- Page 1 © ™ Instruction Manual ® Model RAM-30 UL For Class I Vehicular Gate Operators No. 545327 REV 5/02...
-
Page 3: Table Of Contents
Table of Contents Important Safety Requirements & Instructions ........2,3 Mechanical Specifications . -
Page 4: Important Safety Requirements & Instructions
8. SAVE THESE INSTRUCTIONS. NOTE: Always consult and follow all local building and electrical codes prior to installation. Ramset Gate Operators should not be installed without non-contact sensing devices such as non- contact sensors, photo electric sensors or the equivalent. -
Page 5: Mechanical Specifications
operating the controls. Controls intended to be used to reset a Vehicular Gate Operator after 2 sequential activations of the entrapment protection device or devices must be located in the line-of-sight of the gate. Outdoor or easily accessible controls shall have a security feature to prevent unauthorized use. All warning signs and placards must be installed where visible in the area of the gate. - Page 6 Figure 1 Alarm Horn Operators shown with covers removed Radio Receiver Terminal Strip Figure 2 Electrical PBC Conduit Power Switch R A M S E T R A M S E T R A M S E T - 4 -...
-
Page 7: Installation Specifications
Installation Specifications Pad Construction: 2. Locate mounting pad according to dimensions given in illustration. Dimensions given for pad are based on soil bearing shear of 2000 P.S.F. These figures may 3. Level top edge of form. have to be adjusted depending on local soil con- 4. - Page 8 4. Slowly open the gate. While opening the gate, place a finger against the string (see point A, Figure 9) and hold the string taunt and level until the gate is fully open. * If the wall is too close to the operator to overlap the string, place point A as close to the wall as...
-
Page 9: Gate Travel Adjustment
GATE TRAVEL ADJUSTMENT To a d j u s t g a t e t r a v e l , l o o s e n s e t s c r e w ( s ) o n Cam Slam(s) and rotate to required posi- tion (Figure 11). -
Page 10: Electrical Connection
ELECTRICAL CONNECTION A 3 wire, 120VAC electrical circuit with a 15 amp independent circuit breaker is required for each oper- ator. Ideally, the electrical conduits should exit the concrete under the operator. Low voltage control wires must be run in a separate conduit to the operator as shown. Intelligate ©... -
Page 11: Introduction
SPECIFICATIONS Used with a three button switch or a pedestrian entranceto stop INTRODUCTION the gate. Ramset’s “Intelligate” Control board is for operating a vehicular DIP FUNCTION gate operator. The control board is available for either 110VAC or ‘off’ normal operation 220VAC, single phase, applications. -
Page 12: Terminal Strip Connections
DIP SWITCH B5: “LAG DELAY” SAFETY INPUT DESCRIPTION Note: if both B5 & Lag on Close B6 are 'on', there One second lag on close Limit 1 & Limit 2 – Depending on dip switch B7 (see “dip will be NO lag on switch features”), stops the motor from moving in one direc- the open or close. -
Page 13: Wiring Diagram
Electronic Control Board must be serviced by a certified technician only. Power must be turned OFF before servicing operator. Power must be turned OFF before attempting to adjust the limit switches. Power must be turned OFF for power failure release. WIRING DIAGRAM Figure 15 NEUTRAL... -
Page 14: Sensor Installation
SENSOR INSTALLATION WARNING Reversing Sensors on the ground floor prevent A non-contact sensor (photoelectric sensor or gate from closing when vehicle is in loop area. equivalent) and a contact sensor (edge device or Exit Loops on the ground floor opens gate when equivalent) is required on each individual instal- vehicle crosses loop area. -
Page 15: Master-Slave Installation
MASTER-SLAVE INSTALLATION Figure 17 Set Dip Switch “Slave Mode” to ON for Slave Operator. RH operation requires Dip Switch “Reverse” to be ON. Use jumper Use jumper JP6 to JP6 JP6 to JP6 Conduit for Low Voltage Conduit for High Voltage Use 3-stranded, shielded wires (not supplied) from Master to Slave. -
Page 16: Ram-30 Bill Of Materials
BILL OF MATERIAL FOR RAM-30 PIECES ITEM PART # PART DESCRIPTION FOR RAM-30 PER UNIT 50-026 gear reducer size 50 50-033 1/2 hp 115 vac electric motor 50-039 20 pin edge connector 50-050 40 b 12 7/8" sprocket 50-069 limit switch 00-h3 50-084 # 40 drive chain 50-095... -
Page 17: Ram-30 Parts Diagram
MODEL RAM-30 UL PARTS DIAGRAM Figure 18 R A M S E T R A M S E T R A M S E T - 15 -... -
Page 18: Glossary
O U R W E B S I T E W W W . R A M S E T I N C . C O M Ramset Automatic Gate Systems (800) 771-7055 9116 De Garmo Ave. Sun Valley, CA. 91352...
