OTC DP-400 Owner's Manual

Digital inverter
Hide thumbs
Table of Contents

Advertisement

Quick Links

MANUAL NO:P10355
OWNER'S
MANUAL
FOR
CO
/MAG/MIG
DIGITAL INVERTER
2
DP400
MODEL: DP-400 P10355
INVERTER CONTROLLED WELDING POWER SOURCE
DO NOT DESTROY
IMPORTANT:
Read and understand the entire contents of this
manual, with special emphasis on the safety material throughout
the manual, before installing, operating, or maintaining this
equipment. This equipment and this manual are for use only by
persons trained and experienced in the safety operation of welding
equipment. Do not allow untrained persons to install, operate or
maintain this equipment. Contact your distributor if you do not
fully understand this manual.
DAIHEN Corporation
WELDING PRODUCTS DIVISION
June 1, 2004
Upon contact, advise MODEL and MANUAL NO.
