5

Terminals

5.1

Power terminal connections

Figure 5.1 Commander SE Size 1 power terminal connections
Thermal
protection
device
Figure 5.2 Commander SE Size 2 to 4 power terminal connections
When a Commander SE Size 2 200V unit is used on single phase, use terminals L1
NOTE
and L2.
Commander SE User Guide
Issue Number 8
L1 L2/N
Optional
RFI filter
Optional
line reactor
Fuses
Circuit breaker
/Isolator
L1 L2/N
Mains
Supply
-
+
DBR
Braking
Resistor
Stop
Start/
Reset
Optional
Drive Size Maximum Power Terminal Screw Torque
1 & 2
3 & 4
5
www.controltechniques.com
PE U V
*
Motor
Supply
* See Fuses on page 24
Ground
L1 L2 L3 PE
Optional RFI
filter
Optional
line reactor
Fuses
L1 L2 L3
Mains Supply
Supply Ground
1Nm (9lb in)
2Nm (18lb in)
15Nm (11lb ft)
W
Motor
Ground
U V W
Motor
Ground
Motor
34
