Ryobi DP102L Operator's Manual

10 in. drill press
Hide thumbs Also See for DP102L:
Table of Contents

Advertisement

Quick Links

Your drill press has been engineered and manufactured to our high standard for dependability, ease of operation, and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using
this product.
Thank you for your purchase.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
10 in. DRILL PRESS
DP102L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DP102L and is the answer not in the manual?

Questions and answers

Barry Straughan
May 20, 2025

I need the self ejecting chuck key but cannot find a part number of anyone who can send it.

0
1 comments:
Mr. Anderson
May 24, 2025

The part number for the self-ejecting chuck key is 3653.

This answer is automatically generated

0
ken hoffmann
February 9, 2025

what is the thread count on the depth guage lock knob

0

Related Manuals for Ryobi DP102L

Summary of Contents for Ryobi DP102L

  • Page 1 Your drill press has been engineered and manufactured to our high standard for dependability, ease of operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance. WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using this product.

  • Page 2: Table Of Contents

    WHAT THIS WARRANTY COVERS: This warranty covers all defects in workmanship or materials in your RYOBI tool for a period of two years from the date of purchase. With the exception of batteries, power tool accessories are warranted for ninety (90) days.

  • Page 3: General Safety Rules

    WARNING: Read and understand all instructions. Failure to follow all instructions listed below, may result in electric shock, fire and/or serious personal injury. READ ALL INSTRUCTIONS n KNOW YOUR POWER TOOL. Read the operator’s manual carefully. Learn the applications and limitations as well as the specific potential hazards related to this tool.
  • Page 4 n STAY ALERT AND EXERCISE CONTROL. Watch what you are doing and use common sense. Do not operate tool when you are tired. Do not rush. n DO NOT USE TOOL IF SWITCH DOES NOT TURN IT ON AND OFF. Have defective switches replaced by an authorized service center.

  • Page 5: Specific Safety Rules

    USE RECOMMENDED SPEED FOR DRILL ACCES- SORY AND WORKPIECE MATERIAL. n BE SURE DRILL BIT OR CUTTING TOOL IS SECURELY LOCKED IN THE CHUCK. n BE SURE CHUCK KEY IS REMOVED from the chuck...

  • Page 6: Symbols

    Some of the following symbols may be used on this tool. Please study them and learn their meaning. Proper interpreta- tion of these symbols will allow you to operate the tool better and safer. SYMBOL NAME Volts Amperes Hertz Watt Minutes Alternating Current Direct Current...
  • Page 7 The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SIGNAL DANGER: WARNING: CAUTION: CAUTION: SERVICE Servicing requires extreme care and knowledge and should be performed only by a qualified service technician. For service we suggest you return the product to your nearest AUTHORIZED SERVICE CENTER for repair.

  • Page 8: Extension Cords

    EXTENSION CORDS Use only 3-wire extension cords that have 3-prong ground- ing plugs and 3-pole receptacles that accept the tool’s plug. When using a power tool at a considerable distance from the power source, use an extension cord heavy enough to carry the current that the tool will draw.

  • Page 9: Glossary Of Terms

    Non-Through Cuts Any cutting operation where the blade does not extend completely through the thickness of the workpiece. Pilot Hole (drill presses) A small hole drilled in a workpiece that serves as a guide for drilling large holes accurately. Push Blocks and Push Sticks Devices used to feed the workpiece through the saw blade during cutting operations.

  • Page 10: Product Specifications

    PRODUCT SPECIFICATIONS Chuck ... 1/2 in. Input ... 120 Volt, 60Hz, AC Only, 3 Amps Motor ... 1/4 HP Induction No Load Speed ... 570–3,050 RPM Swing... 10 in. WORKLIGHT SWITCH KEY WORKLIGHT LASER FEATURES Spindle Travel ...2-3/8 in. Table Size ... 9-1/4 in. x 8-3/16 in. Table Movement ...45°...

  • Page 11: Tools Needed

    Five different spindle speeds allow you to drill a wide variety of material including wood, plastic, and metal. TABLE The table of your drill press rotates 360˚ and bevels up to 45˚ for angle drilling. VISE Use the vise to secure the workpiece to the table when drilling.

  • Page 12: Loose Parts

    The following items are included with the drill press: Head Assembly ...1 Column Assembly ...1 Table Assembly ...1 Base ...1 Hex Key (3 mm, 4 mm, and 5 mm)...3 Hex Bolts (M8)...4 Feed Handles ...3 Table Adjustment Handle ...1 AA BATTERIES...

  • Page 13: Assembly

    UNPACKING This product requires assembly. n Carefully remove the tool and any accessories from the box. Place it on a level work surface. NOTE: This tool is heavy. To avoid back injury, lift with your legs, not your back, and get help when needed. n Inspect the tool carefully to make sure no breakage or damage occurred during shipping.
  • Page 14 INSTALLING TABLE ASSEMBLY See Figures 6 - 8. n Loosen the set screw in the column collar. Remove the column collar and gear rack from the column and set aside. n Locate the worm gear and feed the D-shaft through the hole in the table assembly.
  • Page 15 INSTALLING CHUCK, HEAD ASSEMBLY, AND FEED HANDLES See Figures 9 - 11. n Place the head assembly upside down on a level, flat surface. n Position chuck on spindle. Chuck should be fully opened to avoid damaging jaws. n Using a piece of scrap wood to protect the chuck, firmly tap the chuck into place using a mallet or hammer.

  • Page 16: Mounting The Drill Press

    If the drill press is to be used in a permanent location, secure it to a workbench or other stable surface. If the drill press is to be used as a portable tool, fasten it permanently to a mounting board that can easily be clamped to a workbench or other stable surface.
  • Page 17 Mark an “X” on a piece of scrap wood. n Insert a small drill bit into the chuck and align its tip to the intersection of the lines of the “X”. n Secure the board to the table.

  • Page 18: Power Switch

    Drilling in ceramics, plastics, fiberglass, and laminates n Drilling in metals POWER SWITCH See Figure 16. The drill press is equipped with a power switch that has a built-in locking feature. This feature is intended to prevent unauthorized and possible hazardous use by children and others.

  • Page 19: Installing And Removing Bits

    Open or close the chuck jaws to a point where the open- ing is slightly larger than the bit size you intend to use. n Insert drill bit into the chuck the full length of the jaws. WARNING: Do not insert drill bit into chuck jaws and tighten as shown in figure 19.

  • Page 20: Drilling Tips

    This will automatically raise the chuck and bit. DRILLING TIPS n If a large hole is needed, it’s a good idea to drill a smaller pilot hole before drilling the final one. Your hole will be more accurately positioned, rounder, and the bits will last longer.

  • Page 21: Adjusting Table Height

    ADJUSTING TABLE BEVEL See Figures 22 - 23. The drill press is equipped with a tilting table that allows you to drill angled holes. The table can be tilted left or right, from 0º to 45º. To tilt the table: n Loosen the large hex bolt located underneath the table.

  • Page 22: Changing Speeds

    The spindle speed is determined by the location of the belt on the pulleys inside the head assembly. The speed chart located on the cover inside the head assembly shows the recommended speed and pulley configuration for each drill- DRIVE ing operation.

  • Page 23: General Maintenance

    After using the drill press, clean it completely and lubricate all sliding and moving parts. Apply a light coat of automotive- type paste wax to the table and column to help keep the surfaces clean.

  • Page 24: Troubleshooting

    Speeds in the Adjustments section of this manual. Retract bit frequently to clear chips. Sharpen or replace bit. Feed fast enough; allow drill to cut. Lubricate bit for metal work. Replace bit. Install bit properly. Install chuck properly. Contact authorized service center.
  • Page 25 NOTES...
  • Page 26 Please record the model number and serial number in the space provided below. • HOW TO ORDER REPAIR PARTS When ordering repair parts, always give the following information: • MODEL NUMBER • SERIAL NUMBER Ryobi is a registered trademark of Ryobi ® ONE WORLD TECHNOLOGIES, INC. 983000-641 12-21-05 (REV:01) OPERATOR’S MANUAL 10 in.
