Cyrus AV5 Service Manual page 13

R1102 SMD0805
R1103 SMD0805
R1104 SMD0805
R1201 SMD0805
R1301 AXIAL0.5
R1302 SMD0805
R1303 SMD1206
R1304 SMD0805
R1305 SMD0805
R1306 SMD0805
R1307 SMD0805
R1308 SMD0805
R1309 SMD0805
R1310 SMD0805
R1311 SMD0805
R1312 SMD0805
R1313 SMD0805
R1314 SMD0805
R1315 SMD0805
R1316 SMD0805
R1317 SMD0805
Key:
MF = metal film. NFR = non flammable resistor. MRS25 = axial metal film resistor
SMD-0805 = refers to surface mount device size profile 0805
RESISTOR PACKS
RP501 RES CAT16..4
RP502 RES CAT16..4
RP503 RES CAT16..4
RP504 RES CAT16..4
RP801 RES CAT16..4
RP802 RES CAT16..4
RP803 RES CAT16..4
RP804 RES CAT16..4
RP805 RES CAT16..4
RP901 RES CAT16..4
RP902 SIL_9W
RP1101 RES CAT16..4
RP1102 RES CAT16..4
RP1103 RES CAT16..4
RP1104 RES CAT16..4
RP1105 RES CAT16..4
RP1106 RES CAT16..4
RP1107 RES CAT16..4
CYRUS AV5 PCB COMPONENTS
1k MF 1/8W 1%
47k MF 1/8W 1%
100k MF 1/8W 1%
10k MF 1/8W 1%
1R MF 1/4W 5%
10k MF 1/8W 1%
3.3R MF 1/8W 1%
680R MF 1/8W 1%
10k MF 1/8W 1%
10k MF 1/8W 1%
10k MF 1/8W 1%
10k MF 1/8W 1%
10k MF 1/8W 1%
10k MF 1/8W 1%
47R MF 1/8W 1%
47R MF 1/8W 1%
680R MF 1/8W 1%
270R MF 1/8W 1%
47R MF 1/8W 1%
47R MF 1/8W 1%
47R MF 1/8W 1%
47R 4 off resistor pack
47R 4 off resistor pack
47R 4 off resistor pack
47R 4 off resistor pack
47R 4 off resistor pack
47R 4 off resistor pack
47R 4 off resistor pack
47R 4 off resistor pack
47R 4 off resistor pack
47R 4 off resistor pack
100k 8-Commoned resistor pack
47R 4 off resistor pack
47R 4 off resistor pack
47R 4 off resistor pack
47R 4 off resistor pack
47R 4 off resistor pack
47R 4 off resistor pack
47R 4 off resistor pack
11 July 2000
