250-8309, 250-8309B, and 250-8309-LPB Installation Instructions
Parts Identification
Vehicle Preparation
System Layout
Installation
Troubleshooting
Parts Identification
Item Qty.
Part Number
1
1
250-8208
2
1
250-8082
3
1
250-8083
4
1
250-8092
5
1
250-8505
6
1
250-8584
7
1
250-8579
8
1
250-8598
Vehicle Preparation
Before beginning your installation, familiarize yourself with the installation instructions and the RearSight
camera system components.
To ensure your safety, (A) apply the emergency brake and (B) read this entire manual before beginning.
CAUTION: It is advisable to disconnect the negative battery cable for 3 minutes before
beginning installation, to avoid unintended air bag deployment. Note and record any anti- theft
radio codes prior to disconnecting.
Form #5397, 5-03-2012
Rostra Precision Controls, Inc. - 2519 Dana Dr. - Laurinburg, NC 28352 - 800-782-3379 - rostra.com
REARSIGHT CAMERA SYSTEM
Description
4.3" LCD Mirror/Monitor
CMOS Camera (Hinge/Tab)
CMOS Camera (Bullet)
CMOS Camera (License Plate)
Male DC Power Harness
S-video to RCA Adapter Harness
30-foot S-video Extension Harness
Sack Parts: Tie Straps, T-taps, Foam Tape
Page 1
Page 1
Page 2
Page 2
Page 2
Page 1
