ELECTRIC FIREPLACE INSERT
Model No.: WESTERN (EF42D-45D)
OWNER'S MANUAL
Read and understand this entire owner's manual, including all safety
information, before plugging in or using this product. Failure to do so could
WARNING
result in fire, electric shock, or serious personal injury.
Keep this owner's manual for future reference. If you sell or give this product
CAUTION
away, make sure this manual accompanies this product.
NO VENTING REQUIRED
120V AC; 60 Hz; 1500 Watts

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WESTERN EF42D-45D and is the answer not in the manual?

Questions and answers

Related Manuals for PuraFlame WESTERN EF42D-45D

Summary of Contents for PuraFlame WESTERN EF42D-45D

  • Page 1 ELECTRIC FIREPLACE INSERT Model No.: WESTERN (EF42D-45D) OWNER’S MANUAL Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product. Failure to do so could WARNING result in fire, electric shock, or serious personal injury. Keep this owner’s manual for future reference.

  • Page 2: Table Of Contents

    CONTENTS Important Safety Information ……………………………………………………........3 Preparation …………………………………………………………………………………………….….…... 5 Product Dimension …………………………………………………………………………………….……. 6 Assembly ……………………………………………………………………………………………….……... 7 Battery Information ………………………………………………………………………………………..… 7 Operation ……………………………………………………………………………………...………………. 8 Control Panel ………………………………………………………………………...………………… 9 Remote Control …………………………………………………………………………………...….. 10 Care and Maintenance ………………………………………………………………………………….…. 11 Schematic Diagram ………………………………………………………………………………………... 12 FAQ –...

  • Page 3: Important Safety Information

    IMPORTANT SAFETY INFORMATION! WARNING Read all instructions before using this heater! This heater is hot when in use. To avoid burns, DO NOT let bare skin touch hot surfaces. If provided, use handles when moving this heater. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9m) from the front of the heater, and keep them away from the sides and rear.

  • Page 4: Save These Instructions

    heater voids all warranties, and could cause injury. This product is not intended to be a primary heat source. It is for supplemental heat only. INDOOR use only! NEVER use this heater outdoors! Doing so may result in electric shock! Risk of electric shock! DO NOT OPEN! No user-serviceable parts inside! NEVER modify this heater.

  • Page 5: Preparation

    PREPARATION DO NOT use this Electric Fireplace if any part has been under water. Immediately call a qualified service technician to inspect and to replace any part of the electrical system if necessary. Keep plastic wrapping away from children. Unpacking the Electric Fireplace. Remove all parts and hardware from the carton and place them on a clean, soft, dry surface.

  • Page 6: Product Dimension

    PRODUCT DIMENSIONS Fireplace Insert Fireplace Mantel Units:mm Mantel opening size Width Height Depth Mantel Minimum Depth Width Height Model （W） （H） （D） （RD） （OW） （OH） EF42D 580-610 510-540 EF43D 660-690 590-620 EF44D 760-790 590-620 EF45D 840-870 650-680 Units:inch Mantel opening size Width Height Depth...

  • Page 7: Assembly

    ASSEMBLY ALWAYS unplug this fireplace heater before assembly or cleaning, or before relocating. Failure to do so could result in electric shock, fire, or personal injury. KEEP drapery and other furnishings at least 3ft /0.9m from the front and sides of the electric fireplace.

  • Page 8: Operation

    OPERATION Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product. Failure to do so could result in electric shock, fire, serious injury, or death. Power Make sure the Power Switch, located on the control panel, is in the OFF position. Plug the power cord into a 110~120 Volt 15 Amp outlet (see IMPORTANT SAFETY INFORMATION on Pages 3 and 4).

  • Page 9: Control Panel

    Control Panel Located on the right and top side panel of the fireplace. BUTTON NAME FUNCTION Turn on the main power supply. A long “beep” sound will be heard when the switch is turned on On Position “I”. POWER Note: The remote control will lost the memory for function settings SWITCH when the switch is turned on Off Position “0”.

  • Page 10: Remote Control

    Remote Control Control panel Power Switch must be ON to use remote control. NOTICE: Aim the remote control at the remote receiver. Make sure you hear a beep each time you press the button! If not, the fireplace will not respond to the signal. REMOTE BUTTON NAME...

  • Page 11: Care And Maintenance

    CARE AND MAINTENANCE ALWAYS turn the heater OFF and unplug the power cord from the outlet before cleaning, performing maintenance, or moving this fireplace. Failure to do so could result in electric shock, fire, or personal injury. Cleaning NEVER immerse in water or spray with water. Doing so could result in electric shock, fire, or personal injury.

  • Page 12: Schematic Diagram

    SCHEMATIC DIAGRAM...

  • Page 13: Faq - Frequently Asked Questions

    FAQ - FREQUENTLY ASKED QUESTIONS Why does the fan blow before the heat comes on, and after the heater is turned off? Heat and cool gradually. The fan blows when the heater is first turned on, and the heat is still heating up.

  • Page 14: Troubleshooting Guide

    2. If the Power Switch is ON, and the functions do not work, please e-mail us at customerservice@puraflame.com The heater does not work. 1. Make sure the Power Switch on the control panel turned on. 2. Control Panel: Press the heater button on the control panel to override the thermostat at any time.

  • Page 15: Limited Warranty

    This product is not intended to be used as a primary heat source. It is for supplemental heating purposes only. Thank you for purchasing this product! If you have questions about assembly or operation of this product, are missing parts, or if the product is damaged, please e-mail us at: customerservice@puraflame.com...
  • Page 16 3.EF.42.05.456 A/0...
