Foscam FosBaby Quick Installation Manual

142.5mm
Quick Installation Guide
Wireless HD Baby Monitor
FosBaby FosBaby P1
V1.8
"Foscam" App download
EQFB0012
.00
.00
95.00mm
1
Hardware Introduction
Package Contents
1.1
Physical Description
FosBaby
Temperature Detection
IP Camera Mounting Bracket
Sensor
Wireless Router
Watch strap Power Adapter USB Power Cable Remote Control
(Fosbaby P1 only)
Quick Installation Guide
HD Wireless Baby Monitor
WARNING:
FosBaby FosBaby P1 STRANGULATION
HAZARD!
in cords. Keep this cord out Children have STRANGLED
of the reach of children (more than 3ft(0.9m)away).
Do not remove this tag.
"Foscam" App download
Power
Quick Installation Guide Warranty Card Warning Sticker CD-ROM
190.00mm
FosBaby P1
Lens
Lens
Microphone
Soft AP
Soft AP
WPS / Reset
WPS / Reset
Microphone
WPS
Speaker
Micro-SD Card Slot
Wi-Fi & System
Wi-Fi Status Light
Status Light
Power
Micro-SD Card Slot
Temperature Detection
Temperature & Humidity
Sensor
Detection Sensor
Warning Sticker
285.00mm
Remote Control Description:
One Key Alert o
One Key Alert on
Night Lamp
Speaker Volume Up
Speaker Volume Down Play/Stop Lullabies
Up Control
Snapshot
Left control
Right Control
Down Control
WPS
Wireless Router
Please Note:
If you used snapshot by the remote control, the default
storage path of snapshot les are FTP server and SD card.
Speaker
Wi-Fi Status Light
Night Lamp
Wi-Fi Light Description
Power
O No Wi-Fi connection
Warning Sticker
Flashing every 0.1 seconds Soft AP takes e ect
Flashing every 0.2 seconds EZLink takes e ect (default)
Flashing every 0.4 seconds WPS is connecting
Slow Flash every 1.0 second Wi-Fi connected
380.00mm
Please Note:
If required, the Fosbaby camera can also be powered
using portable or mobile power sources. We suggest
an output of 5V/2A and a capacity of 5000 mAH. Under
ideal conditions this will provide about 5 hours of use.
We do not recommend the use of a PC or Laptop
power source due to their insu cient current strength.
Use of these power supplies may result in damage or
inconsistent functioning of your Fosbaby camera.
Before you continue, please note:
Make sure your smartphone is located near the
Fosbaby camera.
Your smartphone should be connected to the same
Wi-Fi network as your fosbaby camera.
After plugging the Fosbaby P1 to the power supply,
the FosBaby P1 will automatically run, cruise startup
(Fosbaby P1 only).
475.00mm 570.00mm
