In Wall Recessed Electric Fireplace
Model Number: (EF172B, EF173B, EF174B, EF175B, EF176B)
Read and understand this entire owner's manual, including all safety information,
WARNING
before plugging in or using this product. Failure to do so could result in fire, electric
shock, or serious personal injury.
Keep this owner's manual for future reference. If you sell or give this product away,
CAUTION
make sure this manual accompanies this product.
WARNING DO NOT RETURN THIS PRODUCT!
Contact our customer service team for help first.
Alice
OWNER'S MANUAL
NO VENTING REQUIRED
120V AC; 60 Hz; 1500 Watts
customerservice@puraflame.com
Call: 844-377-5786

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Alice EF172B and is the answer not in the manual?

Questions and answers

Related Manuals for PuraFlame Alice EF172B

Summary of Contents for PuraFlame Alice EF172B

  • Page 1 Keep this owner’s manual for future reference. If you sell or give this product away, CAUTION make sure this manual accompanies this product. NO VENTING REQUIRED 120V AC; 60 Hz; 1500 Watts WARNING DO NOT RETURN THIS PRODUCT! Contact our customer service team for help first. customerservice@puraflame.com Call: 844-377-5786...

  • Page 2: Table Of Contents

    CONTENTS 1. Important Safety Information …………………………………..………………………….…………….. 2. Technical Specifications…………………………….………………..………………………….………. 3. Parts and Hardware …………..…………………………………….……………………….…....4. Appliance Dimensions …………………………………………….………………………………….…. 5. Installation Instructions..………………………………………………………………………………….. 6. Operating Instructions.…………………………………………………………………………………… 6a. Manual Control Panel…………………………………………………………………………..……… 11 6b. Remote Controls..…………………………………………………………………………….……….. 7. Care and Maintenance……………………………………………………………………………………….. 14 8. Schematic Diagram…………………………………………………………………………………………. 9.

  • Page 3: Important Safety Information

    1. IMPORTANT SAFETY INFORMATION When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following:  Read all instructions before using this appliance.  Use this appliance only as described in this manual. Any other use not recommended by the manufacturer may cause fire, electric shock, or injury to persons.

  • Page 4: Technical Specifications

     ALWAYS disconnect this unit from the power supply before performing any assembly or cleaning, or before relocating the electric fireplace.  Always use properly grounded, fused and polarized outlets.  Always use ground fault protection where required by electrical code. ...

  • Page 5: Parts And Hardware

    3. PARTS AND HARDWARE WARNING! DO NOT use this Electric Fireplace if any part has been under water. Immediately call a qualified service technician to inspect and to replace any part of the electrical system if necessary. Keep plastic wrapping away from children. ...

  • Page 6: Appliance Dimensions

    ST 4*10 Metal Screws (4 pcs) Washers (4 pcs) ST 4*25 Wood Screws (4 pcs) Owner’s Manual (1 pcs) Fixing Brackets (2 pcs) 4. APPLIANCE DIMENSIONS...

  • Page 7: Installation Instructions

    Model 40 9/16″ 20 1/4″ 31 1/2″ 11 1/4″ 35″ 17 13/16″ 5 11/16″ EF172B (1030mm) (515mm) (800mm) (285mm) (888mm) (453mm) (145mm) 48 7/16″ 20 1/4″ 39 3/8″ 11 1/4″ 42 13/16″ 17 13/16″ 5 11/16″ EF173B (1230mm) (515mm) (1000mm) (285mm) (1088mm) (453mm)
  • Page 8 Preparing Power Supply  The fireplace is packaged with a three prong plug installed for plug-in convenience. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. It must be easily accessible to allow disconnection.
  • Page 9 Electrical Connection WARNING: Do not attempt to wire your own new outlets or circuits. To reduce the risk of fire, electric shock or injury to persons. Always use a licensed electrician. WARNING: Ensure that the circuit on which the fireplace is to be installed has the power cut off at the service panel until installation is complete.
  • Page 10 5.4 Lift fireplace and insert into opening and fix the fireplace on the wood stud by the screws (ST4X25 4 pcs ). Make sure the front of the firebox is not lower than the surface of the wall. Fuel Bed The appliance is supplied with 2 fuel effect options: a.
  • Page 11 5.5b Log Effect Logs must be positioned according to the following instructions to give the correct flame effect. The log layouts below cover all models. Please refer to Diagram and table on page 10 to identify the logs for specific models. The logs for the fuel bed are NOT individually labeled; the numbers are for reference information only.

  • Page 13: Operating Instructions

    CAUTION! The next step requires installation of a GLASS panel! The manufacturer recommends that two adults install the glass panel. Always use extreme caution when handling glass. Failure to do so could result in personal injury or property damage. 5.6 Carefully set both hooks of the front glass panel onto the firebox. NOTE: Make sure the glass fully attached to the firebox so that the control panel can work properly.
  • Page 14 ICON TITLE FUNCTION FIREPLACE RESPONSE The POWER button will turn the fireplace on. It will also put the fireplace in a standby mode. Fireplace emits single audible This will turn off all functions at once but will beep to confirm command to POWER hold the settings in memory except Heater transition to ON or STANDBY...

  • Page 15: 6B. Remote Controls

    6b. Remote Controls Remote Control Battery  This remote control uses two AAA batteries (included).  Instructions for battery installation are inside the Remote Control battery compartment.  Battery must be recycled or disposed of properly. Check with your local authority for recycling advice in your area.

  • Page 16: Care And Maintenance

    Fireplace emits signal audible beep to confirm command to Press Heater button, the heater will transition between ON LCD illuminates cycle the heat setting: Low – High and OFF. Fireplace HEATER and displays heater –Off. displays red LEDs for status icon. 8 seconds to confirm command.

  • Page 17: Schematic Diagram

     NEVER use abrasive cleansers, liquid sprays, or any cleaner that could scratch the surface. Plastic:  Wipe gently with a slightly damp cloth and a mild solution of dish soap and warm water.  NEVER use abrasive cleansers, liquid sprays, or any cleaner that could scratch the surface. Vents: ...

  • Page 18: Faq - Frequently Asked Questions

    9. FAQ – FREQUENTLY ASKED QUESTIONS  Why does the fan blow before the heat comes on, and after the appliance is turned off? Heat and cool gradually. The fan blows when the appliance is first turned on, and the heat is still heating up.

  • Page 19: Troubleshooting Guide

    The flame button doesn’t work. 2. If the house circuit breaker is ON, and the functions do not work, please e-mail us at customerservice@puraflame.com The flame effect does not turn off 1. Make sure the batteries are installed properly. If it still cannot when I press the flame button.

  • Page 20: Limited Warranty

    Thank you for purchasing this product! If you have questions about assembly or operation of this product, are missing parts, or if the product is damaged, please e-mail us at: customerservice@puraflame.com Ningbo Richen Electrical Appliance Co.,Ltd Address: No.19,Yongdinghe Road,Xiapu,Beilun,Ningbo PR.China...
