Patty-O-Matic, Inc.
®
The World's Finest Food Machines
Model Protégé
Owner's Manual
Revised April 2006
Route 547
P.O. Box 404 Farmingdale NJ,07727
Tel: (732) 938-2757
Fax: (732) 938-5809
Toll Free in USA: 877-938-5244

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Protege and is the answer not in the manual?

Questions and answers

Related Manuals for Patty-O-Matic Protege

Summary of Contents for Patty-O-Matic Protege

  • Page 1 Patty-O-Matic, Inc. ® The World’s Finest Food Machines Model Protégé Owner’s Manual Revised April 2006 Route 547 P.O. Box 404 Farmingdale NJ,07727 Tel: (732) 938-2757 Fax: (732) 938-5809 Toll Free in USA: 877-938-5244...
  • Page 2 Congratulations on the purchase of your new Model Protégé Patty Molding Machine from Patty-O-Matic, Inc! The Model Protégé will form, interleave paper between, and stack food patties. This machine is designed for easy operation and cleaning. Please become familiar with this manual and your machine will give you years of service.
  • Page 3 Please become familiar with some of the parts of your machine prior to operation. Pressure Feeder Feeder Feeder Top Plate Washer View Meat Stop Mixer Feeder Side Collar View Hopper Protégé Mold Plate Assembly Side View Transition Plate Mold Plate T-Knob Mold Plate Assembly Underside View Ring Pin Pressure Plate...
  • Page 4 Proper Label Location for a Model Protégé...
  • Page 5 Item # Description Part # Danger Tag 514-09 Warning Orange 514-02 Patty-O-Matic 514-08 Warning 514-06 Danger Label 1 514-03 Danger Label 2 514-00 Serial Tag 514-15 Store Tool 514-14 Warning Manual 514-01 Danger on/off 514-05 Do Not Pressure Wash 514-04...
  • Page 6 Pro Warning and Always 514-13 Danger Keep Clear 514-16 Pro Position 514-11 Pro Caution TI Plate 514-10 Pro Risk 514-17 Pro If Sign is Visible 514-14 These Labels are available through the factory, at no charge. Contact the factory for replacements if something is to happen to the originals.
  • Page 7 Always Disconnect Machine From its Power Source Before Cleaning or Adjusting! Proper Procedure for Operating a Model Protégé When the Model Protégé is fully assembled with all guards secured in their proper place, put product in the Feed Tray. Push the product through the holes in the Feed Tray Guard into the hopper opening.
  • Page 8 Changing Your Machine’s Mold Plate Always disconnect the machine from its power source before attempting to change any of the machines component parts. First remove the T-Knob from the Back Drive of the Mold Plate, then pull the Mold Plate out from the rear of the machine. If you prefer, remove the Mold Plate from the machine without removing the T-Knob from the Back Drive.
  • Page 9 Proper Disassembly for Cleaning a Patty-O-Matic Model Protégé Always Unplug Machine From its Power Source Before Cleaning! Feed Tray with attached Mold Plate - Remove Feed Tray with attached Mold Plate Guard from the Machine. Hopper - Remove Pressure Plate by detaching spring and sliding Pressure Plate from the inside of the hopper.
  • Page 10 Pressure Foot Center Pin *Placing more than one inch of paper on the pin may cause improper feeding. Patty-O-Matic Inc. offers the highest quality patty paper, machine lubricant, and machine grease. Please contact the factory for information on these products.
  • Page 11 Points of Daily Lubrication For A Patty-O-Matic Model Protege: Always Unplug Machine and use Food Approved Oil and Grease! The Following Parts should be lubricated daily to ensure proper machine maintenance - Pressure Foot should be lifted up and oiled. Grab Ball Knob and Ball Knob lift up.
  • Page 12 Feed Tray with attached Mold Plate Guard Knock Out Cup Assembly Knock Out Cup Exploded View *Knock Out Cup Hardware is also sold as an assembly. -Knock Out Cup Assembly w/ Hardware is Part #571 -Knock Out Cup Hardware Only is Part #571-H1 Item# Description Part #...
  • Page 13 Hopper Front View Hopper Rear View Hopper Bottom View Feeder Top View Item# Description Part # Hopper Casting Chamber Lid 545-A Protégé Hold Down Bolt (7 required) PRO556-1 Meat Stop Protégé Guard Sign PRO551B Hold Down Holes (4) Pressure Plate Block Hardware 548-C Pressure Plate Block Protégé...
  • Page 14 Machine Front View Machine Left Side View Machine Right Side View Machine Right Side View Item # Description Part # Item# Description Part# Pressure Foot Ball Knob 506B Knock Out Shaft Nut & Lockwasher 503 Protégé Knock Out Arm PRO502 Protégé...
  • Page 15 Paper Interleaver Top View Paper Interleaver Motor View Paper Interleaver Side View Return Bracket Item # Description Part # Item# Description Part# Protégé Paper Interleaver Plug PRO115-04A Protégé PI Capacitor Assembly PRO516C Protégé Paper Motor Cord PRO115-04 Protégé Paper Interleaver Motor PRO516 Protégé...
  • Page 16 Part # Pressure Plate Ball Knob 546D T-Knob Pressure Plate Spring c/w Collar Hopper Casting Ring Pin Adjustment Holes Protege Hold Down Bolt PRO556-1 Ring Pin (shown in Feeder Washer the storage hole) 546C Meat Stop Ring Pin Pressure Plate...
  • Page 17 On/Off Switch Front View Tower Side View On/Off Switch Interior View Interleaver Receptical Machine View Item# Description Part # On/Off Switch Guard On/Off Switch Boot 500B Wire Grommet Power Cord 115-01 Tower Sleeve PRO620-06 Protégé Tower Jam Nut, Acorn Nut, and Washer PRO620-02 Protégé...
  • Page 18 Tower Assembly Tower Assembly Exploded Top View Exploded Bottom View Tower Assembly Protégé Knock Out Shaft Machine View Tube and Support Item# Description Part # Protégé Tower PRO620-07 Tower Stem 620-3 Protégé Tower Stem Hardware PRO620-02 Protégé Feed Tray Safety Interlock Bushing PRO620-03 Protégé...
  • Page 19 Protégé Knock Out Lever Cam Bearing and Interior View Lever Block Item# Description Part # Protégé Knock Out Lever Block Hardware PRO450B Protégé Knock Out Lever PRO450 Protégé Knock Out Lever Hardware PRO451 Cam Follower Bearing Protégé Cam Bearing Hardware PRO475 Protégé...
  • Page 20 Transmission and Main Shaft Assembly Item# Description Part # Protégé Main Shaft w/ Insert and Set Screw PRO464 Protégé Crank-Connecting Arm Assembly PRO455 Protégé Connecting Arm Protégé Knock Out Cam PRO472 Protégé Transmission PRO484A Protégé Transmission Brackets PRO484B Protégé Transmission Bracket Hardware(Set of 4) PRO484C Protégé...
  • Page 21 Machine Interior View Item# Description Part # Protégé Transmission Pulley PRO484C Protégé Transmission Pulley Drive Key PRO484C1 Protégé Machine Leg and Rubber Foot with Hardware PRO446C Set of 4 Protégé Rubber Feet PRO448 Protégé V-Belt PRO471 Motor/Transmission Fastening Hardware(Set of 4) PRO484-1 Protégé...
  • Page 22 Machine Exterior View Item# Description Part # Protégé Main Shaft Insert PRO464-1 Protégé Main Shaft w/ Insert and Set Screw PRO464 Protégé Main Shaft Block Hardware PRO464D Protégé Main Shaft Block c/w Bushing PRO464A Guide Rail (2 Required) Protégé Grease Fitting PRO464B Protégé...
  • Page 24 Model Protégé Warranty Information This appliance is guaranteed to original purchaser to be free from defects in materials and workmanship. Warranty shall be limited to repairing or exchanging any part that in our judgment shows evidence of defect within two years of original date of purchase.
  • Page 25 Important Information on Your Machine Patty-O-Matic Inc. Model Protege Serial Number_________________________________________________ Date Purchased________________________________________________ Purchased From What Dealer___________________________________ Dealer Address and Phone Number_______________________________ _____ _________________________________________ ______________________________________________ ______________________________________________ Maintenance Performed on Machine______________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ Owner’s Notes_________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________...
  • Page 26 NOTES _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________...
