Foscam FosBaby Quick Installation Manual

Quick Installation Guide
HD Wireless Baby Monitor
FosBaby
Power Adapter
Security Warning
Foscam cameras require good security practices to
safeguard your privacy. You can help protect your camera
by changing the default username and/or password.
You should update your camera regularly at
FosBaby
http://www.foscam.us/firmware.html. Make sure your
camera has the latest firmware installed for your specific
camera model.
V1.0
EE200402
4. After finishing Soft AP connection, use the web browser of the
terminal to visit http://192.168.1.1:88.
5. Log in to the camera ( Default username is admin with no
password ). When you login for the first time, it will request that
you modify the default username and/or password.
Foscam Digital Technologies LLC
www.foscam.us
1

Package Contents

Warning 1.1 Physical Description
The wire wrapped the
baby neck may cause
choking. Please keep it
1 meter away from
your baby.DO NOT
tear this stickers.
Mounting Bracket Temperature Detection Watch strap Warning Sticker
Sensor
Quick Installation Guide
HD Wireless Baby Monitor
FosBaby
Power Line Resource CD Quick Installation Guide Security Warning
Card
Notes:
You can use a mobile power whose output current is 5V/2A
to provide power for FosBaby. We recommend that you choose
the capacity of 5000 mAh mobile power, it can provide power
for about 6.5 hours.
Due to the insufficient of current strength, we do not
recommend that you use PC or laptop to provide power for
FosBaby.
Note:
When logging in for the first time, you need to download and
install the add-on.
6. After logging in for the first time, it will go to "Setup Wizard"
automatically. Please set the basic parameters of FosBaby, such as
camera name, camera time, wireless settings (The FosBaby
connect to your wireless router: Wireless Network List - enter the
Input the New username,
New password and password of your wireless router ), IP configuration.
Confirm the password.

Hardware Introduction

1.2 Hardware Installation

Put the camera on the desk
Speaker
WPS
Wireless Router
Indicator Light
Power
Micro-SD Card Slot
Temperature Detection
LENS
Power
Sensor
Use a watch strap for fastening
Warning Sticker
Use a fastening watch strap to fasten the camera on a certain
Soft AP
column where the baby can be monitored conveniently.
WPS / Reset
Microphone
Click Install Click Install
2

FosBaby Connection

Install it on the wall
1. Start FosBaby: power on, the indicator light of FosBaby will
light on, and a short musical tone indicates that the startup is
completed.
2. Press the Soft AP button for 3-5 seconds. The indicator
begins to twinkle at very high frequency.
3. Use a terminal which could search the WLAN (desktop,
laptop, mobile phone, or pad. This part takes laptop as an
example.) to search for the AP named "
connection.
WPS / Reset Soft AP
Soft AP Button
Recommend to select
"Obtain IP Form DHCP".
Notes:
We recommend you to choose to manually set the IP
when you know some knowledge of the network.
It needs about 1 minute to connect FosBaby to your
router.
7. Please connect your laptop to the router which your
FosBaby has connected to.
FosBaby_******
" for
The last six letters of FosBaby's
MAC ID.
