Cyrus AV5 Service Manual page 8

RESISTORS
R101 SMD0805
R102 SMD0805
R103 SMD0805
R104 SMD0805
R105 SMD0805
R106 SMD0805
R107 SMD0805
R108 SMD0805
R109 SMD0805
R110 SMD0805
R111 SMD0805
R112 SMD0805
R120 AXIAL0.5
R121 AXIAL0.5
R122 SMD0805
R123 SMD0805
R124 SMD0805
R125 SMD0805
R126 SMD0805
R201 SMD0805
R202 SMD0805
R214 SMD0805
R401
R402 SMD0805
R403 SMD0805
R404 SMD0805
R405 SMD0805
R406 SMD0805
R407 SMD0805
R408 SMD0805
R409 SMD0805
R410 SMD0805
R411 SMD0805
R412 SMD0805
R413 SMD0805
R414 SMD0805
R415 SMD0805
R416 SMD0805
R417 SMD0805
R422 SMD0805
R423 SMD0805
R428 SMD0805
R429 SMD0805
July 2000
CYRUS AV5 PCB COMPONENTS
330R MF 1/8W 1%
2.7k MF 1/8W 1%
1k MF 1/8W 1%
470R MF 1/8W 1%
100k MF 1/8W 1%
10k MF 1/8W 1%
47k MF 1/8W 1%
100k MF 1/8W 1%
10k MF 1/8W 1%
10k MF 1/8W 1%
10k MF 1/8W 1%
10k MF 1/8W 1%
4.7R MF 1/4W 5%
4.7R MF 1/4W 5%
10k MF 1/8W 1%
NOT FITTED
NOT FITTED
NOT FITTED
NOT FITTED
75R MF 1/8W 1%
75R MF 1/8W 1%
47R MF 1/8W 1%
NOT FITTED
75R MF 1/8W 1%
75R MF 1/8W 1%
75R MF 1/8W 1%
47R MF 1/8W 1%
47R MF 1/8W 1%
270R MF 1/8W 1%
100R MF 1/8W 1%
47R MF 1/8W 1%
47R MF 1/8W 1%
47R MF 1/8W 1%
47k MF 1/8W 1%
47k MF 1/8W 1%
47k MF 1/8W 1%
47k MF 1/8W 1%
47k MF 1/8W 1%
47k MF 1/8W 1%
2.2k MF 1/8W 1%
1.4k MF 1/8W 1%
2.2k MF 1/8W 1%
1.4k MF 1/8W 1%
6
Was originally 2.2k. Reduced to
improve input overload
Was originally 2.2k. Reduced to
improve input overload
