- Page 1 Instruction Manual OMEGA OVEN OBO699W...
- Page 2 Thank you for purchasing an Omega appliance Tailored for the modern aesthetic and lifestyle of busy people, your new Omega Appliance will make a welcome addition to the family. Omega caters to style-savvy customers who look for balance between stunning form and clever function.
-
Page 3: Table Of Contents
The manufacturer will not be responsible for any damage to property or to persons caused by incorrect installation or improper use of the appliance. Due to continual product development, Omega reserves the right to alter specifications and appearances without notice. -
Page 4: Important Safety Warnings
Important Safety Warnings IMPORTANT: Read the assembly instruction section and safety precautions of this booklet carefully before removing the contents of this carton. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience or knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety. -
Page 5: Appliance Details
Appliance Details Electrical Details Model OBO699W Voltage Rating 220-240V ~50Hz Power Rating 2400-2800W Dimensions LENGTH (mm) WIDTH (mm) HEIGHT (mm) Electrical Connections LOCAL AUTHORITY REQUIREMENTS Installation is only permitted by a licensed electrician, and carried out according to instructions provided by the manufacturer. Incorrect installation might cause harm and damage which the manufacturer accepts no responsibility. -
Page 6: Installation Instructions
Installation Instructions This appliance must be installed by an authorised service person or qualified technician, according to the instructions in this guide and in compliance with the current local regulations. Incorrect installation may cause harm and damage, for which the manufacturer accepts no •... - Page 7 Installation Instructions After making the electrical connections, insert the oven into the cabinet by pushing it forward. Open the oven door and insert 2 screws in the holes located on the oven frame. While the product frame touches the wooden surface of the cabinet, tighten the screws.
-
Page 8: Operating Instructions
Operating Instructions Internal View Control Panel Oven Lamp Oven Door Wire Grill Handle Shallow Tray with grill insert Grill Element 8 mm Deep Tray When you first run your oven a certain smell will be emanated arising from the insulation materials and the heater elements. - Page 9 Operating Instructions Controls OVEN FUNCTION CONTROL The oven function control knob is used to select the different functions. Each is explained in detail. To select a function, turn the control knob to the desired oven function and then set the temperature with the OVEN THERMOSTAT CONTROL The oven thermostat control knob is used to select the desired temperature for cooking.
- Page 10 Operating Instructions During heated oven functions a cooling fan in the top of the oven will operate in order to cool down the oven door and kitchen cabinet as well as reducing condensation in the oven. There will then be a slight release of warm air from the top of the closed oven door.
- Page 11 Operating Instructions ENERGY SAVING Choose cookware of an appropriate size. Using a lid will reduce cooking times. Minimize the amount of liquid or fat to reduce cooking times. Oven door should not be opened often during cooking period. USING THE DIGITAL TIMER Function Description Auto cooking Manual cooking...
- Page 12 Operating Instructions Time Adjustment The time must be set before you start using the oven. When the oven is first connected to the power supply, the symbol “A” and “00:00” or “12:00” will flash on the display. Press the “MODE” button for 2 seconds to deactivate keylock. The dot in the middle of the screen will start to flash.
- Page 13 Operating Instructions Audible Warning Time Adjustment The audible warning time can be set to any time between “00:00” and “23:59” hours. The audible warning time is for warning purposes only. The oven will not be activated with this function. Press “MODE”. The “ ” symbol will begin to flash and “00:00” will be displayed. Select the desired time period using the “+”...
- Page 14 Operating Instructions Semi-automatic Time Adjustment (Cooking Period) This function helps you to cook for a fixed period of time. A time range between 0 and 10 hours can be set. Prepare the food for cooking and put it in the oven. Select the desired cooking function and the temperature using the control knobs.
- Page 15 Operating Instructions Semi-automatic Time Adjustment (Finishing Time) This function automatically starts the oven so that cooking will finish at a set time. You can set an end time of up to 10 hours after the current time of day. Prepare the food for cooking and put it in the oven. Select the desired cooking function and the temperature using the control knobs.
- Page 16 Operating Instructions Full-automatic Programming This function is used to start cooking after a certain period of time and for a certain duration. A time of up to 23 hours and 59 minutes after the current time of day can be set. Prepare the food for cooking and put it in the oven.
- Page 17 Operating Instructions Select the desired finishing time using the “+” and “-” keys. “ ” symbol will disappear. Add the cooking period to the current time of day. You can set a time of up to 23 hours and 59 minutes after this. The current time will reappear on the screen, and the symbols “A”, and will remain illuminated.
-
Page 18: Cooking Table
Cooking Table... -
Page 19: Accessories
Accessories Easy Fix Wire Rack Clean the accessories thoroughly with warm water, detergent and a soft clean cloth on first use. • Insert the accessory to the correct position inside the oven. • Allow at least a 1 cm space between the fan cover and accessories. •... - Page 20 Accessories It is recommended that you use the containers indicated depending on the food you will cook in your oven. You can also use glass containers, cake pans and special oven trays suitable for use in your oven (available in kitchenware shops). Pay attention to the information given by the supplier for use of this cookware.
- Page 21 Replacing the Oven Lamp • The appliance must first be disconnected from the power outlet or turned off at your isolation switch. • Unscrew the glass cover attached to the lamp holder; anti-clockwise. • Unscrew the lamp and replace it with another high-temperature lamp with the following characteristics: Type Voltage Rating...
-
Page 22: Cleaning
Cleaning NOTE: Cleaning and maintenance operations must only be carried out when the oven is cool. The appliance should be disconnected from the power outlet or turned off at your isolation switch before commencing any cleaning process. Cleaning the oven exterior Before starting to clean your oven, be sure that all control buttons are off and your appliance has cooled off. -
Page 23: Australian Product Warranty Statements Of Standard Warranty Conditions
The provided with the product. product will be repaired or replaced at the option of Omega, and Misuse or abuse, including failure to properly maintain or all costs of installation, removal, cartage, freight travelling service. -
Page 24: New Zealand Product Warranty Statements Of Standard Warranty Conditions
WHAT IS COVERED: By Our Warranty During the warranty period, Omega or its authorised Service Centre will, at no extra charge, if your appliance is readily accessible without the need of special equipment and subject to the terms and conditions of this warranty, repair or replace any parts which it considers defective.
