3/8 in. (10 mm) electric drill double insulated
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Chuck Capacity
Switch
Rating
Input
No Load Speed
Horsepower
THANK YOU FOR BUYING A RYOBI DRILL.
Your new drill has been engineered and manufactured to Ryobi's high standard for dependability, ease of operation, and
operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
CAUTION: Carefully read through this entire owner's manual before using your new drill. Pay close attention to
the Rules for Safe Operation, Warnings, and Cautions. If you use your drill properly and only for what it is intended, you will
enjoy years of safe, reliable service.
Thank you again for buying Ryobi tools.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OWNER'S OPERATING MANUAL
3/8 in. (10 mm) Electric Drill – D28VSR
DOUBLE INSULATED
SPECIFICATIONS:
1/16 in. (1.6 mm) To 3/8 in. (10 mm)
Adjustable Variable Speed/Reversible
120 volts, 60 Hz, AC
3.0 Amperes
0-1300 RPM
1/3
