Ryobi D130VR Owner's Operating Manual

Ryobi D130VR Owner's Operating Manual

1/2 in. (13 mm) electric drill
Hide thumbs

Advertisement

Table of Contents

Chuck Capacity
Switch
Rating
Input
No Load Speed
Net Weight
THANK YOU FOR BUYING A RYOBI DRILL.
Your new drill has been engineered and manufactured to Ryobi's high standard for dependability, ease of operation, and
operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
CAUTION: Carefully read through this entire owner's manual before using your new drill.
Pay close attention to the Rules for Safe Operation, Warnings, and Cautions. If you use your drill properly and only for what
it is intended, you will enjoy years of safe, reliable service.
Thank you again for buying Ryobi tools.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OWNER'S OPERATING MANUAL
1/2 in. (13 mm) Electric Drill
Model D130VR Type II
Double Insulated
SPECIFICATIONS:
1/16 in. (1.6 mm) - 1/2 in. (13 mm)
Adjustable Variable Speed/Reversible
120 volts, 60 Hz, AC
5.0 Amperes
0-550 RPM
5.1 lbs. (2.3 kg.)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D130VR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ryobi D130VR

Summary of Contents for Ryobi D130VR

  • Page 1 Net Weight THANK YOU FOR BUYING A RYOBI DRILL. Your new drill has been engineered and manufactured to Ryobi's high standard for dependability, ease of operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.

  • Page 2: Double Insulation

    For service we suggest you return the tool to your nearest RYOBI FACTORY or AUTHORIZED SERVICE CENTER for repair. When servicing use only identical Ryobi replacement parts.

  • Page 3: Rules For Safe Operation

    RULES FOR SAFE OPERATION READ ALL INSTRUCTIONS 1. KNOW YOUR POWER TOOL. Read owner's manual carefully. Learn its applications and limitations as well as the specific potential hazards related to this tool. 2. GUARD AGAINST ELECTRICAL SHOCK by preventing body contact with grounded surfaces.
  • Page 4 A guard or other part that is damaged should WARNING: WEAR YOUR The operation of any drill can result in foreign objects being thrown into your eyes, which SAFETY GLASSES SAFETY GLASSES can result in severe eye damage. Before beginning power tool operation, always wear safety goggles or safety glasses with side shields and a full face shield when needed.

  • Page 5: Operation

    Before attempting to use your drill, familiarize yourself with all operating features and safety requirements. WARNING: If any parts are missing do not operate your drill until the missing parts are replaced. Failure to do so could result in possible serious injury.
  • Page 6 REVERSIBLE See Figure 3. Your drill has the feature of being reversible. The direction of chuck rotation is controlled by a lever located above the switch trigger. With your drill held in normal operating position, the direction of rotation lever should be positioned to the left of the switch for drilling operation.

  • Page 7: Variable Speed

    Your drill has a variable speed control selector designed to allow operator control and adjustment of speed and torque limits. The speed and torque of your drill can be increased or decreased by rotating the variable speed control selector in the direction of the arrows shown in figure 5.
  • Page 8 3. Insert drill bit into chuck the full length of the jaws. WARNING: Do not insert drill bit into chuck jaws and tighten as shown in figure 8. This could cause drill bit to be thrown from your drill resulting in possible serious personal injury or damage to your chuck.
  • Page 9 To accomplish this, operate your drill at a low speed until the hole is started. When drilling metals use a light oil on the drill bit to keep it from overheating. The oil will prolong the life of the bit and increase the drilling action.
  • Page 10 2. Open chuck jaws. Insert a 5/16 inch or larger hex key wrench (allen wrench) into the chuck of your drill and tighten the chuck jaws securely. 3. Tap the hex key wrench sharply with a mallet in a clockwise direction.

  • Page 11: Maintenance

    WARNING: When servicing use only identical Ryobi replacement parts. Use of any other parts may create a hazard or cause product damage. GENERAL Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from various types of commercial solvents and may be damaged by their use.
  • Page 12 Now that you have purchased your tool, should a need ever exist for repair parts or service, simply contact your nearest Ryobi Factory Service Center. Be sure to provide all pertinent facts when you call or visit. Please refer to the Service Center insert or call 1-800-525-2579 in the United States or 1-800-265-6778 in Canada for your nearest Factory or Authorized Service Center.
