Declaration of conformity for the European Community
ATLINKS declares that Alcatel Conference IP1550 complies with the relevant basic requirements and
provisions of the European directive 1999/5/CE. You can download the declaration of conformity from
the following address: www.alcatel-business.com.
The CE logo shown on the products indicates that they are compliant with the basic requirements of all
the applicable directives.
Environment
This symbol means that your inoperative electronic appliance must be collected separately
and not mixed with the household waste. The European Union has implemented a specific
collection and recycling system for which producers' are responsible.
This appliance has been designed and manufactured with high quality materials and components that
can be recycled and reused.
Electrical and electronic appliances are liable to contain parts that are necessary in order for the
system to work properly but which can become a health and environmental hazard if they are not
handled or disposed of in the proper way. Consequently, please do not throw out your inoperative
appliance with the household waste. If you are the owner of the appliance, you must deposit it at the
appropriate local collection point or leave it with the vendor when buying a new appliance.
(a)- If you are a professional user, please follow your supplier's instructions.
(b)- If the appliance is rented to you or left in your care, please contact your service provider.
Please help us protect the environment in which we live!
Notice of copyright and trademarks
Copyright © 2016 ATLINKS. All rights reserved. ATLINKS reserves the right to change the technical
specifications of its products without prior notice, so as to make technical improvements or respect
new regulations.
Alcatel is a registered trademark. Alcatel logo and Alcatel name are trademarks of Alcatel Lucent and
used under license by ATLINKS.
Visual indicators description
LED status
Steady orange
Flashing orange
Steady green
Flashing green
Steady red
Slow flashing red
Flashing green and red
Steady blue
Flashing blue
Slow flashing blue
Display icon description
Model : IP1550
A/W No.: 10001567 Rev.0 (EN)
Printed in China
Led 1
Led 2
Led 3
ErisStation
IP1550
14:10
25/03/2015
Redial
Directory
Main Unit
Speakerphone in use (led1)
Incoming call (led1)
Mute activated (led 1)
Bluetooth device connected (led 2 and 3)
- Incoming call on Bluetooth device
(led 2 and 3)
- Main unit in Bluetooth registration mode
(alternatively led 2 and 3)
A call is held (led 2 and 3)
Line registered
Line disabled
Line unregistered
Speakerphone activated
Ringer off
Conference IP1550

QUICK START GUIDE

Visual indicator
Navigation keys
Menu key
OK key
Call hold
Back/Cancel key
Soft keys
On hook/off hook
During ringing : increase or decrease
ringer volume
In communication : increase or
decrease speakerphone volume
In communication mode : mute/unmute
a call (central unit and mics)
Wireless mics
Charging in progress
Low battery
Mic in use
Incoming call
All mics muted
Mic in paging mode, out of range or not registered
- Registration mode
- Unregistratered mic in charge
Received call
Dialled call
Missed call
Call forward enabled
Do not disturb function activated
