Skytech RCAF-1035 Installation And Operation Instruction Manual

INSTALLATION AND OPERATION INSTRUCTIONS
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS DO

INTRODUCTION

This remote control system was developed to provide safe, reliable, user-friendly remote control system for gas heating
appliances. The system can be operated manually from the transmitter. It operates a HI/MED/LO step motor.

TRANSMITTER

SIGNAL
LIGHT
ON/OFF
ON/OFF
H/M/L
BUTTON
HI/MED/LO
BUTTON
FRONT

KEY SETTINGS

ON/OFF
H/M/L
THE REMOTE RECEIVER SHOULD BE POSITIONED WHERE AMBIENT

RECEIVER

Install the (4) AA-size batteries supplied with the unit. It is recommended that ALKALINE batteries always be used for this
product. Be sure the batteries are installed with the (+) and (-) ends facing the correct direction.
The remote receiver has a 2-position slide switch for selecting the
mode of operation, which is OFF/REMOTE.
• REMOTE: The receiver must be in this position if you want to
use the appliance, you must use the transmitter to turn ON
the appliance. If the system does not respond to the transmit-
ter on initial use, check the battery positions in the remote. If
that does not work, see the LEARNING TRANSMITTER TO
RECEIVER section.
• OFF: Disables the remote receiver.
• It is suggested that the slide switch be placed in the
OFF position if you will be away from your home for an
extended period of time.
Skytech: RCAF-1035
MODEL: RCAF-1035
NOT ATTEMPT TO INSTALL OR OPERATE
he transmitter operates on a 12-volt (A23) battery that is included. Install the 12V
T
WALL CLIP
SLOT
battery supplied into the transmitter battery compartment. It is recommended that
ALKALINE batteries always be used for this product. Be sure the batterery is
installed with the (+) and (-) ends facing the correct direction.
The LED signal light should illuminate when either the ON/OFF or HI/MEDIUM/LOW
button is pressed. If the signal light does not illuminate, check the position of the
transmitter's battery, and if the battery is fully charged.
12V
BATTERY
COMPARTMENT
BACK
1
1. ON/OFF - This turns the appliance ON or OFF.
2. H/M/L - This controls the height of the flame. It has three levels; High, Medium, Low
2
TEMPERATURES DO NOT EXCEED 130º F.

IMPORTANT

Learning
button
Slide
Switch
REMOTE
OFF
Requires 4-AA 1.5V
alkaline batteries
Remote Receiver
REV. 5-17-16 Page 1
