Alcatel IP1550 Manual

Conference phone connections / Branchements du téléphone de conférence / Conexiones del sistema de audioconferencias /
Ligações do telefone / Collegamenti del sistema di audioconferenza / Anschlüsse / Telefoonaansluitingen
Slots
Ethernet cable
with yellow plugs
To Adapter
or PoE Switch
Option 1
With PoE switch
PoE switch
1
Option 2
With power adapter
Ethernet cable
Battery X2
Wall outlet
3
RF frequency band
Channels
Operating Temperature
AC power cord
AC Adapter
Adapter
AC Adapter (EU plug)
2
AC Adapter (UK plug)
Network switch
or router
Ethernet network jacks
USB port
Battery pack (mics only)
/ Połączenia telefoniczne
Electrical and environmental Specifications
1881.792-1897.344MHz
10
0-50ºC (32-122ºF)
Input: 100-240Vac/Output:
9.0Vdc 1.5A, SMPS adaptor
Model#S018AGP0900150, manufactured by Ten
Pao International Ltd.
Model#S018AGP0900150, manufactured by Ten
Pao International Ltd.
It is same AC adapter with changeable EU/EK plug.
10/100 Mbps RJ-45 jacks
B-plug
Ni-MH 2/3 AAA 400mAh 2.4V
Ni-MH rechargeable battery pack. Only use the
batteries supplied with the telephone.
Caution: Use any other type of battery presents a
risk of explosion. Manufacturer: Corun.
Used batteries must be disposed of in compliance
with current environmental protection regulations.
Use only batteries listed above.
For pluggable equipment, the socket-outlet (power
adaptor) shall be installed near the equipment and
shall be easily accessible.
