Installation
1. 15-pin SATA Power & 7-pin Data
Connector
Step 1. Locate the SATA connector
of your 2.5" SATA drive.
1
Step 2. Connect the converter
board to the SATA connector of the
hard drive.
Step 3. (Optional) Connect the IDE
ribbon cable to the 44-pin connector
on the converter. The red edge of
the ribbon cable needs to line up to
pin 1 marker of the 44-pin connec-
tor. The other end of the ribbon
cable will be connected to your
motherboard's 44-pin IDE channel.
www.addonics.com
Technical Support (M-F 8:30am - 6:00pm PST)
Phone: 408-453-6212
Email: www.addonics.com/support/query/
