MODEL
AC supply voltage and frequency
Input displacement factor (cos φ)
Nominal motor power - kW
Nominal motor power - hp
Output voltage and frequency
100% RMS output current - A
150% overload current for 60 secs - A
Typical full load input current - A* 1ph/3ph
Typical inrush current - A**(duration <10ms)
Drive power losses at 230Vac at 6kHz switching
frequency - W
Weight - kg/lb
Cooling fan fitted
Table 3.3 Commander SE Size 2, 200V dual rated units
* See section 3.1.1.
** For an explanation of inrush current, see section 3.1.2.
MODEL
Recommended input supply fuse - A
Control cable
Recommended input cable
Recommended motor cable
Recommended braking resistor cable
MODEL
Minimum braking resistor value - Ω
Recommended braking resistor value - Ω
Resistor peak power rating - kW*
* Based on recommended braking resistor value.
Before fitting a braking resistor please read the information on Braking, and the
NOTE
Warnings on High Temperatures and Overload Protection at the end of this
section.
5
1ph
mm²
AWG
mm²
AWG
mm²
AWG
mm²
AWG
Table 3.4 Recommended supply fuses and cables
Table 3.5 Braking resistors
www.controltechniques.com
SE2D200...
075 110
Single or 3 phase 200 to 240V +/- 10%, 48 to 62Hz
>0.97
0.75 1.1
1.0
3 phase, 0 to input voltage, 0 to 1000Hz
4.3 5.8
6.5 8.7
11.0 5.5 15.1 7.9
55
54 69
2.75 / 6
No
SE2D200...
075 110
3ph 1ph 3ph
16 10 20 16
≥ 0.5
20
1.5 1.0 2.5 1.5
14 16 12 14
1.0
16
1.0
16
SE2D200...
075 110
50
100
1.8
150 220
1.5 2.2
2.0 3.0
7.5 10.0
11.3 15.0
19.3 9.6 26.2 13.1
35
88 125
Yes
150 220
1ph 3ph 1ph 3ph
25 16 32 20
2.5 1.5 4.0 2.5
12 14 10 12
1.5
14
1.5
14
150 220
40
75 50
2.4 3.5
