Front View
Back View
3
Jumper Settings
Master
NOTE: To set the SATA hard drive as a Master Device when connected to an IDE channel,
do not install a jumper. As a Slave Device short the middle pins.
www.addonics.com
Overview
1
2
4
Slave
Technical Support (M-F 8:30am - 6:00pm PST)
1. 44-pin IDE Connector
2. SATA Power and Data Connector
3. Master, Slave & Cable Select
Jumpers
4. Pin 1 Marker
Cable Select
Phone: 408-453-6212
Email: www.addonics.com/support/query/
