAI H260A01O-AAT STEREO RADIO OPERATION (H260) (If Installed) 3. BASS/TREBLE Control Knob 4. SCAN Button 6. BAND Selector 7. PRESET Button 5. TUNE/SEEK Select Button 1. POWER ON-OFF/VOLUME/BALANCE Control Knob 2. FADER Control Knob H260A01O 1- 72...
Page 81 FEATURES OF YOUR HYUNDAI H260B02E-AAT 3. BASS Control Knob 6. BAND Selector 1. POWER ON-OFF Control Knob Press to pop the knob out and turn to the left or Pressing the button changes the AM, FM1 FM/AM The radio unit may be operated when the ignition right for the desired bass tone.
Page 82 FEATURES OF YOUR HYUNDAI You should then release the button, and pro- ceed to program the next desired station. A total of 18 stations can be programmed by selecting one AM and two FM stations per button. o When completed, any preset station may be recalled by selecting AM, FM or FM2 band and the appropriate station button.
Page 83 FEATURES OF YOUR HYUNDAI H260B01O-AAT COMPACT DISC PLAYER OPERATION (H260) (If Installed) 4. SCAN Button 1.Playing CD 3. TRACK UP/DOWN 6. EJECT Button 2. FF/REW Button 5. REPEAT Button H260A01O 1- 75...
Page 84 FEATURES OF YOUR HYUNDAI o The preset station frequencies are all B260D02O-AAT 5. REPEAT Button 1. Playing CD erased when the car battery is discon- o To repeat the track you are currently listening o Insert the CD with the label facing upward.
Page 85 FEATURES OF YOUR HYUNDAI B260E01E-AAT CD AUTO CHANGER (H260) (If Installed) 6. SCAN Button 1. CD Select Button 3. TRACK UP/DOWN 4. FF/REW Button 5. REPEAT Button 2. DISC Select Button H260A01O 1- 77...
Page 86 This process will be continued until you push be used even if the radio is being used. The the button again. Hyundai CD changer can hold up to eight discs. The disc number will be lit, and the track number, 6. SCAN Button and elapsed time will be displayed.
Page 87 CD DECK MECHANICAL ERROR AFTER RESETTING THE AUDIO SYSTEM, PUSH THE EJECT BUTTON. (EJECT ERROR, LOADING ERROR) IF DISC IS NOT EJECTED, CONSULT YOUR HYUNDAI DEALER. FOCUS ERROR MAKE SURE THE DISC IS NOT SCRATCHED OR DAMAGED. DATA READ ERROR PRESS THE EJECT BUTTON AND PULL OUT THE DISC.
Page 88 FEATURES OF YOUR HYUNDAI B260A01GK-GAT INFINITY SOUND SYSTEM (B260)(If installed) B260A01GK 1. On/Off Switch ( 5. Function button ( Function) 9. Multifunction buttons 2. Tone Button ( 6. Waveband switching button ( Band) 10.Display 3. Road traffic announcement button( 7. CD eject button ( 11.Right rotary control...
Page 89 FEATURES OF YOUR HYUNDAI B260B01GK-GAT 2. Inserting portable panel 4. Activate Tone menu ANTI-THEFT DEVICE Insert the portable panel so that it engages first in Press button. The tone menu is activated. the lower left catch and then in the lower right.
Page 90 FEATURES OF YOUR HYUNDAI B260D01GK-GAT 6.Adjust Treble 10.Linear Adjustment RADIO OPERATION Press button and then multifunction button It controls the amplification ratio from high to low 1. Select operating Mode (2) "-" or "+". TREB and the set value are dis- tone.
Page 91 FEATURES OF YOUR HYUNDAI B260E01GK-GAT 5. FM, AM station search CD OPERATION Turn the right rotary control to the left/right in 1.CDs - insert / eject desired waveband. The radio searches in de- scending/ascending order. Press button briefly; the display folds down- wards and the CD slot with the printed side upwards.
Page 92 FEATURES OF YOUR HYUNDAI By against pressing the multifunction button "T" (within 10 seconds), the number of tracks and total playing time of the CD currently being played are displayed for approx.10 seconds 6. Random play The random play is activated by pressing the multifunction button (4) "RP".
Page 93 FEATURES OF YOUR HYUNDAI B850A02F-AAT B860A01A-AAT Storage CARE OF DISC Care of Cassette Tapes When not in use, place your discs in their indi- Proper Handling vidual cases and store them in a cool place away from the sun, heat, and dust.
Page 94 FEATURES OF YOUR HYUNDAI Head Cotton applicator HGK062 SSAR042B B860A04A o Be sure that the cassette label is not loose or o The playback head, capstan and pinch rollers NOTE: peeling off or tape ejection may be difficult. will develop a coating of tape residue that can Look at a tape before you insert it.
Page 95 FEATURES OF YOUR HYUNDAI B870A01A-GAT ANTENNA Fixed Rod Antenna B870A01F Your car uses a fixed rod antenna to receive both AM and FM broadcast signals. This antenna is a removable type. To remove the antenna, turn the antenna counterclockwise. To install the antenna, turn the antenna clockwise.
Page 96: Driving Your Hyundai
Hyundai dealer. o Do not run the engine in an enclosed area.
Page 97 To unlocking the steering wheel, insert the START To Start the Engine key, and then turn the steering wheel and key o If your Hyundai is equipped with a manual simultaneously. transaxle, place the shift lever in neutral and C040A01E depress the clutch pedal fully.
Page 98 DRIVING YOUR HYUNDAI C070C01A-AAT C050A01A-AAT C050B01A-GAT STARTING To remove the ignition key Normal Conditions: The Starting Procedure: 1. Insert key, and fasten the seat belt. LOCK 2. Depress the clutch pedal fully and place the LOCK gearshift lever (manual transaxle) in neutral or the selector lever (automatic transaxle) in "P"...
Page 99 R(Reverse), put the HGK181 shift lever in N(Neutral) position and re- Your Hyundai's manual transaxle has a conven- lease the clutch. Press the clutch pedal tional shift pattern. This shift pattern is imprinted back down, and then shift into 1 on the shift knob.
Page 100 DRIVING YOUR HYUNDAI WARNING: C070D03A-AAT C070E01GK-GAT Good Driving Practices RECOMMENDED SHIFT POINTS o Avoid high cornering speeds. o Never take the car out of gear and coast down o Do not make quick steering wheel move- The shift points as shown below are recom- a hill.
Page 101 (Park) position unless the vehicle is fully stopped. Failure to observe this caution will HGK174 cause severe damage to the transaxle. The highly efficient Hyundai automatic transaxle has four forward speeds and one reverse speed. The individual speeds are selected automatical- C090C01A-AAT...
Page 102 DRIVING YOUR HYUNDAI CAUTION: o Before driving away from a stop on a C090E01O-AAT o D(Drive): o In sports mode, the driver must execute slippery road, push the selector lever for- Use for normal driving. The transaxle will auto- shifts in accordance with prevailing road ward into the +(UP) position.
Page 103 "N" to any other position with the acceler- son wearing a seatbelt. do so and call your Hyundai dealer for assis- ator pedal depressed. o The risk of rollover is greatly increased if tance.
Page 104 DRIVING YOUR HYUNDAI WARNING: also increases the wear of the brake compo- o Do not hold the vehicle on the upgrade with nents. the accelerator pedal. This can cause the Your ABS will not prevent accidents due to o If a tire goes flat while you are driving, apply transmission to overheat.
Page 105 DRIVING YOUR HYUNDAI CAUTION: 2) When the traction control system is oper- C300A03Y-GAT TRACTION CONTROL SYSTEM (TCS) When the TCS indicator blinks, SLIP control ating properly, you can feel a slight pulsa- (If installed) has been activated. It also means that the tion in the vehicle.
Page 106 Always maintain a safe distance from other always be taken under gentle acceleration. If you your Hyundai should be kept clean and free of vehicles so you can avoid unnecessary brak- follow these suggestions, tire wear will be held to corrosive materials.
Page 107 The proper temperature for using the immo- deceleration, use engine braking to the fullest by your Hyundai dealer or a service station. bilizer key is from -40°C to 80°C. If you heat extent. Sudden brake applications on snowy or the immobilizer key over 80°C to open the...
Page 108 Ask your result in reduced traction or tire failure. first or reverse gear (manual transaxle) and Hyundai dealer for further details before towing. NOTE: block the rear wheels so the car cannot roll. Then CAUTION release the parking brake.
Page 109 DRIVING YOUR HYUNDAI C190C02Y-GAT another vehicle. To eliminate this potentially dan- Trailer Brakes gerous situation, safety chains, attached be- If your trailer is equipped with a braking system, tween your car and the trailer or towed vehicle, make sure it conforms to federal and/or local are required in most provinces.
Page 110 DRIVING YOUR HYUNDAI 4. The maximum permissible static vertical C190F01A-GAT Trailer or Vehicle Towing Tips load on the coupling device: Maximum 1. Before towing, check hitch and safety chain connections as well as proper operation of 1.6 L Towable Weight...
Page 111 DRIVING YOUR HYUNDAI NOTE: 9. If the trailer has electric brakes, start your vehicle and trailer moving, and then apply the When towing check transaxle fluid more fre- trailer brake controller by hand to be sure the quently. brakes are working. This lets you check your CAUTION: electrical connection at the same time.
Page 112: What To Do In An Emergency
Over Slowly Reconnect any that may be disconnected or loose. 3 Check the fuel line in the engine compart- ment. 4 If engine still refuses to start, call a Hyundai dealer or seek other qualified assistance. D010D01A-AAT Battery HGK184A If Engine Stalls While Driving WARNING: 1.
Page 113 (because the lights were left on, stop). etc.), have the charging system checked by your WARNING: Hyundai dealer. While the engine is running, keep hair, hands, and clothing away from moving parts such as the fan and drive belts to prevent injury.
Page 114 5. The temporary spare tire should not be used be checked as soon as possible by a Hyundai on any other wheels, nor should standard dealer.
Page 115 WHAT TO DO IN AN EMERGENCY D050A01A-AAT D060A01A-AAT D060K01FC-GAT IF YOU HAVE A FLAT TIRE CHANGING A FLAT TIRE Wheel Cap (If Installed) If a tire goes flat while you are driving: 1. Take your foot off the accelerator pedal and let the car slow down while driving straight Groove ahead.
Page 116 WHAT TO DO IN AN EMERGENCY 4. Reinstall the wheel cap by fitting the boss of The jack is located behind the right side of D060D02A-AAT 3. Loosen Wheel Nuts the wheel cap in the groove of the wheel, luggage trim. Remove the jack cover by un- hitting the center of the wheel cap with your screwing the bolts.
Page 117 WHAT TO DO IN AN EMERGENCY D060E01A-AAT D060F02E-AAT D060G02Y-AAT 4. Put the Jack in Place 5. Raising the Car 6. Changing Wheels Wrench bar Wheel nut wrench HGK186 HFC4022 HGK232 The base of the jack should be placed on firm, Loosen the wheel nuts and remove them with After inserting a bar into the wheel nut wrench, level ground.
Page 118 WHAT TO DO IN AN EMERGENCY D060H02A-AAT D060I01E-GAT 7. Re-install Wheel Nuts 8. Lower Vehicle and Tighten Nuts STA3071H WARNING: HGK194 D060H01GK Wheels and wheel covers may have sharp To reinstall the wheel, hold it on the studs, put the Lower the car to the ground by turning the wheel edges.
Page 119 Also, be sure that the ignition key is in Always reinstall the valve cap after checking or your Hyundai dealer or a commercial tow truck the "ACC" position. This is necessary to adjusting tire pressure. If the cap is not replaced, service.
Page 120 WHAT TO DO IN AN EMERGENCY D080C02A-GAT For emergency towing when no commercial tow Towing a Car With an Automatic vehicle is available, attach a tow cable, chain or Transaxle strap to one of the towing hooks under the front/ rear of your car.
Page 121 WHAT TO DO IN AN EMERGENCY D120A02A-GAT IF YOU LOSE YOUR KEYS Information about the key of immobilizer system (if installed) will be found on page 1-2. 3-10...
Page 122: Corrosion Prevention & Appearance Care
Mud is a particular corrosive because it is slow to underside thoroughly when winter is over. term corrosion resistance your Hyundai can de- dry and holds moisture in contact with the ve- liver, the owner's cooperation and assistance is o When cleaning underneath the car, give par- hicle.
Page 123 Check under the car is to remove water from the car so it will dry age. These are available at your Hyundai dealer mats periodically to be sure the carpeting is dry. without water spots. Don't rub, this can damage or auto parts outlet.
Page 124 Do not use gasoline, Hyundai. They are: solvent, paint thinner or other strong cleaners. E030B01A-AAT Spot Cleaning o Be careful not to spill battery electrolyte or Don't use gasoline, strong solvents or corrosive hydraulic brake fluid on the bumpers.
Page 125 E040C01A-AAT If you have any questions about the care of your Cleaning the Carpets car, consult your Hyundai dealer. Use a foam-type carpet cleaner. Cleaners of this type are available in aerosol cans in liquid form or powder. Read the instructions and follow them exactly.
Page 126: Vehicle Maintenance Requirements
Hyundai or you fill the with conditions of the emissions system war- fuel tank. A list of these items will be found on o Specified scheduled procedures ranty.
Page 127 VEHICLE MAINTENANCE REQUIREMENTS F030A01GK-GAT SCHEDULED MAINTENANCE The following maintenance services must be performed to assure good vehicle control and performance. Keep receipts for all vehicle services to protect your warranty. Where both mileage and time are shown, the frequency of service is determined by whichever occurs first. F030B03GK-GAT R :Replace I : Inspect and, after Inspection, clean, adjust, repair or replace if necessary.
Page 128 VEHICLE MAINTENANCE REQUIREMENTS F030C01GK-GAT R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary KILOMETERS X 1000 DESCRIPTION MONTHS GENERAL MAINTENANCE COOLING SYSTEM COOLANT See Note (1) MANUAL TRANSAXLE OIL AUTOMATIC European Community Only TRANSAXLE FLUID Except European Community BRAKE HOSES AND LINES...
Page 129 VEHICLE MAINTENANCE REQUIREMENTS F040A03GK-GAT MAINTENANCE UNDER SEVERE USAGE CONDITIONS The following items must be serviced more frequently on cars normally used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary MAINTENANCE DRIVING MAINTENANCE ITEM...
Page 130 F060H01A-AAT required. o Air Cleaner Filter damage and deformation. Replace any dam- aged parts immediately. A Genuine Hyundai air cleaner filter is recom- F060B02A-AAT mended when the filter is replaced. o Drive Belts F060G01A-AAT Inspect all drive belts for evidence of cuts,...
Page 131 VEHICLE MAINTENANCE REQUIREMENTS F070C01A-AAT F070G02A-AAT F070L01A-AAT o Coolant o Brake Fluid o Suspension Mounting Bolts The coolant should be changed at the Check brake fluid level in the brake fluid reser- Check the suspension connections for loose- intervals specified in the maintenance sched- voir.
Page 132 VEHICLE MAINTENANCE REQUIREMENTS F070Q01A-AAT o Air Conditioning Refrigerant Check the air conditioning lines and connec- tions for leakage and damage. Check air condi- tioning performance according to the relevant shop manual if necessary.
Page 133: Do-It-Yourself Maintenance
DO-IT-YOURSELF MAINTENANCE 6. DO-IT-YOURSELF MAINTENANCE G010A01GK-GAT ENGINE COMPARTMENT (1.6 DOHC) CAUTION: When inspecting or servicing the engine, you should handle tools and other heavy objects carefully so that the plastic rocker cover of the engine is not damaged. HGK238 1. Engine oil filler cap 6.
Page 134 DO-IT-YOURSELF MAINTENANCE G010A01GK-AAT ENGINE COMPARTMENT (2.0 DOHC CVVT) CAUTION: When inspecting or servicing the engine, you should handle tools and other heavy objects carefully so that the plastic rocker cover of the engine is not damaged. HGK059 1. Engine oil filler cap 6.
Page 135 DO-IT-YOURSELF MAINTENANCE G010B01GK-GAT ENGINE COMPARTMENT (2.7 V6) CAUTION: When inspecting or servicing the engine, you should handle tools and other heavy objects carefully so that the plastic rocker cover of the engine is not damaged. HGK209 9. Radiator cap 1. Power steering fluid reservoir 5.
Page 136 Exhaust system condition efficient oil is recommended. ly, inspect it carefully and seek assistance from o Light condition and operation your Hyundai dealer if service is needed. o Windshield glass condition o Wiper blade condition o Paint condition and body corrosion...
Page 137 DO-IT-YOURSELF MAINTENANCE G030C01A-AAT G030D01A-GAT 2.0 L (DOHC CVVT) To Check the Oil Level Adding Oil DOHC DOHC HGK259 See the lubrication chart on the page 9-3. HGK210 HGK211 If the oil level is close to or below the "L" mark, Before checking the oil, warm up the engine to NOTE: add oil until it reaches the "F"...
Page 138 DO-IT-YOURSELF MAINTENANCE G350A01A-GAT G040A02GK-GAT 3. Slide underneath the car and loosen the ENGINE OIL CONSUMPTION CHANGING THE OIL AND FILTER drain plug by turning it counterclockwise with a wrench of the proper size. Be sure Function of Engine Oil DOHC that a drain pan is in position to catch the oil Engine oil has the primary function of lubricat- as it drains out, then remove the drain plug.
Page 139 Never allow the concentration of anti- quently. If the level drops again, visit your freeze to exceed the 60% level or go below the Hyundai dealer for an inspection and diagnosis G050A01A-AAT 35% level, or damage to the cooling system CHECKING AND CHANGING THE EN- of the reason.
Page 140 This is a normal spark plugs are replaced, always use spark cool. condition. plugs recommended by Hyundai. The use of 2. Be sure your drain receptacle is in place. G060A02Y-GAT other spark plugs can result in loss of perfor- Open the drain cock on the radiator.
Page 141 2.7L Engines should be changed by an au- 5. To remove the old spark plug, turn the and can't fall off. thorized Hyundai dealer. wrench handle in a counterclockwise direc- 2. Using a clean cloth, remove any dirt that has tion.
Page 142 The fluid level should be the wiper blades and arms, use a clean sponge put in its place. Genuine Hyundai Replacement checked more frequently during inclement or cloth with a mild soap or detergent and water.
Page 143 Recommended Oil 2. Use your finger or suitable tool to feel inside G110B03A-AAT Use only HYUNDAI GENUINE PARTS MTF the hole. The oil level should be at its bottom Recommended Fluid 75W/90 (API GL-4) in the manual transaxle.
Page 144 DO-IT-YOURSELF MAINTENANCE G110C02Y-GAT Transaxle Fluid Capacity DOHC The fluid capacity of the automatic transaxle is 7.8 liters (8.2 U.S. quarts). Fluid level should be within this range WARNING: The transaxle fluid level should be checked when the engine is at normal operating tem- perature.
Page 145 If the level is at or below Hyundai dealer. The brakes should be the "MIN" mark, carefully add fluid to bring it up G130A01S-AAT checked and inspected for wear at those to "MAX".
Page 146 2. If the air coming out of the in-dash vents is (0.315 in.) not cold, have the air conditioning system NOTE: inspected by your Hyundai dealer. Do not allow any other liquids to contami- nate the brake fluid. Seal damage will result. CAUTION:...
Page 147 Use very light finger pressure and be sensitive to changes in resistance that mark the limits of the freeplay. If the freeplay is greater than specified, have it inspected by your Hyundai dealer and adjusted or repaired if necessary. HGK254 4.
Page 148 Then, using your hand, press down slowly on times and then hold it down with a force of about it is not, have it inspected by your Hyundai the brake pedal until you feel a change in 490N (50 kg, 110 lbs). The brake pedal clear- dealer and adjusted or repaired if necessary.
Page 149 After a belt is re- will see that the metal strip inside the fuse has have a Hyundai dealer determine the cause, placed, the new belt should be adjusted again burned through. If you suspect a blown fuse, repair the system and replace the fusible link.
Page 150 If you re- minutes and then seek medical assistance. clip repaired or replaced by a Hyundai dealer. place a fuse and it blows as soon as the o If battery fluid is in your eyes, rinse out your...
Page 151 Hyundai, you may tween the "MAX" and "MIN" level markings on matically shut off. This is a normal condi- purchase a factory Shop Manual at your Hyundai the fluid reservoir. tion. dealer's parts department. This is the same...
Page 152 DO-IT-YOURSELF MAINTENANCE G260A02A-AAT 3. Disconnect the power cord from the bulb G290A02GK-GAT REPLACING LIGHT BULBS HEADLIGHT AIMING ADJUSTMENT base in the back of the headlight. Before attempting to replace a headlight bulb, 4. Remove the dust cover. Low Beam be sure the switch is turned to the "OFF" 5.
Page 153 DO-IT-YOURSELF MAINTENANCE SPECIFICATION: 1. Keep all tires inflated to the correct pres- G290B01GK-GAT Adjustment After Headlight Assembly sure. "H" 2. Place the vehicle on level ground and press Horizontal center line of headlights from ground: Replacement the front bumper & rear bumper down sev- Low Beam: 679mm (26.7 in.) Vertical eral times.
Page 154 DO-IT-YOURSELF MAINTENANCE G280A02GK-GAT (High) (Low) 11 12 HGK035A Part Name Wattage Part Name Wattage High Mounted Without spoiler 2.4 (LED) Head Light (High/Low) 55/55 Stop LIght With spoiler 3.5 (LED) Map Light Rear Turn Signal Light Front Position Light Combination Stop/Tail Light 21/5 Front Fog Light (If installed)
Page 155 DO-IT-YOURSELF MAINTENANCE G200C01GK-GAT FUSE PANEL DESCRIPTION Engine Compartment PROTECTED COMPONENTS DESCRIPTION FUSE RATING BATT 120A Generator BATT Generator COND Condenser Fan Radiator Fan Engine Control, ECM. ATM Control Ignition, Start Relay ABS 1 ABS 2 BLOWER Blower Injector SNSR Sensor, ECM F/FOG Front Fog Light TCM, ECM...
Page 156 DO-IT-YOURSELF MAINTENANCE G200D01GK-GAT Inner Panel DESCRIPTION FUSERATING PROTECTED COMPONENTS IG COIL Ignition Coil, ECM AMP. Multi Gauge Unit B/UP LAMP B/Up Lamp A/BAG IND Air Bag Indicator A/BAG Air Bag HTD MIR Outside Mirror Defroster HAZARD Hazard Warning Light R/WIPER Rear Window Wiper TAIL-RH Tail Light...
Page 157: Emission Control Systems
Its purpose is to re- Purge Control Solenoid Valve tained by an authorized Hyundai dealer in ac- move certain engine emission products from The purge control solenoid valve is controlled cordance with the maintenance schedule in this the engine's exhaust.
Page 158 Your Hyundai should not be either pushed or pulled to get it started. This can cause the catalytic converter to overload. o Take care not to stop your Hyundai over any combustible material such as grass, paper, leaves or rags. As these materials could come in contact with the catalytic converter and could cause a fire.
Page 159: Consumer Information
I020A01A-AAT PRESSURE, kPa (PSI) TIRE INFORMATION TIRE HGK220 UP TO The tires supplied on your new Hyundai are UP TO 2 SIZE SIZE PERSONS MAX. LOAD chosen to provide the best performance for The vehicle identification number (VIN) is the normal driving.
Page 160 WARNING: evenly between rotations, have the car checked o When driving on roads covered with snow by a Hyundai dealer so the cause may be or ice, drive at less than 30 km/h (20 corrected. I040A01S-GAT After rotating, adjust the tire pressures and be mph).
Page 161 TIRE BALANCING HGK248 A tire that is out of balance may affect handling and tire wear. The tires on your Hyundai were The original tires on your car have tread wear balanced before the car was delivered but may indicators. The tread wear indicators appear need balancing again during the years you own when the tread depth is 1.6 mm (0.06 in.).
Page 162: Vehicle Specifications
VEHICLE SPECIFICATIONS J030A01GK-GAT 9. VEHICLE SPECIFICATIONS TIRE Standard 195/65 R15 Option 205/55 R16, 215/45 R17 J010A01GK-GAT MEASUREMENT mm (in.) Overall length 4395(173) J035A01GK-GAT Overall width 1760(69.3) SPARE TIRE Overall height (unladen) 1330(52.4) Standard T125/70 R16 (Temporary) Wheel base 2530(99.6) Front 1490(58.7) Wheel tread J040A02GK-GAT...
Page 163 VEHICLE SPECIFICATIONS J070A03GK-GAT ENGINE SPECIFICATION ITEMS 1.6 L 2.0 L 2.7 L Engine Type 2.7 6 Cylinder V6 DOHC 4-Cyl., In-line DOHC Bore x Stroke 76.5 x 87 82 x 93.5 86.7 x 75 Displacement (cc) 1,599 1,975 2,656 Firing order 1 - 3 - 4 - 2 1 - 3 - 4 - 2 1 - 2 - 3 - 4 - 5 - 6...
Page 164 Engine Oil Consumption Normal driving condition MAX. 1L / 1000 Km Severe driving condition Transaxle Manual HYUNDAI GENUINE PARTS MTF 75W/90 (API GL-4) 5 speed:2.15(2.27, 1.86) 6 speed:2.2(2.32, 1.94) 7.8 (8.2, 6.9) Auto DIAMOND ATF SP-III or SK ATF SP-III As required...
Page 165: Index
Cooling Fans ..................6-19 Corrosion Protection Battery ..................2-11, 6-18 Cleaning the interior ............... 4-3 Brake Protecting your Hyundai from corrosion ......... 4-1 Anti-lock system ................2-9 Washing and waxing ..............4-2 Checking the brakes ..............6-13 Cruise Control ................... 1-47 Fluid ....................
Page 166 INDEX Driving Fuel Filler Lid Economical driving ............... 2-11 Remote release ................1-45 Smooth cornering ................. 2-11 Fuse Panel Description ............6-23 ~ 6-24 Winter driving ................2-11 Fuses ....................6-17 Emissions Control Systems ..............7-1 Engine General Everyday Checks ..............6-4 Before starting the engine ..............
Page 167 INDEX Jump Starting ..................3-1 Rear Seats Before Folding the Rear Seats ............. 1-10 Fold down ..................1-10 Keys ....................1-2 Rear seat entry ................1-10 If you lose your keys ..............3-10 Rear Seat Positions ............... 1-9 Positions ..................2-2 Rear Window Defroster Switch ............
Page 168 INDEX Tires Balancing ..................8-3 Washer fluid ..................6-10 Chains .................... 8-2 Warning Lights ............... 1-28 ~ 1-29 Changing a flat tire ................. 3-4 Windows Glass ................... 1-7 Windshield Wiper and Washer ............1-34 If you have a flat tire ..............3-4 Information ..................
Page 169 Logo on the package (see below). and built to meet rigid original manu- The export specifications are written facturing requirements. Using imita- in English only. tion, counterfeit or used salvage parts A100A03L is not covered under the Hyundai New A100A02L A100A04L A100A01L...
Page 170 TABLE OF CONTENTS SECTION PAGE 1. CONTROLS AND EQUIPMENT ................1-1 2. DRIVING YOUR HYUNDAI ................. 2-1 3. IN CASE OF EMERGENCY ................3-1 4. APPEARANCE CARE ..................4-1 5. VEHICLE MAINTENANCE REQUIREMENTS ............ 5-1 6. OWNER MAINTENANCE ..................6-1 7.
Page 171 A090A01A-AAT SAFETY AND VEHICLE DAMAGE WARNING This manual includes information titled as WARNING, CAUTION and NOTE. These titles indicate the following: WARNING: This indicates that a condition may result in harm or injury to you or other persons if the warning is not heeded.
Page 172 It is possible for incorrectly installed two way radio equipment including mobile telephones to adversely affect these systems. Before radio equipment of this kind is installed, please contact your Hyundai dealer for recommendation regarding the suitability of the particular radio equipment concerned and the recommended method of installation and equip- ment location.
Page 173 Page 9-3 in the Vehicle Specifications section of the Owner's Manual. Copyright 2003 Hyundai Motor Company. All rights reserved. No part of this publication may be reproduced, stored in any retrieval system or transmitted in any form or by any means without the prior written permission of Hyundai Motor Company.
Page 174 It is recommended that all maintenance operations and repairs are entrusted to a franchised Hyundai dealer to ensure that the latest repair methods, specialized tooling and genuine Hyundai parts are used to ensure the continued reliability and safety of the vehicle.
Page 175 This manual applies to all markets and includes descriptions and explanations of optional as well as standard equipment. As a result, some of the equipment operating descriptions referred to may not apply to the particular vehicle with which this manual is supplied. Please refer to the nearest franchised Hyundai dealer for information regarding current standard and optional equipment levels.
Page 176 A000A01A-EAT This Owners Manual should be considered a part of the car and remain with it when it is sold for the use of the next owner. OWNER I.D. ORIGINAL: NAME: ADDRESS: STREET: TOWN: COUNTY: P.CODE: DATE OF SALE: SUBSEQUENT: NAME: ADDRESS: STREET:...
Page 177: Controls And Equipment
4) Never allow the engine to labour. Use the PETROLS FOR CLEANER AIR gearbox freely and avoid large throttle open- To help contribute to cleaner air, Hyundai recom- ings when the engine speed is below 1,500 mends that you use petrols treated with deter- B010A02GK rpm.
Page 178 AX10020A-1 keys arises. New keys are available from any All of the locks fitted to the vehicle are operated Hyundai dealer by quoting the relevant key num- by the same key. However, since it is possible to ber. lock the doors without the use of the key, care...
Page 179 CONTROLS AND EQUIPMENT B040B01A-AAT B040C01S-AAT B040D01S-AAT Locking and unlocking front doors with Locking From the Outside Locking From the Inside a key UNLOCK UNLOCK LOCK LOCK HGK208-D HGK099-D HGK101-D To lock the doors from the inside, simply close The doors can be locked without a key. o The door can be locked or unlocked with a key.
Page 180 CONTROLS AND EQUIPMENT 3) Once the system is armed, only the hatch- B040G01GK-GAT B070A01A-AAT Central Door Lock THEFT-ALARM SYSTEM back door may be unlocked using the key without disarming the system. (Not all models) This system is designed to provide protection CAUTION: from unauthorized entry into the car.
Page 181 CONTROLS AND EQUIPMENT B070D03GK-AAT B070F01A-GAT B070E01GK-GAT Disarmed Stage KEYLESS ENTRY SYSTEM (If installed) Replacing the battery When the transmitter's battery begins to get Locking doors weak, it may take several pushes on the button 1. Close all doors. to lock or unlock the doors, and the LED will not 2.
Page 182 CONTROLS AND EQUIPMENT B050A01GK-AAT DOOR WINDOWS Power window (Not all models) Battery HGK121 HGK097-D 2. Remove the old battery from the case and CAUTION: note the polarity. Make sure the polarity of the Never try to operate the main switch and sub- HGK096-D new battery is the same(+side facing down), switch in opposing directions at the same...
Page 183 CONTROLS AND EQUIPMENT WARNING: SB070A1-E FRONT SEAT ADJUSTMENT To ensure the seat is locked securely, at- tempt to move the seat forward or rearward WARNING: without using the lock release lever. Front seat adjustments must not be under- taken whilst the vehicle is in motion. Loss of control of the vehicle may result if seat ad- justments are made whilst the vehicle is in SB070C1-E...
Page 184 CONTROLS AND EQUIPMENT SB070D2-E SB070E1-E FB070F1-F Head restraint adjustment Lumbar support adjustment Seat Cushion Height Adjustment (Driver's seat only) (Not all models) (Driver's seat only) (Not all models) SOFT FIRM Lock knob HGK049-D HGK052-D HGK050-D To raise the head restraint, pull it up. To lower it, push it down whilst pressing the lock knob.
Page 185 CONTROLS AND EQUIPMENT B100A01Y-AAT B129A01F-AAT B130A01GK-DAT SEAT WARMER (Not all models) REAR SEAT POSITIONS REAR SEAT ENTRY (Walk in device) The driver and front passenger's seatback should be tilted to enter the rear seat. B129A01GK HGK123 The seat warmer is provided to warm the front WARNING: HGK053-D seats during cold weather.
Page 186 CONTROLS AND EQUIPMENT B099A01F-AAT SB480A1-E BEFORE FOLDING THE REAR SEATS FOLDING REAR SEAT HGK240-D By pulling up the walk in device lever (1) at the B099A01GK HGK108 left-up side of the passenger side seatback, the seatback will tilt forward. And then push the seat The rear seatbacks may be folded to facilitate the In order to prevent the shoulder belt from being forward to enter the occupants.
Page 187 CONTROLS AND EQUIPMENT SB090A1-E SB090O1-E WARNING: SEAT BELT PRECAUTIONS Pregnant Women The folding rear seats are intended to allow Seat belts should be worn at all times by all The use of a seat belt is recommended for the carriage of longer objects than could occupants front and rear.
Page 188 Hyundai do not become damaged by being trapped in seat evident. Additional questions concerning seat Dealer. mechanisms, door shuts etc. belt operation should be directed to a Hyundai WARNING: Dealer. o The height adjuster must be in the locked SB090I-E position when the vehicle is moving.
Page 189 CONTROLS AND EQUIPMENT SB090P1-E nism by allowing a small amount of webbing to be B210A01A-AAT SEAT BELTS (3-Point Type) To Release the Seat Belt retracted and the belt withdrawn again. To Fasten The Seat Belt B200A01S-GAT Adjusting Your seat Belt FUD1090R The seat belt is released by pressing the release FUD1090P...
Page 190 If the seat belt will not properly fit the minimize the risk of injury in an accident, sudden Should an accident occur and cause the child, Hyundai recommends the use of an stop or sudden maneuver. According to accident passenger side airbag to deploy, it could...
Page 191 If the seat belt does not operate as de- scribed, have the system checked imme- Cover, Child Restraint diately by your authorized Hyundai dealer. Hook Holder Bolt, Holder (5/16"-30 mm) WARNING: Do not install any child restraint system in the...
Page 192 Front of Vehicle requirements of ECE-R44. For your Hyundai, B230E01GK the Hyundai ISOFIX GR1 / Hyundai Duo / Römer Two child restraint hook holders are located on ISOFIX GR1 and the Römer Duo ISOFIX / Britax the vertical back panel.
Page 193 Do not mis- law. Please ask your Hyundai dealer in this Hyundai. use the ISOFIX anchors by attempting to respect.
Page 194 Outboard Center Pre-tensioner Seat Belt (Not all models) 0 : Up to 10 kg Your Hyundai vehicle is equipped with driver's (0 ~ 9 months) and front passenger's pre-tensioner seat belts. 0+ : Up to 13 kg The purpose of the pre-tensioner is to make sure...
Page 195 Do not attempt to inspect or replace the dent in which the pre-tensioner seat belts pre-tensioner seat belts yourself. This Your Hyundai is equipped with a Supplemental were activated. must be done by an authorized Hyundai Restraint (Airbag) System. The indications of the dealer.
Page 196 If the airbags inflate, they must be re- in light collisions in which protection can forcefully contact the occupant causing placed by an authorized Hyundai dealer. be provided by the seat belt alone. serious or fatal injuries. o Do not tamper with or disconnect SRS...
Page 197 CONTROLS AND EQUIPMENT B240B01GK-AAT A fully inflated airbag in combination with a prop- SRS Components and Functions erly worn seat belt slows the driver's or the passenger's forward motion, thus reducing the risk of head and chest injury. After complete inflation, the airbag immediately starts deflating, enabling the driver to maintain forward visibility.
Page 198 When installing a container of liquid air fresh- continuously when the ignition key is ener inside a vehicle, do not place it near the Your Hyundai is equipped with a side airbag in turned to "ON", or continuously remains instrument cluster nor on the instrument panel each front seat.
Page 199 To prevent unexpected deployment of the wheel must be performed by a qualified Hyundai if the vehicle is in a crash severe enough side air bag that may result in personal technician.
Page 200 If components of the airbag system must be discarded, or if the vehicle must be scrapped, certain safety precautions must be observed. Your Hyundai dealer knows these precautions and can give you the necessary information. Failure to follow these precautions and procedures could increase the risk of personal injury.
Page 201 CONTROLS AND EQUIPMENT B250A01GK-EAT INSTRUMENTS AND CONTROLS 3 4 5 6 1213 1. Passenger's side Drink Holder 2. Passenger's Side Air Bag (Not all models) 3. Multi Guage (Not all models) 4. Front Fog Light Switch (Not all models) 5. Rear fog Light Switch 6.
Page 202 CONTROLS AND EQUIPMENT B260A01GK-EAT INSTRUMENT CLUSTER AND INDICATOR LIGHTS 2 3 4 HGK026UK 9 10 11 12 13 151617 18 1920 22 23 1. Speedometer 9. Traction Control Indicator Light 17. Malfuction Indicator Light (Not all models) 2. Turn Signal Indicator Light (Not all models) 18.
Page 203 The high beam indicator lamp will illuminate ignition is turned "on", contact the nearest Hyundai come on when the key is turned to the "ON" whenever the headlamps are switched to high dealer before further operating the vehicle.
Page 204 9 litres and that the vehicle should be The Hyundai Coupe is equipped with a diago- the advice of a Hyundai dealer should be sought. refuelled. If the vehicle is driven for an extended nally split dual braking system which will ensure...
Page 205 The fuel gauge indicates the quantity of fuel cruise control main switch is pushed a second rized Hyundai dealer and have the system remaining in the fuel tank. time. checked. See section 2 for more information Information about the use of cruise control is about the TCS.
Page 206 The speedometer indicates the vehicle speed in be readily established, the assistance of a both miles and kilometres per hour. Hyundai dealer should be sought. WARNING: The engine cooling system is pressurized and removal of the radiator cap when the...
Page 207 CONTROLS AND EQUIPMENT B310B01GK-EAT B400B01GK-EAT 1. Odometer ODOMETER/TRIP ODOMETER TRIP COMPUTER The odometer records the total driving distance in miles, and is useful for keeping a record for maintenance intervals. A Type NOTE: Any alteration of the odometer may void your warranty coverage.
Page 208 NOTE: AVERAGE SPEED o If the distance to empty is indicated "- -", have the trip computer system checked by your authorized Hyundai dealer. B Type DRIVE TIME o The distance to empty can differ from the actual tripmeter according to driving con- ditions.
Page 209 CONTROLS AND EQUIPMENT B330C01GK-GAT SB220A1-E Instantaneous Fuel Consumption gauge MULTI GAUGE (Not all models) MULTI FUNCTION SWITCH It shows instantaneous fuel consumption ac- Multi gauge is consists of torque gauge, instan- Turn Signal Operation cording to the driving condition. The more indi- taneous fuel consumption gauge and volt gauge.
Page 210 CONTROLS AND EQUIPMENT NOTE: To indicate an intention to change lanes, moving To operate the automatic light feature, turn the the lever slightly towards the direction of the The ignition must be in the "ON" position to barrel on the end of the multi-function switch. If relevant turn signal will cause the turn signal turn on the headlights.
Page 211 CONTROLS AND EQUIPMENT B350A01GK-EAT The variable intermittent wipe facility is operated Mist Wiper Operation WINDSCREEN WIPER/WASHER by moving the windscreen wiper switch to the first position. The time period between wipes is SWITCH adjusted by moving the rotary control on the windscreen wiper switch barrel.
Page 212 CONTROLS AND EQUIPMENT o In icy or snowy weather, ensure that the SB240A1-E SB250A1-E HAZARD WARNING SYSTEM HEATED REAR WINDOW wiper blades are not frozen to the glass prior to operating the wipers. A Type B350A01O-EAT Hatchback door Wiper And Washer Switch B Type HGK140...
Page 213 When this is done: Do not use electric accessories or equipment Pressing "R" between 10 : 30 and 11 : 29 changes other than the Hyundai genuine parts in the the readout to 11 : 00 Pressing "R" between 11 : socket.
Page 214 CONTROLS AND EQUIPMENT B430A01GK-AAT B450A01GK-GAT SB320A2-F FRONT ASHTRAY DRINK HOLDER (Not all models) HEADLIGHT LEVELING DEVICE SYS- Driver's Passenger's HGK146-D HGK149-D HGK157-D The front ashtray may be opened by pushing and The drink holder is used for holding cups or cans. releasing the ashtray door at its top edge.
Page 215 HGK029 FB330A1-E HGK030 SUNROOF (Not all models) Your HYUNDAI is equipped with a sliding sun- The sunroof can be electrically opened or closed The electrically operated sunroof may be used shade which you can manually adjust to let in with the ignition key in the "ON" position. The only whilst the ignition switch is at the "ON"...
Page 216 CONTROLS AND EQUIPMENT CAUTION: B460D03GK-AAT 3. Push and turn the wrench counterclockwise Manual Operation of Sunroof o Do not open the sunroof in severely cold to open or clockwise to close the sunroof. temperature or when it is covered with ice If the sunroof does not electrically operate: or snow.
Page 217 CONTROLS AND EQUIPMENT B480A01GK-GAT FB340B1-F B500A01A-EAT MAP LIGHT SPECTACLE CASE (Not all models) GLOVE BOX (1) (2) HGK036 HGK034 HGK147-D The spectacle case is located on the front over- (1) Push in the map light switch to turn the driver WARNING: head console.
Page 218 CONTROLS AND EQUIPMENT CAUTION: YB270B2-A the switch for the rear window defroster. The EXTERIOR REAR VIEW MIRROR o Do not operate the switch continuously rearview mirror glass will be heated for defrost- for an unnecessary length of time. ing or defogging and will give you improved rear Electric Type o Scraping ice from the mirror face could vision in inclement weather conditions.
Page 219 CONTROLS AND EQUIPMENT SB370A1-E B520B01O-GAT SB380A1-E INTERIOR REAR VIEW MIRROR DAY/NIGHT REAR VIEW MIRROR PARKING BRAKE (Electric type) (Not all models) Sensor B520A01GK HGK178 The parking brake must always be set when the The interior mirror is of the day/night type to B520B01GK vehicle is to be left unattended.
Page 220 CONTROLS AND EQUIPMENT YB800A2-A B360B01GK-GAT B550A02S-DAT FRONT FOG LIGHT SWITCH REAR FOG LIGHT SWITCH HIGH-MOUNTED REAR STOPLIGHT (Not all models) (Not all models) A Type B Type C Type B550A01GK HGK142 HGK183 In addition to the lower-mounted rear stoplights on either side of the car, the high mounted rear To turn on the rear fog lights, push the switch.
Page 221 CONTROLS AND EQUIPMENT WARNING: SB410A1-E B570A01GK-EAT FRONT DOOR EDGE WARNING LAMP BONNET RELEASE o Always double check to be sure that the bonnet is firmly latched before driving away. If it is not latched, the bonnet could fly open while the vehicle is being driven, causing a total loss of visibility, which might result in an accident.
Page 222 Do a Genuine Hyundai replacement part should not lever the lid. If necessary, spray around be used to prevent fuel leakage. WARNING:...
Page 223 CONTROLS AND EQUIPMENT SB450C2-E B540D01GK-GAT SB510A1-E To Unlock Using the Key When you close the hatchback door SUNVISOR Vanity mirror B540C01GK HGK145-D HGK226 To open the hatchback door using the ignition Sun visors are fitted to both the driver and pas- key, insert the key into the lock barrel and turn senger side of the vehicle.
Page 224 CONTROLS AND EQUIPMENT B600A01HP-AAT SB530B1-F B540D02HP-DAT STEERING WHEEL TILT LEVER HORN LUGGAGE NET (Not all models) (Not all models) A Type Working Zone B Type HGK141 HGK241 Some objects can be kept in the net at the HGK127-D Press the pad on the steering wheel to sound the luggage compartment.
Page 225 CONTROLS AND EQUIPMENT WARNING: SB700A1-E B660B01E-AAT CRUISE CONTROL (Not all models) To Set the Cruise Speed To avoid accidental cruise control engage- ment, keep the cruise control main switch off when not using the cruise control. B660C01E-AAT To Cancel the Cruise Speed Main switch B660B01GK B660A01GK...
Page 226 CONTROLS AND EQUIPMENT o During cruise-control driving with a manual B660D01E-AAT B660F01E-AAT To Resume the Preset Speed To Reset at a Slower Speed transaxle vehicle, do not shift into neutral without depressing the clutch pedal, or the engine will be overrevved. If this happens, depress the clutch pedal or release the main switch.
Page 227 CONTROLS AND EQUIPMENT B710A01GK-EAT B710A01S-AAT HEATING AND COOLING CONTROL VENTILATION To operate the ventilation system: o Set the air intake control on "Fresh" mode o To direct all intake air to the dashboard vents, set the airflow control to "Face". o Adjust the fan speed control to the desired speed.
Page 228 CONTROLS AND EQUIPMENT B670A01GK-GAT B670B01A-AAT B670E02A-AAT Fan Speed Control (Blower Control) ROTARY TYPE (Not all models) Temperature Control Cool Warm HGK006 HGK002 HGK007 1. Air Conditioning switch This is used to turn the blower fan on or off and This control is used to adjust the degree of to select the fan speed.
Page 229 CONTROLS AND EQUIPMENT B670C01FC-EAT With the "Recirculation" mode selected, air from B670D01GK-EAT Air Intake Control Air Flow Control within the passenger compartment will be drawn through the heating system and heated or cooled according to the function selected. NOTE: o It should be noted that prolonged opera- tion of the heating in "Recirculation"...
Page 230 CONTROLS AND EQUIPMENT If the "Floor-Defrost" mode is selected, the A/C will be on automatically and it will be changed to "Fresh" mode. HGK021-D HGK023-D Face-Level Floor-Level Selecting the "Face" mode will cause air to be Air is discharged through the floor vents, HGK025-D discharged through the face level vents.
Page 231 CONTROLS AND EQUIPMENT NOTE: B690A01S-AAT B720A01FC-EAT HEATING CONTROLS DEFROSTING/DEFOGGING When the A/C is operated continuously on For normal heating operation, set the air intake the floor-defrost level ( ) or defrost level control to the "Fresh" position and the air flow ( ), it may cause fog to form on the exterior control to "Floor".
Page 232 CONTROLS AND EQUIPMENT B740A01S-AAT B740B01S-AAT B740C01S-AAT AIR CONDITIONING SYSTEM Air Conditioning Operation Dehumidified Heating For dehumidified heating: (Not all models) Cooling Air Conditioning Switch o Turn on the fan control switch. o Turn on the air conditioning switch. The air conditioning indicator light should come on at the same time.
Page 233 CONTROLS AND EQUIPMENT B970A01Y-EAT AUTOMATIC HEATING AND COOLING CONTROL SYSTEM (Not all models) Your Hyundai is equipped with an automatic heating and cooling control system controlled by simply setting the desired temperature. B970B01GK-EAT Heating and Cooling Controls TYPE A (Without Air Quality System)
Page 234 CONTROLS AND EQUIPMENT NOTE: B970C02E-AAT Automatic Operation If the battery has been discharged or discon- nected, the temperature mode will reset as centigrade degrees. This is a normal condition and you can change the temperature mode from centigrade to farenheit as follows; Press the TEMP button down 3 seconds or more with the OUTSIDE...
Page 235 CONTROLS AND EQUIPMENT B995A01Y-GAT B980B01Y-AAT B670C01GK-EAT AMBIENT SWITCH Fan Speed Control Switch Air Intake Control Switch (Without A.Q.S) HGK015 HGK009 The fan speed can be set to the desired speed by Pressing the OUTSIDE button displays the amb- HGK008-1 TEMP pressing the appropriate fan speed control but- ient temperature on the display.
Page 236 CONTROLS AND EQUIPMENT With the "Recirculation" mode selected, and air B980C01GK-EAT Exhaust gas cutoff mode : Air Intake Control Switch (With A.Q.S) from within the passenger compartment will be Air enters the vehicle from the outside. drawn through the heating system and heated or (Not all models) But if exhaust gas enters the vehicle from the cooled according to the function selected.
Page 237 CONTROLS AND EQUIPMENT B980D01Y-AAT makes it possible to have cooler air from the Heating and Cooling System Off dashboard vents and warmer air from the floor Press the "OFF" button to stop the operation of outlets at the same time. the heating and cooling system.
Page 238 CONTROLS AND EQUIPMENT B740D01A-AAT B760A03GK-EAT Floor-Defrost Level Operation Tips AIR CONDITIONER FILTER When selecting the "Floor-Defrost" mode, the o If the interior of the car is hot when you first (IN FRONT OF BLOWER UNIT) indicator light will come on and the air will be get in, open the windows for a few minutes to discharged through the windscreen defrost Outside air...
Page 239 CONTROLS AND EQUIPMENT B750A02A-AAT AM reception FM radio station STEREO SOUND SYSTEM Ionosphere Unobstructed How Car Audio Works area FM reception Ionosphere Mountains Obstructed area Buildings SSAR011A Iron bridges SSAR012A AM broadcasts can be received at greater dis- FM broadcasts are transmitted at high frequen- tances than FM broadcasts.
Page 240 CONTROLS AND EQUIPMENT B750B02Y-AAT Using a cellular phone or a two-way radio When a cellular phone is used inside the vehicle, noise may be produced from the audio equip- ment. This does not mean that something is wrong with the audio equipment. In such a case, use the cellular phone at a place as far as possible from the audio equipment.
Page 241 CONTROLS AND EQUIPMENT JB580B2-A Do not grip or pull out the disc with your hand SR040B1-F CARE OF DISC Care of Cassette Tapes while the disc is being pulled into the unit by the Self Loading mechanism. Proper Handling Keep Your Discs Clean B860A01L B850A01L Proper care of your cassette tapes will extend...
Page 242 CONTROLS AND EQUIPMENT Head Cotton applicator SSAR042B B860A04A HGK062-D o Be sure that the cassette label is not loose or o The playback head, capstan and pinch rollers NOTE: peeling off or tape ejection may be difficult. will develop a coating of tape residue that can Look at a tape before you insert it.
Page 243 CONTROLS AND EQUIPMENT B870A01A-GAT ANTENNA Fixed Rod Antenna B870A01F Your car uses a fixed rod antenna to receive both AM and FM broadcast signals. This antenna is a removable type. To remove the antenna, turn the antenna counterclockwise. To install the antenna, turn the antenna clockwise. CAUTION: Be sure to remove the antenna before wash- ing the car in an automatic car wash or the...
Page 244: Driving Your Hyundai
DRIVING YOUR HYUNDAI SC000A1-E 2. DRIVING YOUR HYUNDAI C010A01O-EAT WARNING: ENGINE EXHAUST CAN BE DANGEROUS! Engine exhaust gases are potentially lethal. If at any time engine exhaust gas is detected within the passenger compartment, move the vehicle to an open area and open all windows.
Page 245 SC040A1-F COMBINATION IGNITION SWITCH AND STEERING LOCK To Start the Engine o If your Hyundai is equipped with a manual START transaxle, place the shift lever in neutral and depress the clutch pedal fully. o If your Hyundai has an automatic transaxle, C040A01E place the shift lever in "P"...
Page 246 DRIVING YOUR HYUNDAI SB050B1-E SC090D1-F SC060A1-E STEERING WHEEL LOCK To Remove the Ignition Key STARTING THE ENGINE When the key is removed, the steering column lock will be activated and will engage when the LOCK steering wheel is turned to the appropriate po- LOCK sition.
Page 247 B Type o Avoid cruising at unnecessary high speeds. o Always ensure that the periodic maintenance services are performed by a Hyundai dealer at the time and/or mileage intervals speci- fied. o Use the air conditioning only when neces- Mis-shift sary.
Page 248 DRIVING YOUR HYUNDAI NOTE: When shifting into reverse gear, pull the miss- C070E02GK-AAT RECOMMENDED SHIFT POINTS shift prevention tab and shift into reverse gear o During cold weather, shifting may be dif- position. (B Type : 6 speed type) ficult until the transaxle lubricant has The shift points as shown below are recom- warmed up.
Page 249 (Park) position unless the vehicle is fully stopped. Failure to observe this caution will HGK174-D cause severe damage to the transaxle. The highly efficient Hyundai automatic transaxle has four forwards speeds and one reverse speed. The individual speeds are selected au- C090C01A-AAT...
Page 250 DRIVING YOUR HYUNDAI CAUTION: o Before driving away from a stop on a C090E01O-AAT o D(Drive): o In sports mode, the driver must execute slippery road, push the selector lever Use for normal driving. The transaxle will auto- shifts in accordance with prevailing road forward into the +(UP) position.
Page 251 In a collision crash, un unbelted person ator pedal depressed. o Use only genuine Hyundai replacement is significantly more likely to die than a o Never move the gear selector lever into "P"...
Page 252 DRIVING YOUR HYUNDAI WARNING: o Apply the parking brake only when the vehi- C300A03Y-EAT TRACTION CONTROL SYSTEM (TCS) cle is at rest. ABS will not prevent accidents due to im- (Not all models) o Since the power assistance provided by the proper or dangerous driving manoeuvres.
Page 253 DRIVING YOUR HYUNDAI CAUTION: NOTE: effect of brake control and indicates noth- When the TCS indicator blinks, SLIP control ing unusual. 1) When the TCS-OFF indicator illuminates, has been activated. It also means that the 3) When the engine starts, a click is heard...
Page 254 DRIVING YOUR HYUNDAI heat, which reduces their effectiveness and o Remember, your car does not require ex- ZC170B1-E Electrical System may lead to more serious consequences. tended warm-up. As soon as the engine is o Take care of your tires. Keep them inflated running smoothly, you can drive away.
Page 255 1000 miles of o It is advisable to carry emergency equip- Running In has been completed. All Hyundai ment including, torch, shovel, tow rope, blan- SC170E1-E coupe models are suited to towing trailers kets etc., if a journey is to be undertaken into...
Page 256 TOWING ATTACHMENTS towed. The inside walls of the tyres should be tion performance will be available by selecting It is strongly recommended that only an Hyundai inspected along with the outside walls for crack- "Overdrive Off","2", or "1" depending upon road Approved towing attachment is used to ensure ing and damage.
Page 257 DRIVING YOUR HYUNDAI o The maximum permissible static vertical YC200E1-E Lbs.(kg) Trailer or Vehicle Towing Tips load on the coupling device : Lbs.(kg) Maximum 1. Before towing, check towbar hitch and safe- ty cable connections as well as proper oper- Towable Weight 1.6 L...
Page 258 DRIVING YOUR HYUNDAI NOTE: 9. If the trailer has electric brakes, start your vehicle and trailer moving, and then apply When towing check transaxle fluid more the trailer brake controller by hand to be frequently. sure the brakes are working. This lets you...
Page 259: In Case Of Emergency
3. Check the fuel line in the engine room. tion, if the vehicle is equipped with an ex- 4. If engine still refuses to start, call a Hyundai haust catalyst, damage to the catalyst may dealer or seek other qualified assistance.
Page 260 1. Ensure that the booster battery is 12 volt type. coolant is leaking out, stop the engine imme- If the booster battery is installed in another diately and call the nearest Hyundai dealer SD040A1-E vehicle, ensure that the two vehicles are not for assistance.
Page 261 CHANGING A FLAT TYRE checked as soon as possible by a Hyundai other car components may occur. dealer. 6. The temporary spare tyre pressure should be checked once a month while the tyre is stored.
Page 262 IN CASE OF EMERGENCY D060K01FC-EAT 4. Reinstall the wheel cap by fitting the boss of the The jack is located in the right side of luggage Wheel Cap (Not all models) wheel cap in the groove of the wheel, hitting the trim.
Page 263 IN CASE OF EMERGENCY SD070E1-E SD070F1-F D060F02E-EAT 3. Loosen Wheel Nuts 4. Put the Jack in Place 5. Raising the Car Wrench bar Wheel nut wrench HGK186 HGK193 HFC4022 The base of the jack should be placed on firm, The wheel nuts should be loosened slightly be- After inserting a bar into the wheel nut wrench, level ground.
Page 264 IN CASE OF EMERGENCY D060G02Y-EAT D060H02Y-EAT 6. Changing Wheels 7. Reinstall Wheel Nuts STA3071H WARNING: D060H01GK HGK232 Wheels and wheel cover may have sharp To reinstall the wheel hold it on the studs put the Loosen the wheel nuts and remove them with edges.
Page 265 IN CASE OF EMERGENCY SD070J1-E SD070K1-E SD080A1-E 8. Lower Vehicle and Tighten Nuts AFTER CHANGING WHEELS VEHICLE TOWING OR RECOVERY D080A01GK o OK FOR AUTOMATIC OR MANUAL TRANSAXLE EQUIPPED VEHICLE HGK195 HGK194 The pressure of the spare tyre should be checked Lower the car to the ground turning the wheel nut CAUTION: at the first available opportunity.
Page 266 IN CASE OF EMERGENCY SD090A1-E since the steering lock is not designed to Manual Transaxle Vehicle withstand the force required to hold the front wheels straight during the tow. o The vehicle must not be towed with the front wheels on the ground for more than thirty miles.
Page 267: Appearance Care
By using the most advanced design and con- light particularly in the case of vehicles having washing the underbody, the more vulnera- struction practices, every Hyundai is built to ble areas such as wheel arches should be dark body colours. The heat from the sun rays is absorbed by the paint film increasing the surface retain the original factory finish for many years.
Page 268 SEAT BELTS those used in manufacture. It is recommended Seat belts should be cleaned only with a mild that repairs are entrusted to a Hyundai dealer to soap solution. Strong detergents, solvens or SE040C1-E ensure that replacement parts used are of the...
Page 269: Vehicle Maintenance Requirements
It is recommended that all maintenance opera- at your Hyundai dealer because of the need for tions with the exception of the daily operating specialized knowledge and tooling and to en- checks are entrusted to a Hyundai dealer to...
Page 270 Hyundai dealer to ensure that the manufacturers recommended procedures In order to ensure the continued safety, reliability and longevity of the vehicle, are employed and that only genuine Hyundai replacement parts are used. the following maintenance service operations should be performed at the time Incorrect maintenance techniques or the use of non genuine replacement parts or mileage intervals specified.
Page 271 VEHICLE MAINTENANCE REQUIREMENTS F030C02GK-EAT R : REPLACE I : INSPECT AND, AFTER INSPECTION, CLEAN, ADJUST, REPAIR OR REPLACE IF NECESSARY MILES X 1000 DESCRIPTION MONTHS GENERAL MAINTENANCE COOLING SYSTEM COOLANT COOLANT SPECIFIC GRAVITY MANUAL TRANSAXLE OIL AUTOMATIC TRANSAXLE FLUID BRAKE PIPES, HOSES, AND CONNECTIONS BRAKE FLUID CLUTCH FLUID REAR BRAKE LININGS AND CYLINDERS...
Page 272 VEHICLE MAINTENANCE REQUIREMENTS F040A02GK-EAT MAINTENANCE UNDER SEVERE USAGE CONDITIONS The following items must be serviced more frequently on cars normally used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary MAINTENANCE MAINTENANCE DRIVING...
Page 273 6ZF060H1-A damage and deformation. Replace any dam- o Air cleaner filter aged parts immediately. A Genuine Hyundai air cleaner filter is recom- 6ZF060B2-A mended when the filter is replaced. o Drive belts Inspect all drive belts for evidence of cuts, cracks,...
Page 274 VEHICLE MAINTENANCE REQUIREMENTS 6ZF070B1-A 6ZF070F1-A 6ZF070K1-A o Cooling system o Brake hoses and lines o Exhaust pipe and muffler Check the cooling system part, such as radiator, Visually check for proper installation, chafing, Visually inspect the exhaust pipes, muffler and coolant reservoir, hoses and connections for cracks, deterioration and any leakage.
Page 275 VEHICLE MAINTENANCE REQUIREMENTS 6ZF070P1-A o Driveshafts and boots Check the drive shafts, boots and clamps for cracks, deterioration, or damage. Replace any damaged parts and, if necessary, repack the grease. 6ZF070Q1-A o Air conditioning refrigerant Check the air conditioning lines and connections for leakage and damage.
Page 276: Owner Maintenance
OWNER MAINTENANCE SG000A1-E 6. OWNER MAINTENANCE G010A01GK-EAT ENGINE COMPARTMENT (1.6 DOHC) CAUTION: When inspecting or servicing the engine, you should handle tools and other heavy objects carefully so that the plastic rocker cover of the engine is not damaged. HGK238-D 1.
Page 277 OWNER MAINTENANCE G010A01GK-EAT ENGINE COMPARTMENT (2.0 DOHC CVVT) CAUTION: When inspecting or servicing the engine, you should handle tools and other heavy objects carefully so that the plastic rocker cover of the engine is not damaged. HGK059-D 1. Clutch fluid reservoir (Not all models) 6.
Page 278 OWNER MAINTENANCE G010B01GK-EAT ENGINE COMPARTMENT (2.7 V6) CAUTION: When inspecting or servicing the engine, you should handle tools and other heavy objects carefully so that the plastic rocker cover of the engine is not damaged. HGK209-D 11. Engine oil filler cap 1.
Page 279 OWNER MAINTENANCE SG020B1-E SG030A1-E SG030B02GK-E DAILY OPERATING CHECKS ENGINE OIL Recommended Oil The following items should be checked on a daily The correct engine oil level is of paramount 1.6 DOHC basis or whenever the vehicle is refuelled, which- importance. An excessively high or low oil level 2.7 L V6 20W-40 20W-50 ever occurs sooner.
Page 280 OWNER MAINTENANCE SG030C1-E SG030D1-E 2.0 L DOHC CVVT Engine Oil Level ENGINE OIL REPLENISHMENT DOHC DOHC HGK259 See the lubrication chart on the page 9-3. HGK210 HGK211 NOTE: The engine oil level should be checked with the If the indicated oil level is at or below the lower o The use of a 5W-20 multi grade oil is not engine at normal operating temperature and the mark of the dipstick, oil should be added until the...
Page 281 OWNER MAINTENANCE WARNING: G350A01A-GAT G040A02GK-EAT ENGINE OIL CONSUMPTION ENGINE OIL AND FILTER The oil being drained from the engine will be REPLACEMENT hot. Care should be exercised to prevent Function of engine oil scalding. Engine oil has the primary function of lubricating DOHC and cooling the inside of the engine.
Page 282 "LOW" mark on a regular basis despite sion inhibitor properties deteriorate with time. being topped up, consult a Hyundai dealer. SG050A1-E It is important to note that whilst an increase in the...
Page 283 Use Engine 2.7L should be changed by an autho- extreme caution when working near the blades rized Hyundai dealer. of the cooling fan so that you are not injured by a rotating fan blade. As the engine coolant 2.
Page 284 1/2 to 3/4 of a turn only. When replacing the spark plugs, genuine therefore care should be exercised that the Hyundai replacement parts are recom- air flow sensor is not damaged during mended. replacement of the element.
Page 285 3 litres. If the wipers continue to streak or smear the glass, replace them with genuine Hyundai re- CAUTION: placement. Engine coolant anti freeze must not be used...
Page 286 Wipe the dipstick, replace it fully and promptly SG110A2-E AUTOMATIC TRANSAXLE Your Hyundai automatic transaxle is specially remove it again. The fluid level should be be- designed to operate with DIAMOND ATF SP-III, tween the upper and lower marks. Fluid need FLUID SK ATF SP- III.
Page 287 Fluid level should be within this range essential to the safe operation of the vehicle and therefore, any maintenance operations other than those listed below should be en- trusted to a Hyundai dealer. SG120C2-E Brake Fluid Recommendations HGK249 Only brake fluid conforming to DOT 3 or DOT 4...
Page 288 OWNER MAINTENANCE SG130A1-C SG130B2-E CHECKING THE CLUTCH FLUID Adding Fluid Recommended brake fluid conforming to DOT 3 (Not all models) or DOT 4 should be used. The reservoir cap must To Check the Clutch Fluid be fully tightened to avoid contamination from foreign matter or moisture.
Page 289 Adjustment of the belt should compressor and seals are lubricated. If this pre- be entrusted to a Hyundai dealer. caution is not observed the compressor seals may become stuck to the compressor shaft and...
Page 290 The clutch pedal freeplay should be checked against the specified value. If the freeplay is not correct, the clutch should be adjusted by a Hyundai dealer. HGK218 Steering wheel freeplay should be checked to ensure that the specified value is not exceeded.
Page 291 Hyundai dealer before a replace- should be performed by a Hyundai dealer. Pedal ment link is fitted. to floor clearance: 1.97 in. (50 mm)
Page 292 The circuit which is corrosive and poisonous. Hydrogen even when the engine is not running. Use should be checked by a Hyundai dealer at the gas is emitted from the battery which is ex- extreme caution when working near the blades first available opportunity.
Page 293 OWNER MAINTENANCE NOTE: The engine cooling fan should operate before the G270A02A-GAT HEADLIGHT BULB temperature gauge reaches the upper portion of Grinding noise from power steering pump Replacement instructions: the scale and the condenser fan should operate may be heard immediately after the engine is whenever the air conditioning is in use.
Page 294 OWNER MAINTENANCE WARNING: 7. Adjust each cut-off line of the low beam to the High Beam The halogen bulb contains gas under pres- parallel line with a phillips screwdriver - VER- sure and if impacted could shatter, resulting TICAL AIMING. in flying fragments.
Page 295 OWNER MAINTENANCE SPECIFICATION: "H" Horizontal centre line of headlights from ground: Low Beam: 26.7 in. (679mm) High Beam: 26.5 in. (672mm) "W" Distance between each headlight centre : Low Beam: 47.3 in. (1,202mm) High Beam: 38.0 in. (966mm) "L" Distance between the headlights and the wall that the lights are tested against : 118.11 in.
Page 296 OWNER MAINTENANCE G280A02GK-EAT (Low) (High) 11 12 HGK035A Part Name Wattage Part Name Wattage High Mounted Without spoiler 2.4 (LED) Head Light (High/Low) 55/55 Stop LIght With spoiler 3.5 (LED) Map Light Rear Turn Signal Light Front Position Light Combination Stop/Tail Light 21/5 Front Fog Light (Not all models)
Page 297 OWNER MAINTENANCE G200C01GK-GAT FUSE PANEL DESCRIPTION Engine Compartment PROTECTED COMPONENTS DESCRIPTION FUSE RATING BATT 120A Generator BATT Generator COND Condenser Fan Radiator Fan Engine Control, ECM. ATM Control Ignition, Start Relay ABS 1 ABS 2 Blower BLOWER Injector SNSR Sensor, ECM F/FOG Front fog Light TCM, ECM...
Page 298 OWNER MAINTENANCE G200D01GK-GAT Inner Panel DESCRIPTION FUSERATING PROTECTED COMPONENTS IG COIL Ignition Coil, ECM AMP. Multi Gauge Unit B/UP LAMP B/Up Lamp A/BAG IND Air Bag Indicator A/BAG Air Bag HTD MIR Outside Mirror Defroster Hazard Warning Light HAZARD R/WIPER Rear Window Wiper Taillight TAIL-RH...
Page 299: Emission Control System
SSA7020A recommended that the vehicle is inspected and The purge control solenoid valve is controlled by Hyundai Coupe models are fitted with catalytic maintained by an authorized Hyundai dealer in the ECU; when the engine coolant temperature convertors which require special operating con-...
Page 300 (Note, it is impos- sible to push or tow start a Hyundai model equipped with fuel injection since the fuel pump safety interlock will prevent the pump from oper- ating under these conditions).
Page 301: Consumer Information
CONSUMER INFORMATION SI010B1-E pressures can affect vehicle safety by causing SI000A1-E Engine Number reduced adhesion, steering response and tyre 8. CONSUMER failure through overheating. The tyre pressure DOHC must only be checked when the tyres are cold. INFORMATION The correct tyre pressures are indicated on the label affixed to the drivers door pillar and below.
Page 302 CONSUMER INFORMATION I050A01GK-EAT I060A01GK-EAT TYRE CHAINS TYRE ROTATION Tyre chains should be installed on the front 16" Tyre 17" Tyre Sidewall wheels. Be sure that the chains are installed in accordance with the manufacturer's instructions. Refer to the following information. Tyre rotation direction Tyre size...
Page 303 It is recommended that the tyres be balanced on The original wheels may only be replaced with the car for best results and that the tyres are Hyundai Approved Wheels. balanced whenever they have been removed from the wheel for repair.
Page 304: Vehicle Specifications
VEHICLE SPECIFICATIONS J030A01GK-DAT SJ000A1-F TYRE 9. VEHICLE SPECIFICATIONS 1.6 & 2.0 L 2.7 V6 205 / 55 R16 215 / 45 R17 J010A01GK-AAT MEASUREMENT in. (mm) Overall length 173(4395) J035A01GK-DAT SPARE TYRE Overall width 69.3(1760) Standard T125/70R 16 (Temporary) Overall height (unladen) 52.4(1330) Wheel base 99.6(2530)
Page 305 VEHICLE SPECIFICATIONS J070A03GK-EAT ENGINE SPECIFICATION ITEMS 1.6 L 2.0 L 2.7 L Engine Type 4-Cyl., In-line DOHC CVVT 2.7 6 Cylinder V6 DOHC Bore x Stroke 76.5 x 87 82 x 93.5 86.7 x 75 Displacement (cc) 1,599 1,975 2,656 Firing order 1 - 3 - 4 - 2 1 - 3 - 4 - 2...
Page 306 Severe driving condition MAX. 1L / 1000 Km Transaxle Manual HYUNDAI GENUINE PARTS MTF 75W/90 (API GL-4) 5 speed : 1.86 (2.15, 2.27), 6 speed : 1.94 (2.2, 2.32) Auto DIAMOND ATF SP-III or SK ATF SP-III 6.9 (7.8, 8.2)
Page 307: Index
INDEX JK000A2-EAT CARE OF CASSETTE TAPE ............1-65 10. INDEX CARE OF DISC ................1-65 CARE OF SEAT BELTS ..............1-12 CATALYTIC CONVERTOR OPERATING PRECAUTIONS ..7-1~7-2 CENTRAL DOOR LOCK ..............1-4 AIR BAG ................... 1-19 CHANGING A FLAT TYPE ..............3-3 AIR CONDITIONING SWITCH ............
Page 308 INDEX EFFECTIVE BRAKING ............... 2-8 GLOVE BOX ..................1-41 ELECTRIC COOLING FANS ............6-17 EMISSION CONTROL SYSTEMS ............. 7-1 ENGINE COMPARTMENT ..............6-1 HATCHBACK DOOR ................ 1-46 ENGINE COOLANT CHECKING AND REPLACING ......6-7 HATCHBACK DOOR WIPER AND WASHER ........ 1-36 ENGINE COOLANT TEMPERATURE GUAGE .......
Page 309 POWER STEERING HOSES ............6-18 KEY POSITIONS ................2-2 PRE-TENSIONER SEAT BELT ..........1-18 ~ 1-19 KEYS ....................1-2 PROTECTING YOUR HYUNDAI FROM CORROSION ....4-1 LIGHTING SWITCH ................1-34 REAR FOG LIGHT SWITCH ............1-44 LUGGAGE NET ................1-48 REAR PARCEL SHELF ..............
Page 310 INDEX SEAT CUSHION HEIGHT ADJUSTMENT ........1-8 TYRE PRESSURES ................8-1 SEAT WARMER ................. 1-9 TYRE BALANCING ................8-3 SERVICE HISTORY ................5-1 TYRE CHAINS ................... 8-2 SMOOTH CORNERING ..............2-11 TYRE REPLACEMENT ..............8-3 SNOW TYRES ................... 8-1 TYRE ROTATION ................8-2 SPARE TYRE ..................

Hyundai 2003 Coupe Tiburon Owner's Manual

Table of Contents

Table of Contents

Quick Links

Chapters

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hyundai 2003 Coupe Tiburon

Summary of Contents for Hyundai 2003 Coupe Tiburon

Table of Contents
