Page 1: Steam Oven
Instructions for the Use and Care and Installation of OS450X Steam Oven CONTENTS - 1 -... -
Page 2: Important Safety Information
NOTE: This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference; for you or any person not familiar with the operation of the appliance. - Page 3 Warning • The Appliance is not intended for use by persons (including Children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervised instruction concerning use of the appliance by a responsible person for their safety. •...
- Page 4 Product description Technical Specifications Rated using Voltage：220-240V, 50/60Hz。 Rated using power：1900W Oven capacity：28L Water tank capacity：1.2L Spare part 1. Steam oven with bellowing spare parts: a、one pair of side shelf, the food can be steam or bake in three different height positions b．one food shelf c．one big pan left side shelf...
- Page 5 1、Control panel Fuctions Clock functions/Operating time Temperuture/Meory program Clean symbol Child safety device Clean On/Off button Operating start button Function button Child safety button Memory Function Clock function Clean Function Selection buttons Temperuture selection button 2. The use of water tanks Water tank is necessary to provide water to generate steam.
- Page 6 2. Set clock： Every power on can be set clock. the display "0:00" starts to flash, long press or short press button when flash，Hour "0" can be quickly adjusted from 0-23 by cycles，Press the OK button to confirm the hours time, If not button, it will automatically confirm after 6 seconds, and converted to minutes “00 Min”...
- Page 7 Clock function: when steam function operating，press the button , the display will show the time, long press or short press button，minute “00”can increase or reduce rapidly. When increasing to“59”minutes，the hour time will add “1”；when reducing to “00”，the hour time reduce to “1”，the time can be stetted in the range of”0:00—6:00”。Press button after setting，the clock setting is finished, the countdown is beginning, function symbol...
- Page 8 6． Automatic setup function Press to automatic setup function after starting up, function icon and gears icon will flash, and you can chose 14 automatic function models circulatively by each press .The function icon and gear icon will flash synchronically when you choose the corresponding function mode, please directly press button to begin working, and the system will get in working station automatically without pressing button within 6 seconds.
- Page 9 ，open child safety lock. It can operate functions. Keeping press Child safety lock till not show symbol When Child safety lock starting which still can stop steam oven working, pressing power button can stop operation。 9. Cleaning Function Inner Container Cleaning of Steam Oven Sump Oil is easy to be removed after the dirt on the inner container and assembly is softened by steam.
-
Page 10: Door Installation
Note: The lighting should be off when cleaning and calcium removing of steam heating dish. Steam-oven using guildline 1、Please refer to the related information of the cooking temperature and time which shown on the food packaging. When you are familiar with use of the steam oven, you can follow your own habits to set the cooking temperature and time. 2、If you are using hot-air circulation for cooking, you should refer to the pattern of such proposals of cooking on the food packaging. - Page 11 2． Clean the inner glass of the oven door To clean the inner glass of the door, please remove the door from oven 1. put the door on the table with handle down 2. Take the internal glass out by removing the screw on the bracket 3.
- Page 12 4、You should select a cooking temperature and function that is appropriate for the food that you are cooking. You should also ensure that the food is placed in an adequately sized dish and that you use the drip tray where appropriate. 5、To clean the surface of steam oven, also use the sponge or soft cloth with hot suds instead of abrasive detergent.
- Page 13 The dimensioned drawing for installation of steam oven and cabinet. Ensure the steam oven installed safety in cabinet and fixed by two screws which should be inserted from steam oven(A). Notice! The false installation method as following: Abnormal analysis Steam oven does not work Check if the steam oven works under manual operation mode.
- Page 14 Come out condensate water in steam oven In the condition of full volume water to cook food, it is very nature to come out the steam and condensate phenomenon when you cook the freezing food, chicken, etc. Information code When the steam oven working without water; the fault code will display E001,and the buzzer will honk accordingly. When the sensor short circuit or open circuit, the fault code will display E002,and the buzzer will honk accordingly.
- Page 15 Steam Manual Defrost Weight of Temperatu Function Food Bake Pan Pan Position Time (min) Food re ( Chicken 1500g Rack + Hole less Pan 45-60 Beef 2500g Rack + Hole less Pan 45-60 - 15 -...
